Verified Exact DIM
The official CMT variation row specifies M3.5 × 6 × 8.5 mm for Item Code 990.077.00.
CMT Orange Tools T15 Torx Screw for Insert V-Groove Tooling M3.5x6x8.5mm
CA$999.99
In stock
SKU
990.077.00
Product Type
Insert Retaining Screw
Family / Series
CMT 990.torx Torx Screws
Drive
Torx T15
Official DIM
M3.5 × 6 × 8.5 mm
Approx. Imperial
0.138 × 0.236 × 0.335 inch
Verified Tool Set
CMT 616.000.01
Verified Body
CMT 616.200
Package
Screw Only · Separately Sold
T15 Torx Screw
For Insert Tooling
Insert Retaining Screw
CMT 990.077.00 is the exact T15 Torx replacement screw with official DIM M3.5 × 6 × 8.5 mm—approximately 0.138 × 0.236 × 0.335 inch—for compatible CMT insert-tooling systems, including verified MDF profile and V-groove applications.
M3.5Metric Thread Size
6 × 8.5 mmOfficial DIM
T15Torx Drive
Screw OnlyPackage Configuration
Insert Retaining Screw
A separately sold T15 Torx fastener for compatible CMT replaceable-insert tooling. Exact Item Code selection is essential because similar CMT screws use different threads, lengths, heads, and drive sizes.
CMT Orange ToolsT15 TorxM3.5 × 6 × 8.5 mmSKU 990.077.00
Verified in CMT insert systems including complete MDF decorating set 616.000.01 with body 616.200, and documented V-groove/folding/signmaking insert-tool families. Confirm the exact host-tool spare-parts table before ordering.
Main Product Description
CMT 990.077.00 is the exact T15 Torx replacement screw listed in the official CMT 990.torx spare-parts family. The verified variation row specifies DIM M3.5 × 6 × 8.5 mm, approximately 0.138 × 0.236 × 0.335 inch.
The screw retains compatible replaceable inserts in designated CMT cutter bodies. Official documentation confirms its use with CMT set 616.000.01 and body 616.200, while CMT catalog references also identify it in compatible V-groove, folding, signmaking, and MDF insert-tool systems.
This SKU represents the screw only. The cutter body, carbide insert, T15 key 991.061.00, torque tool, and other components are not included. Select the fastener by exact Item Code and host-tool documentation rather than appearance or nominal thread size alone.
Technical Specifications
Torx Screw · SKU 990.077.00
- CMT Orange Tools
- Insert Retaining Screw
- 990.077.00
- 990.torx — Torx Screws
- Torx T15
- M3.5 × 6 × 8.5 mm
- 0.138 × 0.236 × 0.335 inch
- CMT 616.000.01
- CMT 616.200
- CMT 991.061.00 · T15
- Screw Only
- Separately Sold Spare Part
- Insert V-Groove Tooling · Folding Cutter Systems · MDF Profile Tooling
- Verified in CMT insert systems including complete MDF decorating set 616.000.01 with body 616.200, and documented V-groove/folding/signmaking insert-tool families. Confirm the exact host-tool spare-parts table before ordering.
Best Fit Applications
Insert V-Groove Tooling
Folding Cutter Systems
MDF Profile Tooling
CMT Body 616.200
Insert-Screw Replacement
Product Highlights
T15 Torx Drive
Designed for a compatible T15 driver, including CMT key reference 991.061.00.
Exact Spare Component
Separately sold screw for compatible CMT replaceable-insert cutter systems.
Compatibility & Installation Notes
Confirm Item Code 990.077.00 in the exact host-tool parts list before installation; nominal M3.5 size alone does not establish interchangeability. Isolate the machine, clean and inspect the screw, insert, pocket, and threads, position the insert fully against its seat, and follow the current CMT assembly instructions and specified fastening method. Do not substitute a visually similar screw.
Exact T15 Fastener for Compatible CMT Insert Systems
CMT 990.077.00 provides the verified T15 Torx, M3.5 × 6 × 8.5 mm configuration for designated CMT insert-tooling assemblies.
Reliable retention depends on exact screw selection, clean undamaged threads, correct insert seating, and compliance with the host-tool assembly instructions.
