3/4-Inch Mortising Diameter
The exact 801.690.11 row specifies a 3/4-inch (19.05 mm) cutting diameter with a 3/4-inch cutting length.
CMT Orange Tools Mortise Bit D3/4 x CL3/4
CA$999.99
In stock
SKU
801.690.11
Product Type
HW mortising router bit
Family / Series
CMT 7/8/901 Mortising Bits
Cutting Diameter
3/4 inch · 19.05 mm
Cutting Length
3/4 inch · 20.05 mm
Overall / Shank
2-1/8-inch overall · 1/4-inch shank
Geometry
Z2 HW carbide · negative shear · right-hand rotation
Configuration
Standard non-B item · no bearing code published
Applications
Hinge mortising,recess cutting,and jig-guided routing
Workpiece Materials
Natural wood and wood composites
HW Z2 Mortising Router Bit
3/4-Inch Diameter
T2 Mortising Bit
CMT 801.690.11 is a right-hand T2 mortising bit with a 3/4-inch (19.05 mm) cutting diameter, 3/4-inch cutting length, 1/2-inch shank, and 2-1/4-inch overall length for clean mortising in natural wood and wood composites.
3/4 inCutting Diameter
3/4 inCutting Length
1/2 inShank Diameter
2-1/4 inOverall Length
T2 Mortising Bit
Thick tungsten-carbide tips and a negative-shear design are specified for clean hinge mortising with reduced splintering and rough-bottom defects.
CMT Orange ToolsTungsten Carbide TipsT2 · RHSKU 801.690.11
For compatible routers and mortising jigs using a 1/2-inch shank; verify collet fit, right-hand rotation, workholding, depth, clearance, feed, and spindle speed before use.
Main Product Description
CMT 801.690.11 belongs to the CMT 801 mortising-bit family for traditional hinge installation and other controlled mortising operations in natural wood and wood composites.
The family uses thick tungsten-carbide tips and negative-shear cutting geometry intended to support clean edges and smooth mortise bottoms when the cutter, jig, router, and workholding are correctly matched.
The exact 801.690.11 configuration uses a 3/4-inch cutting diameter, 3/4-inch cutting length, 1/2-inch shank, and 2-1/4-inch overall length with T2 right-hand geometry.
Technical Specifications
Mortising Bit · SKU 801.690.11
- CMT Orange Tools
- Tungsten-Carbide-Tipped Mortising Router Bit
- 801.690.11
- 801 — Mortising Bits
- 3/4 in · 19.05 mm
- 3/4 in
- 1/2 in
- 2-1/4 in
- T2
- Right-Hand (RH)
- Negative Shear
- Natural Wood and Wood Composites
- Primary Use: Traditional Hinge Mortising · Compatible Setup: Most Mortising Jigs; compatible 1/2-inch router/toolholder interface
- For compatible routers and mortising jigs using a 1/2-inch shank; verify collet fit, right-hand rotation, workholding, depth, clearance, feed, and spindle speed before use.
Best Fit Applications
Traditional Hinge Mortising
Natural Wood Mortising
Wood-Composite Mortising
Mortising-Jig Operations
Controlled Recess & Pocket Work
Product Highlights
1/2-Inch Shank Configuration
This item is the 1/2-inch-shank version with a 2-1/4-inch overall length.
T2 Negative-Shear Cutting
CMT specifies thick tungsten-carbide tips and negative-shear geometry for clean mortising in wood and wood composites.
Compatibility & Installation Notes
Confirm exact SKU 801.690.11, a compatible 1/2-inch collet or toolholder, and right-hand rotation before use. Verify jig compatibility, workholding, cutting depth, cutter projection, spindle clearance, feed, speed, and extraction for the machine and workpiece.
Clean Mortising in the Exact 801.690.11 Configuration
CMT 801.690.11 combines a 3/4-inch cutting diameter and cutting length with a 1/2-inch shank and 2-1/4-inch overall length.
Its T2 right-hand, tungsten-carbide-tipped, negative-shear geometry is intended for controlled mortising in natural wood and wood composites when correctly matched to the router and jig.
