110 mm diameter · 63 mm flange · 125 mm overall length
Blade Range
Compatible circular saw blades from 200–350 mm diameter
Mounting Pattern
6 × M6x10 countersunk screws · 60° spacing · 90 mm pitch circle
Optional Accessory
Z092.100.N security flange for added stability and larger compatible blades
Klein · SISTEMI CNC Toolholding
HSK63F
Saw Blade Adapter
Circular Saw Blade Adapter
An extended-reach Klein T128 adapter for mounting compatible circular saw blades with a 30 mm bore on HSK63F CNC machining centres. The exact T128.165.R Item provides a 100 mm projection dimension, 110 mm adapter diameter, 63 mm HSK flange diameter, and 125 mm overall length.
HSK63FMachine Interface
100 mmProjection (A)
30 mmSaw Blade Bore (D1)
125 mmOverall Length (L)
Tool Type
Circular Saw Blade Adapter
The T128.165.R is a non-cutting HSK63F adapter designed to carry compatible circular saw blades with a 30 mm bore. Six countersunk M6x10 screws are supplied for the official 60° mounting pattern on a 90 mm pitch circle.
HSK63F30 mm BoreA = 100 mmSKU T128.165.R
System Fit
For compatible CNC machining centres and circular saw blades from 200 to 350 mm diameter. The optional Z092.100.N security flange is recommended when greater stability and concentricity are required and is used for larger compatible blade diameters up to 400 mm.
Main Product Description
Klein T128.165.R is the extended 100 mm projection variant in the T128 family of HSK63 circular saw blade adapters. The official Item row specifies HSK63F, a 100 mm A-dimension, 110 mm adapter diameter, 30 mm saw blade bore interface, 63 mm flange diameter, 2.5 mm B-dimension, and 125 mm overall length.
The adapter is supplied with six M6x10 countersunk screws arranged at 60° on a 90 mm pitch circle for mounting compatible saw blades. The countersunk fixing arrangement supports flush-cutting work as well as compatible mitre and rafter-cutting operations when the machine, blade, guarding, and setup are suitable.
The standard adapter configuration is specified for saw blades from 200 to 350 mm diameter. Klein recommends the optional Z092.100.N security flange when improved stability and concentricity are needed; the flange system supports compatible saw blades up to 400 mm when installed with its dedicated screws.
Technical Specifications
Family T128 · SKU T128.165.R
BrandKlein
Product TypeHSK63F Circular Saw Blade Adapter
SKUT128.165.R
Family / SeriesSISTEMI CNC Toolholding
Family / ReferenceT128
Machine InterfaceHSK63F
Projection / Gauge (A)100 mm
Adapter Diameter (D)110 mm
Saw Blade Bore (D1)30 mm
Flange Diameter (D2)63 mm
Blade Seat (B)2.5 mm
Overall Length (L)125 mm
Additional Verified DetailsIncluded Fasteners: 6 × M6x10 Countersunk Screws · Mounting Pattern: 60° Spacing on 90 mm Pitch Circle · Standard Blade Range: 200–350 mm Diameter · Machine Type: CNC Machining Centres · Optional Security Flange: Z092.100.N · Replacement Screw: Z051.014.R · Demount Device: T139.163.N
Machine / System FitFor compatible CNC machining centres and circular saw blades from 200 to 350 mm diameter. The optional Z092.100.N security flange is recommended when greater stability and concentricity are required and is used for larger compatible blade diameters up to 400 mm.
Application Matrix
Best Fit Applications
HSK63F CNC Sawing Operations
Flush-Cutting Setups
Mitre-Cutting Operations
Rafter-Cutting Operations
200–350 mm Circular Saw Blades
Performance Details
Product Highlights
01
Extended 100 mm Projection
The T128.165.R uses the longer 100 mm A-dimension and a 125 mm overall length for compatible reach-sensitive CNC sawing setups.
02
Six-Screw Countersunk Mounting
Six supplied M6x10 countersunk screws secure compatible 30 mm-bore saw blades on the official 60° pattern at a 90 mm pitch-circle distance.
03
Optional Precision Flange
The compatible Z092.100.N security flange improves stability and reduces vibration when greater concentricity and precision are required.
Before Machining
Compatibility & Installation Notes
Confirm the exact T128.165.R Item code, HSK63F spindle interface, 30 mm blade bore, saw blade diameter, blade mounting-hole pattern, adapter clearance, machine guarding, spindle direction, machine speed limits, and workholding before installation. The standard adapter is specified for 200–350 mm blades. For larger compatible diameters up to 400 mm, use the Z092.100.N security flange and replace the adapter screws with the dedicated flange screws.
Production Outcome
Extended-Reach HSK63F Saw Blade Mounting
Klein T128.165.R combines an HSK63F interface, 100 mm projection, 30 mm saw blade bore, 110 mm adapter diameter, and 125 mm overall length for compatible CNC circular-saw operations.
Correct blade fit, mounting pattern, screw installation, spindle interface, guarding, clearance, machine limits, and optional flange selection are essential to safe, accurate production use.
