Verified 1/4-Inch Radius
Exact Item Code 837.222.11 combines a 1/4-inch radius, 1/2-inch cutting length, and 1-inch diameter in the current official variation table.
CMT Orange Tools Cove Router Bit 1-Inch Diameter × 1/2-Inch Cutting Length × 1/4-Inch Radius × 1/4-Inch Shank
CA$999.99
In stock
SKU
837.222.11
Product Type
HW Cove Router Bit with Bearing
Family / Series
CMT 7/8/937 Cove Router Bits
Radius / Diameter
1/4-inch radius · 1-inch cutting diameter
Cutting Length
1/2 inch
Shank / Overall
1/4-inch shank · 2-5/32-inch overall length
Geometry
Z2 · Right-hand rotation
Cutting Material
HW carbide-tipped cutting edges
Profile Guidance
Bearing-guided cove profile
Service Parts
Bearing 791.003.00 · Shield 990.423.00
1/4-Inch Radius
Cove Router Bit
Bearing-Guided Cove Bit
CMT 837.222.11 is the exact 1/4-inch-radius variant in the 7/8/937 cove-router-bit family. The current official row combines a 1/2-inch cutting length, 1-inch cutting diameter, 2-5/32-inch overall length, 1/4-inch shank, Z2 HW carbide cutting material, right-hand rotation, and a serviceable guide-bearing system for decorative cove profiles in compatible woodworking.
1/4 inProfile Radius (R)
1/2 inCutting Length (I)
1 inCutting Diameter (D)
1/4 inShank Diameter (S)
Bearing-Guided Cove Bit
A bearing-guided Z2 HW cove router bit with verified right-hand rotation. The exact Item Code is 837.222.11; the family/series reference is 7/8/937. Its 1/4-inch radius creates the concave profile used for decorative furniture, door, and drawer-front details.
CMT Orange ToolsHW Carbide1/4-Inch ShankSKU 837.222.11
For compatible routing equipment accepting a 1/4-inch shank and providing suitable guarding, workholding, bearing clearance, and cutter clearance for the 1-inch diameter. Confirm collet condition and all machine and tool operating limits.
Main Product Description
CMT 837.222.11 is one exact Item Code within the official 7/8/937 cove-router-bit family. The current verified row specifies a 1/4-inch profile radius, 1/2-inch cutting length, 1-inch cutting diameter, 2-5/32-inch overall length, 1/4-inch shank, two cutting edges, and RH rotation.
CMT positions this cove-bit family for refined finishing on furniture, doors, and drawer fronts. The bearing-guided concave geometry adds a simple or more decorative cove detail, while the verified HW Z2 configuration identifies two carbide cutting edges and right-hand rotation for this exact variant.
The official row identifies bearing 791.003.00, bearing shield 990.423.00, screw 990.058.00, and hex key 991.057.00 as the matching service components. Correct Item Code selection, collet fit, bearing condition, cutter clearance, guarding, workholding, and equipment limits remain essential for compatible equipment.
Technical Specifications
Series 7/8/937 · SKU 837.222.11
- CMT Orange Tools
- HW Cove Router Bit with Bearing
- 837.222.11
- 7/8/937 — Cove Router Bits
- 1/4 inch
- 1/2 inch
- 1 inch
- 2-5/32 inches
- 1/4 inch
- 2
- HW Carbide-Tipped
- Right-Hand (RH)
- Profile Guidance: Bearing-Guided · Guide Bearing: 791.003.00 · 1/2-Inch Diameter · Bearing Shield: 990.423.00 · Service Screw: 990.058.00 · Hex Key: 991.057.00
- For compatible routing equipment accepting a 1/4-inch shank and providing suitable guarding, workholding, bearing clearance, and cutter clearance for the 1-inch diameter. Confirm collet condition and all machine and tool operating limits.
Best Fit Applications
Decorative Cove Profiles
Furniture Edge Details
Door Edge Profiles
Drawer-Front Accents
Refined Rounded Details
Product Highlights
HW Z2 Cove Geometry
Two carbide cutting edges, right-hand rotation, and bearing guidance define the verified cove configuration for this variant.
Serviceable Bearing System
CMT publishes exact matching codes for the guide bearing, shield, screw, and hex key used with this variant.
Compatibility & Installation Notes
Confirm exact Item Code 837.222.11 and a clean compatible 1/4-inch collet; do not select by the 7/8/937 family heading alone. Verify correct bearing assembly, adequate clearance for the 1-inch cutting diameter, suitable guarding and workholding, and all applicable router and tool operating limits before use.
Decorative Cove Profiling in a Verified 1/4-Inch Format
CMT 837.222.11 combines a 1/4-inch radius, 1/2-inch cutting length, 1-inch diameter, 2-5/32-inch overall length, 1/4-inch shank, Z2 HW cutting edges, RH rotation, and bearing-guided cove geometry.
Accurate Item Code selection, collet fit, bearing condition, cutter clearance, guarding, workholding, and equipment limits are essential to consistent edge profiling.
