Verified 1/2-Inch Variant
Exact Item Code 806.629.11 combines a 1/2-inch diameter, 1-1/2-inch cutting length, and 1/2-inch shank.
CMT Orange Tools Flush Trim Router Bit 1/2-Inch Diameter x 1-1/2-Inch Cutting Length x 1/2-Inch Shank
CA$999.99
In stock
SKU
806.629.11
Product Type
HW Flush Trim Router Bit
Family / Series
CMT 7/8/906 Flush Trim Router Bits
Cutting Diameter
1/2 inch
Cutting Length
1-1/2 inches
Shank / Overall
1/2-inch shank · 3-11/16-inch overall length
Geometry
Z2 · Right-hand rotation
Cutting Material
HW carbide
Guide System
Shield 990.423.00 · Bearing 791.003.00
Applications
Laminate trimming,template work,and through-mortise finishing
HW Z2
Flush Trim Router Bit
HW Flush Trim Bit
CMT 806.629.11 is the exact 1/2-inch cutting-diameter variant in the 7/8/906 flush-trim family. It combines a 1-1/2-inch cutting length, 3-11/16-inch overall length, 1/2-inch shank, two HW carbide cutting edges, right-hand rotation, and a ball-bearing guide for precision laminate trimming and fast template work with excellent finishing.
1/2 inCutting Diameter (D)
1-1/2 inCutting Length (I)
1/2 inShank Diameter (S)
Z2 · RHCutting Geometry
HW Flush Trim Bit
A bearing-guided industrial flush trim router bit with two HW carbide cutting edges and verified right-hand rotation. The exact Item Code is 806.629.11; the family/series reference is 7/8/906.
CMT Orange ToolsHW Carbide1/2-Inch ShankSKU 806.629.11
For compatible routers accepting a 1/2-inch shank. The exact official row identifies shield 990.423.00 and guide bearing 791.003.00; confirm collet condition, projection, cutter clearance, guarding, workholding, and operating limits.
Main Product Description
CMT 806.629.11 is one exact Item Code within the official 7/8/906 flush-trim-router-bit family. The verified USA and Canada row specifies a 1/2-inch cutting diameter, 1-1/2-inch cutting length, 3-11/16-inch overall length, 1/2-inch shank, two cutting edges, HW active cutting material, and right-hand rotation.
CMT positions this family for precision work on laminates and quick template work where excellent finishing is required. The guide bearing follows the reference surface while the Z2 carbide geometry trims the workpiece flush to that profile.
The exact row identifies shield 990.423.00 and bearing 791.003.00. CMT also identifies undersized bearing 791.063.00 at 12.5 mm as the replacement for the standard 12.7 mm bearing after resharpening. Correct collet fit, bearing condition, projection, workholding, guarding, feed direction, and machine limits remain essential for controlled routing.
Technical Specifications
Series 7/8/906 · SKU 806.629.11
- CMT Orange Tools
- HW Flush Trim Router Bit
- 806.629.11
- 7/8/906 — Flush Trim Router Bits
- 1/2 inch
- 1-1/2 inches
- 3-11/16 inches
- 1/2 inch
- 2
- HW Carbide
- Right-Hand (RH)
- 990.423.00
- Guide Bearing: 791.003.00 · 12.7 mm · After-Resharpening Bearing: 791.063.00 · 12.5 mm · Verified Applications: Laminate Trimming, Template Work, Through-Mortise Finishing
- For compatible routers accepting a 1/2-inch shank. The exact official row identifies shield 990.423.00 and guide bearing 791.003.00; confirm collet condition, projection, cutter clearance, guarding, workholding, and operating limits.
Best Fit Applications
Laminate Flush Trimming
Template-Guided Routing
Flush Edge Finishing
Through-Mortise Finishing
Compatible 1/2-Inch Routers
Product Highlights
Bearing-Guided Accuracy
Guide bearing 791.003.00 follows the reference surface for controlled flush trimming and template work.
HW Z2 Cutting Geometry
Two carbide cutting edges provide the verified HW Z2 configuration with right-hand rotation.
Compatibility & Installation Notes
Confirm exact Item Code 806.629.11 and a clean compatible 1/2-inch collet. Inspect guide bearing 791.003.00 and shield 990.423.00, then verify cutter clearance, shank engagement, projection, guarding, workholding, feed direction, extraction, and the applicable router and tool speed limits before use. Do not select by the 7/8/906 family heading alone.
Precision Flush Trimming in a Verified 1/2-Inch Format
CMT 806.629.11 combines a 1/2-inch diameter, 1-1/2-inch cutting length, 3-11/16-inch overall length, 1/2-inch shank, Z2 HW carbide geometry, right-hand rotation, and a guide bearing.
The verified configuration is built for precision laminate trimming, fast template work, and bearing-guided finishing when matched to a compatible router and controlled setup.
