Klein G116.381.R R6/R2 Finger-Grip Router Bit

HW Z2 R6 / R2
Finger-Grip Profile Bit

A Klein G116 HW carbide finger-grip profile router bit with a 1/2-inch (12.7 mm) shank, 38.1 mm primary profile diameter, 17 mm secondary diameter, 21 mm primary cutting height, 18 mm secondary cutting height, and 59 mm overall length. The exact G116.381.R Item uses an R6 / R2 dual-radius profile for integrated pulls in compatible drawer and cabinet-door edges.

38.1 mm Primary Diameter (D1)

R6 / R2 Dual-Radius Profile

1/2 in Shank · 12.7 mm

Z2 Two Cutting Edges

Main Product Description

Klein G116.381.R is the exact 1/2-inch-shank Item in the E116–G116 family of HW Z2 finger-grip router bits. The official Item row specifies a 12.7 mm (1/2-inch) shank, 38.1 mm primary diameter, 17 mm secondary diameter, 21 mm primary cutting height, 18 mm secondary cutting height, 59 mm overall length, 6 mm primary radius, and 2 mm secondary radius.

The profile creates an integrated pull in compatible drawer fronts and cabinet doors, providing a positive grip and an easy edge for the fingers. Klein notes that the family can remove substantial material and recommends multiple passes when the required stock removal is large.

Verified workpiece groups include softwood, hardwood, and chipboard. Official machine guidance lists CNC machining centres, hand router machines, and router tables. Correct collet fit, cutter clearance, guarding, workholding, and progressive cutting depth are essential for controlled profile routing.

Technical Specifications

Family E116–G116 · SKU G116.381.R

BrandKlein
ManufacturerSISTEMI S.r.l.
Family / ReferenceE116–G116
SKU / Item CodeG116.381.R
Product TypeHW Z2 Finger-Grip Profile Router Bit
Shank (S)12.7 mm (1/2 inch)
Primary Diameter (D1)38.1 mm
Secondary Diameter (D2)17 mm
Primary Cutting Height (B1)21 mm
Secondary Cutting Height (B2)18 mm
Overall Length (L)59 mm
Primary Radius (R1)6 mm
Secondary Radius (R2)2 mm
Cutting Edges (Z)2
Active Cutting MaterialHW Carbide
Machine TypesCNC Machining Centres / Hand Routers / Router Tables
Supported MaterialsSoftwood, Hardwood, Chipboard
Primary OperationIntegrated Finger-Pull Profiling

Best Fit Applications

Integrated Cabinet-Door Pulls

Drawer-Front Finger Grips

R6 / R2 Edge Profiling

Softwood, Hardwood & Chipboard

CNC, Hand Router & Table

Product Highlights

Integrated Finger-Pull Profile

The verified E116–G116 geometry creates a recessed grip profile for compatible cabinet doors and drawer fronts without separate pull hardware.

R6 / R2 Dual-Radius Geometry

The exact 38.1 mm variant combines 6 mm and 2 mm radii with 21 mm and 18 mm working heights to form the specified profile.

HW Carbide Z2 Cutting

Two HW carbide cutting edges support compatible profiling in softwood, hardwood, and chipboard across the listed machine types.

Compatibility & Installation Notes

Confirm the exact G116.381.R Item code. This G-series version uses a 1/2-inch (12.7 mm) shank, not the 12 mm shank supplied on the corresponding E116.381.R variant. Use a clean compatible collet and verify cutter clearance, projection, guarding, fence or CNC toolpath, workholding, feed direction, and machine speed limits. Use multiple passes when removing large amounts of material.

R6 / R2 Cabinet Finger-Grip Profiling

Klein G116.381.R combines a 38.1 mm primary diameter, 17 mm secondary diameter, R6 / R2 dual-radius profile, 21 mm and 18 mm working heights, Z2 HW carbide geometry, and a 1/2-inch shank.

Correct shank identification, collet fit, clearance, guarding, pass depth, workholding, feed direction, and machine parameters are essential to controlled material removal and consistent profile quality.

Klein HW Z2 Finger-Grip Profile Router Bit, R6/R2 Profile, 1/2-Inch Shank

HW Z2 R6 / R2 Finger-Grip Profile Bit
