CMT HW Pattern Router Bit with Top Bearing, 3/4 in D x 1-1/2 in CL, 1/2 in Shank
HW Z2
Pattern Router Bit
CMT 812.690.11B is the exact 3/4-inch cutting-diameter variant in the 7/8/912B long-series pattern-router-bit family. It combines a 1-1/2-inch cutting length, 3-1/4-inch overall length, 1/2-inch shank, two carbide-tipped cutting edges, and a top-mounted bearing for template-guided pattern work.
Main Product Description
CMT 812.690.11B is one exact Item Code within the official 7/8/912B pattern-router-bit long series. The verified product row specifies a 3/4-inch cutting diameter, 1-1/2-inch cutting length, 3-1/4-inch overall length, and 1/2-inch shank.
CMT describes this family as double-fluted and carbide tipped. A bearing positioned above the cutting section supports top-template pattern routing while keeping the template and bearing reference visible during professional production work.
Official family guidance identifies cabinet and furniture pieces, signs, toys, and other template-generated projects. Final machine compatibility, tooling condition, workholding, guarding, and operating limits remain subject to the current CMT and equipment-manufacturer documentation.
Best Fit Applications
Product Highlights
Verified 3/4-Inch Variant
Exact Item Code 812.690.11B combines a 3/4-inch diameter, 1-1/2-inch cutting length, and 1/2-inch shank.
HW Double-Flute Geometry
Two carbide-tipped cutting edges provide the verified double-flute configuration for long-series pattern work.
Top-Bearing Pattern Format
The bearing is positioned above the cutting section for professional template-guided routing with the template on top.
Compatibility & Installation Notes
Industrial router tooling must be selected, installed, inspected, and operated only by qualified adults following current CMT and machine-manufacturer documentation, facility safety procedures, guarding, PPE, and dust-control requirements. Confirm exact Item Code 812.690.11B and system compatibility through authoritative documentation; this product page is identification information, not an operating instruction.
Long-Series Pattern Routing in a Verified 3/4-Inch Format
CMT 812.690.11B combines a 3/4-inch cutting diameter, 1-1/2-inch cutting length, 3-1/4-inch overall length, 1/2-inch shank, HW double-flute geometry, and a top bearing.
The exact Item Code and published dimensions provide a clear basis for catalog identification and compatibility review within the CMT 7/8/912B long-series pattern-bit family.
