Verified Exact Size
Exact Item Code S790.360.03 identifies the 36 × 12 × 1.5 mm insert configuration.
CMT Orange Tools 36x12x1.5mm 4-Edge Carbide Insert for V-Fold MDF
CA$999.99
In stock
SKU
S790.360.03
Product Type
Reversible Carbide Insert
Application
Compatible V-Fold Tooling for MDF
Dimensions
36 × 12 × 1.5 mm
Cutting Edges
4 Reversible Edges
Geometry
35°
Cutting Material
HW-SMG Solid Micrograin Carbide
HW-SMG 4-Edge
Reversible Insert
HW-SMG Reversible Insert
CMT S790.360.03 is a solid-carbide reversible insert sized 36 × 12 × 1.5 mm. Its four cutting edges and 35° geometry support compatible V-fold tooling used for MDF and other correctly specified production applications.
36 mmInsert Length
12 mmInsert Width
1.5 mmInsert Thickness
4 · 35°Edges / Geometry
HW-SMG Reversible Insert
A precision replaceable cutting component made from solid tungsten micrograin carbide. Exact Item Code S790.360.03 identifies the 36 × 12 × 1.5 mm, four-edge, 35° configuration.
CMT Orange ToolsHW-SMG Carbide4 Cutting EdgesSKU S790.360.03
For compatible cutterheads and V-fold tooling specified for a 36 × 12 × 1.5 mm insert with matching 35° geometry. Confirm the tool manufacturer’s insert code, pocket dimensions, seating surfaces, clamping components, and setup requirements.
Main Product Description
CMT S790.360.03 is the exact orderable insert for the verified 36 × 12 × 1.5 mm configuration. The active cutting material is HW-SMG solid micrograin carbide, with four usable cutting edges and 35° cutting geometry.
The reversible four-edge format lets the operator index the insert to a fresh edge when the installed edge reaches its service limit, provided every edge and seating surface remains undamaged and the host tool is approved for this exact component.
This insert is suited to compatible V-fold tooling for MDF where the cutterhead specification calls for S790.360.03 or an exact 36 × 12 × 1.5 mm, four-edge, 35° match. Fit must be confirmed from the host-tool documentation rather than dimensions alone.
Technical Specifications
Reversible Insert · SKU S790.360.03
- CMT Orange Tools
- Reversible Carbide Insert
- S790.360.03
- Replaceable Reversible Inserts
- 36 mm
- 12 mm
- 1.5 mm
- 4
- 35°
- HW-SMG Solid Micrograin Carbide
- Compatible V-Fold Tooling for MDF
- 36 mm
- MDF V-Fold Machining · Compatible V-Groove Tooling · Indexable Cutterheads
- For compatible cutterheads and V-fold tooling specified for a 36 × 12 × 1.5 mm insert with matching 35° geometry. Confirm the tool manufacturer’s insert code, pocket dimensions, seating surfaces, clamping components, and setup requirements.
Best Fit Applications
MDF V-Fold Machining
Compatible V-Groove Tooling
Indexable Cutterheads
Panel Processing
Replaceable-Edge Systems
Product Highlights
Four Usable Edges
The reversible format provides four cutting edges for compatible indexable tooling systems.
HW-SMG Construction
Solid micrograin tungsten carbide provides the verified active cutting material for this component.
Compatibility & Installation Notes
Confirm exact Item Code S790.360.03 against the host-tool parts list. Dimensions alone do not establish interchangeability. Before installation, isolate the machine, clean and inspect the insert pocket and clamping parts, seat the insert correctly, and follow the cutterhead manufacturer’s tightening, indexing, guarding, rotation, and operating-limit instructions.
Four-Edge Carbide Format for Compatible V-Fold Tooling
CMT S790.360.03 combines a 36 × 12 × 1.5 mm format, four usable cutting edges, 35° geometry, and HW-SMG solid-carbide construction.
Reliable results depend on exact component identification, undamaged seating surfaces, correct clamping, and full compliance with the host tool and machine instructions.
