CMT Super-Duty Flush Trim Router Bit 3/4-Inch Diameter x 1-Inch Cutting Length x 1/2-Inch Shank
HW Z2
Super-Duty Flush Trim Bit
CMT 806.691.11 is the exact 3/4-inch cutting-diameter Super-Duty variant in the 7/8/906 flush-trim family. It combines a 1-inch cutting length, 3-13/32-inch overall length, 1/2-inch shank, two HW carbide cutting edges, right-hand rotation, and a ball-bearing guide for precision laminate trimming and fast template work with excellent finishing.
Main Product Description
CMT 806.691.11 is one exact Item Code within the official 7/8/906 flush-trim-router-bit family. The verified USA and Canada row specifies a 3/4-inch cutting diameter, 1-inch cutting length, 3-13/32-inch overall length, 1/2-inch shank, two cutting edges, HW active cutting material, and right-hand rotation.
CMT positions this family for precision work on laminates and quick template work where excellent finishing is required. The guide bearing follows the reference surface while the Z2 carbide geometry trims the workpiece flush to that profile.
The exact row identifies shield 990.425.00 and bearing 791.004.00. CMT also describes this family for precision laminate and template work with excellent finishing and identifies through-mortise finishing as a suitable application. Correct collet fit, bearing condition, projection, workholding, guarding, feed direction, and machine limits remain essential for controlled routing.
Best Fit Applications
Product Highlights
Verified 3/4-Inch Variant
Exact Item Code 806.691.11 combines a 3/4-inch diameter, 1-inch cutting length, and 1/2-inch shank.
Bearing-Guided Accuracy
Guide bearing 791.004.00 follows the reference surface for controlled flush trimming and template work.
HW Z2 Cutting Geometry
Two carbide cutting edges provide the verified HW Z2 configuration with right-hand rotation.
Compatibility & Installation Notes
Confirm exact Item Code 806.691.11 and a clean compatible 1/2-inch collet. Inspect guide bearing 791.004.00 and shield 990.425.00, then verify cutter clearance, shank engagement, projection, guarding, workholding, feed direction, extraction, and the applicable router and tool speed limits before use. Do not select by the 7/8/906 family heading alone.
Super-Duty Flush Trimming in a Verified 3/4-Inch Format
CMT 806.691.11 combines a 3/4-inch diameter, 1-inch cutting length, 3-13/32-inch overall length, 1/2-inch shank, Z2 HW carbide geometry, right-hand rotation, and a guide bearing.
The verified configuration is built for precision laminate trimming, template work, and through-mortise finishing when matched to a compatible router and controlled setup.
