HW Z2 90° V-Groove Router Bit
A Klein G110 HW carbide V-groove router bit with a 1/2-inch
(12.7 mm) shank, 19 mm cutting diameter, 16 mm cutting length,
54 mm overall length, and a 90-degree included angle. The exact
G110.190.R Item is designed for deep and shallow V-grooves,
engraving, sign writing, decorative panel details, and compatible
chamfering operations.
19 mmCutting Diameter (D)
16 mmCutting Length (B)
90°Included Angle (α)
1/2 inShank · 12.7 mm
Main Product Description
Klein G110.190.R is the exact 1/2-inch-shank Item in the
E110–G110 family of HW Z2 V-groove router bits. The official
Item row specifies a 12.7 mm (1/2-inch) shank, 19 mm cutting
diameter, 16 mm cutting length, 54 mm overall length, and
90-degree included angle.
The family is designed for both deep and shallow V-grooves
used in sign-making, engraving, decorative features on panels
and furniture, and compatible chamfering operations. Klein
specifically identifies engraving and sign writing among the
intended applications.
Verified workpiece groups include softwood, hardwood, and
chipboard. Official machine guidance lists CNC machining
centres, hand router machines, and router tables. Klein
recommends multiple passes when removing large quantities
of material.
Best Fit Applications
Engraving & Sign Writing
Decorative Panel V-Grooves
Furniture Detail Grooving
Compatible 90° Chamfers
CNC, Hand Router & Table
Product Highlights
01
90° V-Groove Geometry
The exact G110.190.R Item uses a 90-degree included angle for
compatible deep or shallow V-grooves and chamfering work.
02
19 mm Diameter · 16 mm Cut
The verified configuration combines a 19 mm cutting diameter,
16 mm cutting length, and 54 mm overall length.
03
Engraving and Sign Work
Klein identifies the E110–G110 family for engraving, sign writing,
and decorative V-groove features in compatible wood products.
!
Compatibility & Installation Notes
Confirm the exact G110.190.R Item code. This G-series version uses
a 1/2-inch (12.7 mm) shank; the corresponding E110.190.R variant
uses a 12 mm shank. Use a clean compatible collet and verify cutter
clearance, projection, guarding, workholding, feed direction, and
applicable machine and tool speed limits. Use multiple passes when
removing large quantities of material.
Precise 90° V-Groove Routing
Klein G110.190.R combines a 19 mm cutting diameter, 16 mm
cutting length, 54 mm overall length, 90-degree profile, Z2 HW
carbide geometry, and a 1/2-inch shank.
Correct shank identification, collet fit, cutter clearance,
guarding, pass depth, workholding, feed direction, and machine
parameters are essential to controlled material removal and
consistent V-groove quality.
