Exact 3/4-Inch OD Variant
Item Code 791.004.00 is the official Series 791 bearing with a 3/4-inch outside diameter, 1/4-inch bore, and 7 mm width.
CMT Orange Tools Guide Bearing 3/4" OD x 1/4" Bore x 7mm Wide
CA$999.99
In stock
SKU
791.004.00
Product Type
Shielded guide bearing / router-bit bearing
Family / Series
CMT Series 791 Bearings
Outside Diameter
3/4 inch · 19 mm
Bore Diameter
1/4 inch · 6.35 mm
Width
7 mm
Compatibility
Selected CMT bearing-guided router-bit assemblies
Verified Families
Flush-trim,roundover,profile,bowl-and-tray,dado,mortising,and plunge-ogee bits
Reassembly
Keep the black shield right side up
Included Component
Bearing only · related hardware varies by parent tool
Series 791
Guide Bearing
791 — Bearings
CMT 791.004.00 is the exact 3/4-inch outside-diameter variant in the official Series 791 bearing family. It combines a 1/4-inch bore and 7 mm width—equivalent to 19 × 6.35 × 7 mm—for compatible CMT bearing-guided router-bit assemblies. This separately orderable non-cutting accessory supports guided profile, flush-trim, roundover, bowl-and-tray, mortising, dado, and related routing systems where the exact parent-tool row specifies bearing 791.004.00.
3/4 inOutside Diameter (D)
1/4 inBore Diameter (B)
7 mmBearing Width (P)
19 mmMetric Outside Diameter
Guide Bearing
A shielded non-cutting guide bearing for compatible CMT router-bit assemblies. The official Series 791 row identifies D = 3/4 inch, B = 1/4 inch, and P = 7 mm.
CMT Orange ToolsNon-Cutting Accessory3/4-Inch ODSKU 791.004.00
Use only where the exact parent-tool row lists bearing 791.004.00. Confirm the 1/4-inch mounting interface, correct shield and fastening hardware, free rotation, secure seating, and black-shield orientation before operating the router or router table.
Main Product Description
CMT 791.004.00 is the exact bearing item in the official Series 791 Spare Parts and Accessories family. The North American variation row specifies a 3/4-inch outside diameter, 1/4-inch bore, and 7 mm width. CMT’s metric table lists the same configuration as 19 × 6.35 × 7 mm.
The bearing functions as a guide, profile-control, or flush-trim component on compatible CMT router-bit assemblies. Verified official references include selected Series 7/8/906 flush-trim bits, 7/8/938 roundover bits, 7/8/914B round-nose bits, 7/8/965B classical-bead bits, 7/851B bowl-and-tray bits, 852B dado and planer bits, 7/8/901B mortising bits, and 7/8/948B plunge-ogee bits.
The bearing is separately orderable and does not automatically include the parent router bit, shield, screw, stop collar, spacer, or hex key. Related hardware changes by tool family and exact item row. CMT’s Series 791 safety guidance requires the black shield to remain right side up during reassembly so it corresponds with bearing rotation.
Technical Specifications
Series 791 · SKU 791.004.00
- CMT Orange Tools
- Shielded guide bearing / router-bit bearing
- 791.004.00
- 791 — Bearings
- 3/4 in · 19 mm
- 1/4 in · 6.35 mm
- 7 mm
- 19 × 6.35 × 7 mm
- Non-cutting accessory
- Not applicable
- Not applicable
- Black shield right side up during reassembly
- Primary Compatibility: Selected CMT bearing-guided router-bit assemblies · Verified Flush-Trim References: 806.690.11 · 806.691.11 · 806.692.11 · 806.191.11 · Verified Double-Bearing References: 806.690.11B · 806.691.11B · Verified Roundover References: 838.993.11 · 838.994.11 · Verified Profile References: 814.190.11B · 865.201.11B · 865.301.11B · Additional Verified References: 851.002.11B · 852.001.11B · 801.190.11B · 848.190.11B · 848.191.11B · Included Components: Bearing only · Related Hardware: Varies by exact parent-tool row; not included unless explicitly stated · Dedicated Titan Image: /media/wysiwyg/titan/CMT-Bearing-791.jpg
- Use only where the exact parent-tool row lists bearing 791.004.00. Confirm the 1/4-inch mounting interface, correct shield and fastening hardware, free rotation, secure seating, and black-shield orientation before operating the router or router table.
Best Fit Applications
Flush-Trim Router Bits
Roundover & Profile Bits
Bowl, Tray & Dado Bits
Mortising & Plunge-Ogee Bits
Replacement & Service Use
Product Highlights
Broad Verified CMT Compatibility
Official CMT tables reference this bearing across selected flush-trim, roundover, round-nose, classical-bead, bowl-and-tray, dado, mortising, and plunge-ogee tools.
Official Reassembly Guidance
CMT specifies keeping the black shield right side up during reassembly so the shield orientation corresponds correctly with bearing rotation.
Compatibility & Installation Notes
Confirm exact Item Code 791.004.00 and dimensions 3/4 × 1/4 × 7 mm before installation. Use only on a compatible CMT assembly that explicitly lists this bearing. Inspect the bearing for roughness, play, shield damage, contamination, or binding; replace damaged components. Reassemble with the black shield right side up, use the exact shield, screw, stop collar, spacer, or key specified by the parent-tool row, and confirm free bearing rotation before use. The router bit and related fastening hardware are not included.
Verified 3/4-Inch Guide-Bearing Fit for Compatible CMT Tools
CMT 791.004.00 combines a 3/4-inch outside diameter, 1/4-inch bore, and 7 mm width in the official Series 791 replacement-bearing format.
Verified use across multiple CMT router-bit families and the official black-shield orientation requirement complete the service-accessory record.
