Verified 15-Degree Geometry
Exact Item Code 809.016.11 combines a 15-degree angle, 47/64-inch diameter, 7/16-inch cutting length, and 1/4-inch shank.
CMT Orange Tools Non-Blocking Combination Trim Router Bit 15-Degree x 47/64-Inch Diameter x 7/16-Inch Cutting Length x 1/4-Inch Shank
CA$999.99
In stock
SKU
809.016.11
Product Type
HW Non-Blocking Combination Trim Router Bit
Family / Series
CMT 7/809.016 Non-Blocking Combination Trimmer Bits
Cutting Angle
15 degrees
Cutting Diameter
47/64 inch
Cutting Length
7/16 inch
Shank / Overall
1/4-inch shank · 2-1/4-inch overall length
Geometry / Material
Z2 · Right-hand rotation · HW carbide
Guide System
Delrin® bearing 791.044.00 · Shield 990.422.00
Applications
Laminate,template work,softwood,and hardwood finishing
HW Z2
Non-Blocking Combination Trim Bit
HW Non-Blocking Trimmer
CMT 809.016.11 is the exact 15-degree imperial-shank variant in the 7/809.016 non-blocking combination-trimmer family. It combines a 47/64-inch cutting diameter, 7/16-inch cutting length, 2-1/4-inch overall length, 1/4-inch shank, two HW carbide cutting edges, right-hand rotation, and a Delrin® guide bearing.
15°Cutting Angle (A)
47/64 inCutting Diameter (D)
7/16 inCutting Length (I)
1/4 inShank Diameter (S)
HW Non-Blocking Trimmer
A 15-degree bearing-guided combination trimmer for laminate, template, softwood, and hardwood edge finishing, with two HW carbide cutting edges and right-hand rotation. The exact Item Code is 809.016.11; the family/series reference is 7/809.016.
CMT Orange ToolsHW Carbide15-Degree Geometry1/4-Inch Shank
For compatible routers accepting a 1/4-inch shank. The exact official row identifies shield 990.422.00, screw 990.058.00, hex key 991.057.00, and Delrin® bearing 791.044.00. This cutting tool is intended for trained adult or professional operators using properly guarded compatible equipment.
Main Product Description
CMT 809.016.11 is the exact imperial-shank Item Code within the official 7/809.016 non-blocking combination-trimmer-bit family. The verified USA and Canada row specifies a 15-degree cutting angle, 47/64-inch cutting diameter, 7/16-inch cutting length, 2-1/4-inch overall length, 1/4-inch shank, two cutting edges, HW active cutting material, and right-hand rotation.
CMT positions this combination flush-and-bevel family for precision laminate finishing, template-guided edge work, and finishing in both softwood and hardwood. The Z2 carbide geometry supports smooth edge quality, while the bearing-guided configuration protects the reference surface.
The exact row identifies shield 990.422.00, screw 990.058.00, hex key 991.057.00, and Delrin® bearing 791.044.00. The non-blocking guide system and fixed 15-degree geometry are key identifiers separating this tool from the nearby 7/8/909, 7/910, and 7/8/921 combination-trimmer families.
Technical Specifications
Series 7/809.016 · SKU 809.016.11
- CMT Orange Tools
- HW Non-Blocking Combination Trim Router Bit
- 809.016.11
- 7/809.016 — Non-Blocking Combination Trimmer Bits
- 15 degrees
- 47/64 inch
- 7/16 inch
- 2-1/4 inches
- 1/4 inch
- 2
- HW Carbide
- Right-Hand (RH)
- Shield for Bearing: 990.422.00 · Bearing Screw: 990.058.00 · Hex Key: 991.057.00 · Guide Bearing: 791.044.00 · Delrin® · Verified Applications: Laminate, Template Work, Softwood, Hardwood
- For compatible routers accepting a 1/4-inch shank. The exact official row identifies shield 990.422.00, screw 990.058.00, hex key 991.057.00, and Delrin® bearing 791.044.00. This cutting tool is intended for trained adult or professional operators using properly guarded compatible equipment.
Best Fit Applications
Laminate Flush Trimming
Laminate Bevel Finishing
Template-Guided Edge Work
Softwood Edge Finishing
Hardwood Edge Finishing
Product Highlights
Non-Blocking Delrin® Guide
The exact row pairs the combination cutter with Delrin® bearing 791.044.00 and shield 990.422.00.
HW Z2 Combination Trimmer
Two HW carbide cutting edges provide the verified Z2 configuration for precision laminate, template, softwood, and hardwood finishing.
Compatibility & Installation Notes
This cutting tool is intended for trained adult or professional shop personnel using compatible, properly guarded machinery. Confirm exact Item Code 809.016.11, 1/4-inch shank compatibility, Delrin® bearing 791.044.00, shield 990.422.00, screw 990.058.00, and hex key 991.057.00 against the machine and CMT documentation. Do not select by a nearby combination-trimmer family heading alone.
Verified 15-Degree Combination Trimming with a Non-Blocking Guide
CMT 809.016.11 combines a 15-degree cutting angle, 47/64-inch diameter, 7/16-inch cutting length, 2-1/4-inch overall length, 1/4-inch shank, Z2 HW carbide geometry, right-hand rotation, and a Delrin® guide bearing.
The verified configuration supports precision combination trimming for laminate, template work, softwood, and hardwood while remaining clearly identified by its 15-degree geometry and non-blocking bearing.
