Klein · SISTEMI Hand Router Tooling
HW Z2 Core Box Router Bit
A Klein G111 HW carbide core box router bit with a 1/2-inch
(12.7 mm) shank, 19 mm cutting diameter, 32 mm cutting length,
70 mm overall length, and 9.5 mm radius. The exact G111.190.R
Item is designed for deep rounded grooves used in decorative
furniture work and grip profiles on compatible large panels.
19 mmCutting Diameter (D)
32 mmCutting Length (B)
R9.5Core Box Radius
1/2 inShank · 12.7 mm
Main Product Description
Klein G111.190.R is the exact 1/2-inch-shank Item in the
E111–G111 family of HW Z2 core box router bits. The official
Item row specifies a 12.7 mm (1/2-inch) shank, 19 mm
cutting diameter, 32 mm cutting length, 70 mm overall
length, and 9.5 mm radius.
Klein describes this family as capable of cutting deeper
rounded flutes than standard core bits. The profile is suited
to compatible decorative furniture work and to recessed grip
features on large panels where a smooth semicircular groove
is required.
Verified workpiece groups include softwood, hardwood, and
chipboard. Official machine guidance lists CNC machining
centres, hand router machines, and router tables. Klein
recommends multiple passes when removing large quantities
of material.
Best Fit Applications
Decorative Furniture Grooves
Large-Panel Grip Profiles
Softwood Routing
Hardwood & Chipboard
CNC, Hand Router & Table
Product Highlights
01
Deep Core Box Profile
Klein specifies the E111–G111 family for deeper rounded flutes
than standard core bits in compatible decorative and grip work.
02
19 mm Diameter · R9.5
The exact G111.190.R Item combines a 19 mm diameter with a
9.5 mm radius, 32 mm cutting length, and 70 mm overall length.
03
HW Carbide Z2 Cutting
Two HW carbide cutting edges support compatible routing in
softwood, hardwood, and chipboard across the listed machine types.
!
Compatibility & Installation Notes
Confirm the exact G111.190.R Item code. This G-series version uses
a 1/2-inch (12.7 mm) shank; the corresponding E111.190.R variant
uses a 12 mm shank. Use a clean compatible collet and verify cutter
clearance, projection, guarding, workholding, feed direction, and
applicable machine and tool speed limits. Use multiple passes when
removing large quantities of material.
Deep Rounded-Groove Routing
Klein G111.190.R combines a 19 mm cutting diameter, 9.5 mm
radius, 32 mm cutting length, 70 mm overall length, Z2 HW
carbide geometry, and a 1/2-inch shank.
Correct shank identification, collet fit, cutter clearance,
guarding, pass depth, workholding, feed direction, and machine
parameters are essential to controlled material removal and
consistent rounded-groove quality.
