Verified 1-Inch Radius
Exact Item Code 838.992.11 combines a 1-inch radius, 1-5/16-inch cutting length, and 2-1/2-inch diameter.
CMT Orange Tools Roundover Router Bit 2-1/2-Inch Diameter × 1-5/16-Inch Cutting Length × 1-Inch Radius × 1/2-Inch Shank
CA$999.99
In stock
SKU
838.992.11
Product Type
HW Roundover Router Bit with Bearing
Family / Series
CMT 7/8/938 Roundover Router Bits
Radius / Diameter
1-inch radius · 2-1/2-inch cutting diameter
Cutting Length
1-5/16 inches
Shank / Overall
1/2-inch shank · 3-13/64-inch overall length
Geometry
Z2 · Bearing-guided large-radius roundover
Cutting Material
HW carbide-tipped edges · FATIGUE-PROOF® steel body
Machine Requirement
For use on compatible router tables only
Bearing / Service
Bearing 791.003.00 · Shield 990.423.00
1-Inch Radius
Roundover Router Bit
Large-Radius Roundover Bit
CMT 838.992.11 is the exact router-table-only variant in the 7/8/938 roundover family. It combines a 1-inch radius, 1-5/16-inch cutting length, 2-1/2-inch cutting diameter, 3-13/64-inch overall length, 1/2-inch shank, carbide-tipped cutting edges, and a serviceable guide-bearing system for large-radius edge profiling.
1 inProfile Radius (R)
1-5/16 inCutting Length (I)
2-1/2 inCutting Diameter (D)
Table OnlyMachine Requirement
Large-Radius Roundover Bit
A bearing-guided, double-edge carbide-tipped roundover bit built on a FATIGUE-PROOF® steel body. The exact Item Code is 838.992.11; the family/series reference is 7/8/938. CMT marks this 1-inch-radius variant for router-table use only.
CMT Orange ToolsHW Carbide1/2-Inch ShankSKU 838.992.11
Restricted to a compatible router table accepting a 1/2-inch shank and providing suitable fence, guard, workholding, and cutter clearance for the 2-1/2-inch diameter. Confirm bearing condition and all router-table and tool operating limits.
Main Product Description
CMT 838.992.11 is one exact Item Code within the official 7/8/938 roundover-router-bit family. The verified row specifies a 1-inch profile radius, 1-5/16-inch cutting length, 2-1/2-inch cutting diameter, 3-13/64-inch overall length, and 1/2-inch shank.
CMT builds the family with FATIGUE-PROOF® steel bodies and carbide-tipped cutting edges. The bearing-guided geometry forms a clean large-radius edge profile for table and countertop edges, picture frames, furniture components, and compatible drop-leaf profile work.
The official row restricts this large-diameter variant to router-table use only and identifies bearing 791.003.00, bearing shield 990.423.00, screw 990.058.00, and hex key 991.057.00 as its matching service components.
Technical Specifications
Series 7/8/938 · SKU 838.992.11
- CMT Orange Tools
- HW Roundover Router Bit with Bearing
- 838.992.11
- 7/8/938 — Roundover Router Bits
- For Use on Router Tables Only
- 1 inch
- 1-5/16 inches
- 2-1/2 inches
- 3-13/64 inches
- 1/2 inch
- 2
- HW Carbide-Tipped
- Tool Body: FATIGUE-PROOF® Steel · Surface Treatment: CMT Orange Non-Stick Coating · Guide Bearing: 791.003.00 · 1/2-Inch Diameter · Bearing Shield: 990.423.00 · Service Screw: 990.058.00 · Hex Key: 991.057.00
- Restricted to a compatible router table accepting a 1/2-inch shank and providing suitable fence, guard, workholding, and cutter clearance for the 2-1/2-inch diameter. Confirm bearing condition and all router-table and tool operating limits.
Best Fit Applications
Large-Radius Edge Rounding
Table Edge Profiles
Countertop Edge Profiles
Picture Frame Edges
Drop-Leaf Table Profiles
Product Highlights
Router-Table-Only Format
CMT explicitly restricts this large-diameter roundover variant to compatible router-table installations.
Serviceable Bearing System
CMT publishes exact matching codes for the guide bearing, shield, screw, and hex key used with this variant.
Compatibility & Installation Notes
CMT 838.992.11 is for router-table use only; do not use it in a handheld router or select it by the 7/8/938 family heading alone. Confirm a clean compatible 1/2-inch collet, suitable fence and guarding, secure workholding, adequate clearance for the 2-1/2-inch diameter, correct bearing assembly, and all applicable router-table and tool operating limits before use.
Large-Radius Roundover Profiling for Compatible Router Tables
CMT 838.992.11 combines a 1-inch radius, 1-5/16-inch cutting length, 2-1/2-inch diameter, 3-13/64-inch overall length, 1/2-inch shank, and carbide-tipped bearing-guided geometry.
Accurate Item Code selection, router-table compatibility, collet fit, bearing condition, cutter clearance, guarding, workholding, and equipment limits are essential to consistent large-radius edge profiling.
