Exact M16×2 Variant
Item Code 796.162.00 is the official Series 796ER20 chuck with an M16×2 mounting thread, 43 mm body length, and 2–12.7 mm ER20 capacity.
CMT Orange Tools ER20 Collet Chuck for Shapers, M16x2 Thread, 43mm Length, 2–12.7mm Range
CA$999.99
In stock
SKU
796.162.00
Product Type
ER20 collet chuck for shapers / spindle moulders
Family / Series
CMT 796ER20 Chucks
Mounting Thread
M16×2
Body Length
43 mm
Collet Capacity
2–12.7 mm
Construction
High-strength steel · precision-machined mating surfaces
Compatible Collets
CMT Series 184 ER20 precision collets
Included Component
ER20 chuck body only · collet not included
Service Components
Nut 992.483.03 · wrench 991.483.00 · TW-200 recommended
M16×2
ER20 Collet Chuck
ER20 Chuck
CMT 796.162.00 is the exact M16×2-thread variant in the Series 796 ER20 chuck family for shapers and spindle moulders. It provides a verified 43 mm body length and supports ER20 collets covering 2–12.7 mm. The chuck is made from high-strength steel and precision machined for accurate tool holding. The ER20 collet is not included.
M16×2Mounting Thread (S)
ER20Collet System
43 mmBody Length (LB)
2–12.7 mmCollet Capacity (B)
ER20 Chuck
A precision-machined, high-strength steel chuck body for ER20 collets. The exact Item Code is 796.162.00; the family reference is 796ER20. This product is the chuck body, not an individual ER20 collet.
CMT Orange ToolsER20 SystemM16×2 ThreadSKU 796.162.00
For compatible shaper or spindle-moulder interfaces using an M16×2 mounting thread. Select the correct Series 184 ER20 collet for the router-bit shank, confirm full thread engagement, clean mating surfaces, correct nut assembly, and secure tool seating.
Main Product Description
CMT 796.162.00 is the exact M16×2 version in the official Series 796 ER20 chuck family. The verified variation row specifies mounting thread S = M16×2, body length LB = 43 mm, and ER20 clamping range B = 2–12.7 mm.
CMT manufactures the chuck from high-strength steel and precision machines the mating surfaces for accuracy. The family is intended for shaper and spindle-moulder applications that accept the matching threaded interface. The chuck converts the compatible machine spindle connection to an ER20 collet-holding system.
The ER20 collet is not included. CMT Series 184 precision ER20 collets are listed for Series 796.122, 796.142, and 796.162 chucks in sizes from 2 mm through 12.7 mm. Official catalog references also identify clamping nut 992.483.03, ER20 wrench 991.483.00, and the TW-200 torque wrench recommendation for proper nut fastening.
Technical Specifications
Series 796ER20 · SKU 796.162.00
- CMT Orange Tools
- ER20 collet chuck for shapers / spindle moulders
- 796.162.00
- 796ER20 — ER20 chucks
- M16×2
- 43 mm
- 2–12.7 mm
- ER20
- High-strength steel
- Precision-machined mating surfaces
- Non-cutting toolholding accessory
- Not applicable
- Collet Included: No · Compatible Collet Family: CMT Series 184 ER20 precision collets · Available Collet Sizes: 2 · 3 · 4 · 5 · 6 · 6.35 · 7 · 8 · 9 · 10 · 11 · 12 · 12.7 mm · Related Clamping Nut: 992.483.03 · M25×1.5 · Related ER20 Wrench: 991.483.00 · Recommended Torque Tool: TW-200 torque wrench · Machine Type: Compatible shapers / spindle moulders · Included Component: ER20 chuck body only · Excluded Components: ER20 collet, router bit, machine spindle, and unrelated tooling · Dedicated Titan Image: /media/wysiwyg/titan/CMT-ER20-Chuck-796.jpg
- For compatible shaper or spindle-moulder interfaces using an M16×2 mounting thread. Select the correct Series 184 ER20 collet for the router-bit shank, confirm full thread engagement, clean mating surfaces, correct nut assembly, and secure tool seating.
Best Fit Applications
Shapers & Spindle Moulders
ER20 Router-Bit Holding
2–12.7 mm Tool Shanks
Toolholding Conversion
Replacement & Service Use
Product Highlights
High-Strength Precision Body
CMT specifies high-strength steel construction and precision-machined mating surfaces for accurate, repeatable toolholding.
Modular ER20 System
The chuck accepts separately ordered Series 184 ER20 collets and uses the related ER20 nut and wrench system; the collet is not included.
Compatibility & Installation Notes
Confirm exact Item Code 796.162.00, an M16×2 machine interface, and a compatible shaper or spindle-moulder spindle before installation. Select the exact ER20 collet for the router-bit shank; the collet is not included. Clean all threads, tapers, nut, and collet contact surfaces, confirm full thread engagement, and seat the collet in the nut correctly before inserting the tool. Use the official CMT nut and wrench components and follow the TW-200 fastening recommendation. Do not exceed the machine, spindle, collet, or cutting tool manufacturer's speed and projection limits.
Verified M16×2 ER20 Toolholding for Compatible Shapers
CMT 796.162.00 combines an M16×2 mounting thread, 43 mm body length, and 2–12.7 mm ER20 collet range in the official Series 796 precision-chuck format.
High-strength steel construction, precision-machined mating surfaces, separately selected Series 184 collets, and verified ER20 service components complete the system.
