Exact 1-1/8-Inch OD Variant
Item Code 791.014.00 is the official Series 791 bearing with a 1-1/8-inch outside diameter, 3/16-inch bore, and 8.4 mm width.
CMT Orange Tools Rabbeting-Set Guide Bearing 1-1/8" OD x 3/16" Bore x 8.4mm Wide
CA$999.99
In stock
SKU
791.014.00
Product Type
Shielded guide bearing / rabbeting-set bearing
Family / Series
CMT Series 791 Bearings
Outside Diameter
1-1/8 inches · 28.5 mm
Bore Diameter
3/16 inch · 4.76 mm
Width
8.4 mm
Primary Compatibility
Compatible CMT rabbeting-set assemblies
Verified Sets
Selected CMT 735,835,and 935 rabbeting-set items
Included With Code
Bearing item number includes the specified reducer
Reassembly
Keep the black shield right side up
Series 791
Guide Bearing
Rabbeting Bearing
CMT 791.014.00 is the exact 1-1/8-inch outside-diameter variant in the official Series 791 bearing family. It combines a 3/16-inch bore and 8.4 mm width—equivalent to 28.5 × 4.76 × 8.4 mm—for compatible CMT bearing-guided assemblies. Official CMT rabbeting-set instructions identify it as the 1-1/8-inch bearing option and state that the bearing item number includes the reducer.
1-1/8 inOutside Diameter (D)
3/16 inBore Diameter (B)
8.4 mmBearing Width (P)
28.5 mmMetric Outside Diameter
Rabbeting Bearing
A shielded non-cutting guide bearing for compatible CMT rabbeting and bearing-guided router-bit assemblies. The exact Series 791 row identifies D = 1-1/8 inch, B = 3/16 inch, and P = 8.4 mm.
CMT Orange ToolsNon-Cutting Accessory1-1/8-Inch ODSKU 791.014.00
Use only where the exact parent-tool or set instructions list bearing 791.014.00. Confirm the reducer and mounting hardware are correctly assembled, the bearing turns freely, and the black shield remains right side up before operating the router or router table.
Main Product Description
CMT 791.014.00 is the exact bearing item in the official Series 791 Spare Parts and Accessories family. The North American variation row specifies a 1-1/8-inch outside diameter, 3/16-inch bore, and 8.4 mm width. CMT’s metric table lists the same configuration as 28.5 × 4.76 × 8.4 mm.
Official CMT rabbeting-set instructions identify 791.014.00 as the 1-1/8-inch bearing option used to change the guided cutting relationship and produce the specified rabbet depth on compatible assemblies. The same instructions state that the bearing item number includes the reducer.
Verified CMT rabbeting-set references include imperial items 835.001.11, 835.501.11, and 835.502.11, plus metric items 735.001.11, 935.001.11, 935.501.11, and 935.502.11. The bearing is separately orderable; the parent router bit, complete set, screw, shield, washer, and other hardware are not included unless the selected product package explicitly states otherwise.
Technical Specifications
Series 791 · SKU 791.014.00
- CMT Orange Tools
- Shielded guide bearing / rabbeting-set bearing
- 791.014.00
- 791 — Bearings
- 1-1/8 in · 28.5 mm
- 3/16 in · 4.76 mm
- 8.4 mm
- 28.5 × 4.76 × 8.4 mm
- Non-cutting accessory
- Not applicable
- Not applicable
- Black shield right side up during reassembly
- Primary Compatibility: Compatible CMT rabbeting-set assemblies · Included With Item Number: Reducer included according to official rabbeting-set instructions · Verified Imperial Set References: 835.001.11 · 835.501.11 · 835.502.11 · Verified Metric Set References: 735.001.11 · 935.001.11 · 935.501.11 · 935.502.11 · Official Assembly Reference: CMT Rabbeting Sets installation instructions · Included Components: Bearing and specified reducer only · Excluded Components: Router bit, complete set, screw, shield, washer, and unrelated hardware · Related Hardware: Use only the components specified by the exact parent-set instructions · Dedicated Titan Image: /media/wysiwyg/titan/CMT-Bearing-791.jpg
- Use only where the exact parent-tool or set instructions list bearing 791.014.00. Confirm the reducer and mounting hardware are correctly assembled, the bearing turns freely, and the black shield remains right side up before operating the router or router table.
Best Fit Applications
CMT Rabbeting Sets
Variable Rabbet-Depth Setup
Bearing-Guided Routing
Replacement & Service Use
Routers & Router Tables
Product Highlights
Verified Rabbeting-Set Component
Official CMT instructions list this bearing with compatible 735, 835, and 935 rabbeting-set items and identify it as the 1-1/8-inch bearing option.
Reducer Included by Item Number
CMT’s assembly instructions state that the bearing item number includes the reducer; the complete router bit, set, and unrelated fastening hardware remain separate.
Compatibility & Installation Notes
Confirm exact Item Code 791.014.00 and dimensions 1-1/8 × 3/16 × 8.4 mm before installation. Use only on a compatible CMT assembly or rabbeting set that explicitly lists this bearing. Follow the official assembly drawing for reducer, shield, washer, and screw placement; never allow retaining hardware to contact the bearing’s rotating outer ring. Inspect for roughness, play, shield damage, contamination, or binding, and replace damaged components. Reassemble with the black shield right side up and confirm free bearing rotation before use.
Verified 1-1/8-Inch Bearing Option for CMT Rabbeting Sets
CMT 791.014.00 combines a 1-1/8-inch outside diameter, 3/16-inch bore, and 8.4 mm width in the official Series 791 replacement-bearing format.
Verified rabbeting-set compatibility, the included-reducer statement, and CMT’s official black-shield orientation guidance complete the service-accessory record.
