Verified 1/16-Inch Radius
Exact Item Code 807.015.11 combines a 1/2-inch diameter, 3/8-inch cutting length, 1/16-inch radius, and 1/4-inch shank.
CMT Orange Tools File-Free Flush Trim Router Bit for Laminates 1/2-Inch Diameter x 3/8-Inch Cutting Length x 1/16-Inch Radius x 1/4-Inch Shank
CA$999.99
In stock
SKU
807.015.11
Product Type
HW File-Free Flush Trim Router Bit for Laminates
Family / Series
CMT 8/907 File-Free Flush Trim Router Bits
Cutting Diameter
1/2 inch
Cutting Length
3/8 inch
Edge Radius
1/16 inch
Shank / Overall
1/4-inch shank · 2-1/16-inch overall length
Geometry / Material
Z2 · Right-hand rotation · HW carbide
Guide System
Bearing 791.002.00 · Shield 990.422.00
Application
File-free finishing of flush-trimmed laminate edges
HW Z2
File-Free Flush Trim Bit
HW File-Free Bit
CMT 807.015.11 is the exact 1/16-inch-radius variant in the 8/907 File-Free flush-trim family for laminates. It combines a 1/2-inch cutting diameter, 3/8-inch cutting length, 2-1/16-inch overall length, 1/4-inch shank, two HW carbide cutting edges, right-hand rotation, and a ball-bearing guide for smooth laminate edge finishing.
1/2 inCutting Diameter (D)
3/8 inCutting Length (I)
1/16 inEdge Radius (R)
1/4 inShank Diameter (S)
HW File-Free Bit
A bearing-guided File-Free flush trim router bit for laminate edge finishing, with a 1/16-inch radius, two HW carbide cutting edges, and right-hand rotation. The exact Item Code is 807.015.11; the family/series reference is 8/907.
CMT Orange ToolsHW Carbide1/4-Inch ShankSKU 807.015.11
For compatible routers accepting a 1/4-inch shank. The exact official row identifies shield 990.422.00, screw 990.058.00, hex key 991.057.00, and guide bearing 791.002.00; confirm collet condition, projection, cutter clearance, guarding, workholding, and operating limits.
Main Product Description
CMT 807.015.11 is one exact Item Code within the official 8/907 File-Free flush-trim-router-bit family for laminates. The verified USA and Canada row specifies a 1/2-inch cutting diameter, 3/8-inch cutting length, 1/16-inch radius, 2-1/16-inch overall length, 1/4-inch shank, two cutting edges, HW active cutting material, and right-hand rotation.
CMT designed this family to remove the sharp edge left on a laminate surface after flush trimming. The small verified radius smooths the edge to the touch, while the guide bearing follows the reference surface and the Z2 carbide geometry produces the finished profile without further filing.
The exact row identifies shield 990.422.00, screw 990.058.00, hex key 991.057.00, and bearing 791.002.00 at 9.5 mm. CMT specifies undersized bearing 791.062.00 at 9.3 mm as the replacement after resharpening. Correct collet fit, bearing condition, projection, workholding, guarding, feed direction, and machine limits remain essential for controlled routing.
Technical Specifications
Series 8/907 · SKU 807.015.11
- CMT Orange Tools
- HW File-Free Flush Trim Router Bit for Laminates
- 807.015.11
- 8/907 — File-Free Flush Trim Router Bits for Laminates
- 1/2 inch
- 3/8 inch
- 1/16 inch
- 2-1/16 inches
- 1/4 inch
- 2
- HW Carbide
- Right-Hand (RH)
- Shield for Bearing: 990.422.00 · Bearing Screw: 990.058.00 · Hex Key: 991.057.00 · Guide Bearing: 791.002.00 · 9.5 mm · After-Resharpening Bearing: 791.062.00 · 9.3 mm · Verified Application: File-Free Laminate Edge Finishing
- For compatible routers accepting a 1/4-inch shank. The exact official row identifies shield 990.422.00, screw 990.058.00, hex key 991.057.00, and guide bearing 791.002.00; confirm collet condition, projection, cutter clearance, guarding, workholding, and operating limits.
Best Fit Applications
Post-Flush Laminate Finishing
Sharp-Edge Removal
Smooth Laminate Edges
Cabinet-Shop Laminate Work
Compatible 1/4-Inch Routers
Product Highlights
File-Free Laminate Finish
The small-radius profile removes sharp laminate edges after flush trimming and leaves a smooth finish without further filing.
HW Z2 Bearing-Guided System
Two HW carbide cutting edges and bearing 791.002.00 provide the verified Z2 configuration with right-hand rotation.
Compatibility & Installation Notes
Confirm exact Item Code 807.015.11 and a clean compatible 1/4-inch collet. Inspect guide bearing 791.002.00, shield 990.422.00, screw 990.058.00, and hex key 991.057.00, then verify cutter clearance, shank engagement, projection, guarding, workholding, feed direction, extraction, and the applicable router and tool speed limits before use. After resharpening, use the CMT-specified 791.062.00 undersized bearing. Do not select by the 8/907 family heading alone.
File-Free Laminate Finishing with a Verified 1/16-Inch Radius
CMT 807.015.11 combines a 1/2-inch diameter, 3/8-inch cutting length, 1/16-inch radius, 2-1/16-inch overall length, 1/4-inch shank, Z2 HW carbide geometry, right-hand rotation, and a guide bearing.
The verified configuration is built to remove sharp edges after laminate flush trimming and leave a smooth-to-the-touch finish without further filing when matched to a compatible router and controlled setup.
