2-1/2-Inch Cutting Length
Exact Item Code 812.629.11 pairs its verified long cutting edge with a 4-3/8-inch overall length.
CMT Orange Tools Long-Series Straight Router Bit 1/2-Inch Diameter x 2-1/2-Inch Cutting Length x 4-3/8-Inch Overall Length x 1/2-Inch Shank, 2 Flutes
CA$999.99
In stock
SKU
812.629.11
Product Type
Long-Series Straight Router Bit
Family / Series
CMT 7/8/912 Long Series
Cutting Diameter
1/2 inch · 12.7 mm
Cutting Length
2-1/2 inches · 63.5 mm
Shank / Overall
1/2-inch shank · 4-3/8-inch overall length
Geometry
Z2 · Right-hand rotation
Cutting Material
HW micrograin carbide
Supported Materials
Natural wood,plywood,and composite panels
Applications
Straight grooves,dados,rabbets,mortises,and joinery
HW Z2
Long-Series Straight Router Bit
Straight Router Bit
CMT 812.629.11 is the exact 1/2-inch-diameter variant in the 7/8/912 long-series straight-router-bit family. It combines a 2-1/2-inch cutting length, 4-3/8-inch overall length, 1/2-inch shank, two HW carbide cutting edges, and right-hand rotation for straight-sided routing profiles in compatible natural wood, plywood, and composite materials.
1/2 inCutting Diameter (D)
2-1/2 inCutting Length (I)
4-3/8 inOverall Length (L)
Z2 · RHCutting Geometry
Straight Router Bit
A long-series, double-cutting-edge straight router bit with HW carbide active cutting edges. The exact Item Code is 812.629.11; the official family reference is 7/8/912.
CMT Orange ToolsHW Carbide1/2-Inch ShankSKU 812.629.11
For compatible routing equipment accepting a 1/2-inch shank and providing the clearances required for the verified 4-3/8-inch overall length. Match the exact Item Code and complete dimensions rather than selecting by family or diameter alone.
Main Product Description
CMT 812.629.11 is one exact Item Code within the official 7/8/912 long-series straight-router-bit family. The verified row specifies a 1/2-inch cutting diameter, 2-1/2-inch cutting length, 4-3/8-inch overall length, 1/2-inch shank, two cutting edges, HW active cutting material, and right-hand rotation.
CMT builds the family with special Fatigue Proof steel and micrograin carbide cutting edges. The long-series design is supported by the family's exceptional chip-ejection geometry, orange non-stick PTFE surface protection, and quality controls for cutting tolerance, balance, and concentricity.
The current CMT catalogue corroborates the exact variant at 12.7 mm cutting diameter, 63.5 mm cutting length, 111 mm overall length, and 12.7 mm shank diameter. CMT identifies the family for industrial-scale routing in plywood, composite panels, and natural wood.
Technical Specifications
Series 7/8/912 · SKU 812.629.11
- CMT Orange Tools
- Long-Series Straight Router Bit
- 812.629.11
- 7/8/912 — Straight Router Bits, Long Series
- 1/2 inch · 12.7 mm
- 2-1/2 inches · 63.5 mm
- 4-3/8 inches · 111 mm
- 1/2 inch · 12.7 mm
- 2
- HW Micrograin Carbide
- Fatigue Proof Steel
- Orange Non-Stick PTFE
- Rotation: Right-Hand (RH) · Supported Materials: Natural Wood, Plywood, Composites · Verified Profile Uses: Straight Grooves, Dados, Rabbets, Joinery
- For compatible routing equipment accepting a 1/2-inch shank and providing the clearances required for the verified 4-3/8-inch overall length. Match the exact Item Code and complete dimensions rather than selecting by family or diameter alone.
Best Fit Applications
Straight-Sided Grooves
Dados & Rabbets
Mortise Components
Tongue-and-Groove Joinery
Plywood & Composite Routing
Product Highlights
HW Z2 Straight Geometry
Two micrograin carbide cutting edges provide the verified straight profile with right-hand rotation.
Industrial Long-Series Construction
Fatigue Proof steel, orange PTFE protection, and controlled balance and concentricity support the official 7/8/912 family.
Compatibility & Selection Notes
Confirm exact Item Code 812.629.11, a compatible 1/2-inch collet, and adequate clearance for the verified 4-3/8-inch overall length. The unusually long cutting edge must be considered when matching machine capacity, guarding, workholding, and the intended material. Setup and operation should follow CMT documentation and the machine manufacturer's safety requirements under qualified supervision.
Long-Series Straight Routing in a Verified 1/2-Inch Diameter
CMT 812.629.11 combines a 1/2-inch cutting diameter, 2-1/2-inch cutting length, 4-3/8-inch overall length, 1/2-inch shank, Z2 HW carbide geometry, and right-hand rotation.
Its long-series construction supports straight profiles in compatible natural wood, plywood, and composite applications.
