CMT Orange Tools Solid Carbide Twist Drill 5mm x 28mm Cutting Length x 60mm Overall Length, 120° 2-Tooth, Right-Hand
Solid Carbide Z2
120° Twist Drill
CMT 363.050.11 is the exact 5 mm right-hand variant in the 363.11HWM solid-carbide twist-drill family. It combines a 28 mm cutting length,60 mm overall length,a 5 mm shank matching the drilling diameter,two precision-ground cutting edges at 120°,and two spiral flutes for compatible blind- and through-hole drilling in solid wood,plywood,laminates,and related wood-based materials.
Main Product Description
CMT 363.050.11 is the exact 5 mm right-hand item in the official 363.11HWM solid-carbide twist-drill family. The verified variation row specifies a 5 mm drilling diameter,28 mm cutting length,60 mm overall length,5 mm shank,and RH rotation.
The drill is manufactured from premium HWM solid carbide and uses two precision-ground cutting edges set at a 120° point with two spiral flutes. Its common shank and drilling diameter configuration,S=D,provides a straight 5 mm cylindrical interface for compatible systems.
CMT identifies the family for blind and through holes in solid wood,plywood,laminates,and related wood-based materials. The 363.11HWM drills are intended for compatible drilling-machine chucks or adaptors and are listed for use with CMT Series 364 and 365 items.
Best Fit Applications
Product Highlights
Exact 5 mm RH Variant
Item Code 363.050.11 combines a 5 mm diameter and shank,28 mm cutting length,60 mm overall length,and verified right-hand rotation.
Z2 120° Twist Geometry
Two precision-ground cutting edges at 120° and two spiral flutes support controlled entry and chip evacuation in blind- and through-hole drilling.
Premium Solid-Carbide Construction
The HWM solid-carbide body provides the active cutting material and a common S=D interface for compatible adapter bushings and Series 364–365 systems.
Compatibility & Installation Notes
Confirm exact Item Code 363.050.11,right-hand machine rotation,and a compatible 5 mm adapter-bushing,chuck,or adaptor interface before use. The shank diameter matches the drilling diameter at 5 mm. Verify secure seating,tool projection,spindle clearance,workholding,and the applicable speed limits. The family is listed for use with CMT Series 364 and 365 items. Do not substitute the left-hand 363.050.12 variant.
Long-Life Drilling in a Verified 5 mm RH Format
CMT 363.050.11 combines a 5 mm drilling diameter and shank,28 mm cutting length,60 mm overall length,right-hand rotation,two cutting edges,and a 120° point.
Premium HWM solid carbide,two spiral flutes,and the common S=D interface complete the verified Series 363.11HWM configuration for compatible blind- and through-hole drilling.
