3/8-Inch Guided Profile
The 3/8-inch cutter diameter and matched 3/8-inch guide bearing support accurate flush trimming and template duplication.
CMT Orange Tools Bearing-Guided Flush Trim Router Bit 3/8" Diameter x 1" Cut, 1/4" Shank
CA$999.99
In stock
SKU
806.095.11
Product Type
HW bearing-guided flush trim router bit
Family / Series
CMT 7/8/906 Flush Trim Bits
Cutting Diameter
3/8 inch · 9.53 mm
Cutting Length
1 inch · 25.4 mm
Overall / Shank
2-11/16-inch overall · 1/4-inch shank
Geometry
Z2 HW carbide · right-hand rotation
Guide Bearing
CMT 791.002.00 · 3/8-inch outside diameter
Bearing Shield
CMT 990.422.00
Applications
Laminate trimming,template routing,edge duplication,and through-mortise finishing
HW Z2
Flush Trim Router Bit
Flush Trim Bit
CMT 806.095.11 is the exact 3/8-inch cutting-diameter variant in the Series 7/8/906 flush-trim family. It combines a 1-inch cutting length, 2-11/16-inch overall length, 1/4-inch shank, two HW carbide cutting edges, right-hand rotation, shield 990.422.00, and bearing 791.002.00 for precision laminate trimming, template routing, edge duplication, and through-mortise finishing.
3/8 inCutting Diameter (D)
1 inCutting Length (I)
1/4 inShank Diameter (S)
Z2 · HW · RHCutting Geometry
Flush Trim Bit
A bearing-guided flush-trim router bit with two HW carbide cutting edges. The exact Item Code is 806.095.11; the family reference is 7/8/906.
CMT Orange ToolsHW CarbideBearing GuidedSKU 806.095.11
For compatible routers accepting a 1/4-inch shank. Confirm collet condition, bearing 791.002.00 rotation, shield 990.422.00 seating, cutter projection, template support, guarding, and correct feed direction before use.
Main Product Description
CMT 806.095.11 is the exact imperial variant in the official 7/8/906 Flush Trim Router Bits family. The North American row specifies I = 1 inch, D = 3/8 inch, L = 2-11/16 inches, S = 1/4 inch, Z = 2, MAT = HW, and RH rotation.
The worldwide metric table confirms the same configuration as a 25.4 mm cutting length, 9.53 mm cutting diameter, 68.2 mm overall length, and 6.35 mm shank. CMT positions the family for precision laminate work and fast template-guided routing with a clean finished edge.
The exact variation row identifies shield 990.422.00 and bearing 791.002.00. The bearing measures 3/8 inch outside diameter, 3/16 inch bore, and 3.2 mm width. CMT also recommends this family for completing through mortises by following a previously established groove from the opposite face of the workpiece.
Technical Specifications
Series 7/8/906 · SKU 806.095.11
- CMT Orange Tools
- Bearing-guided flush trim router bit
- 806.095.11
- 7/8/906 — Flush trim router bits
- 3/8 in · 9.53 mm
- 1 in · 25.4 mm
- 2-11/16 in · 68.2 mm
- 1/4 in · 6.35 mm
- 2
- HW carbide
- Right hand
- Ball-bearing guided
- Published Bearing: 791.002.00 · Bearing Outside Diameter: 3/8 in · 9.5 mm · Bearing Bore: 3/16 in · 4.76 mm · Bearing Width: 3.2 mm · Published Bearing Shield: 990.422.00 · Primary Applications: Flush trimming · laminate finishing · template routing · Additional Verified Use: Completing through mortises from the opposite face · Workpiece Materials: Laminates · natural wood · Machine Fit: Compatible routers accepting a 1/4-inch shank · Material Image Route: /media/wysiwyg/titan/Titan-SolidCarbide.jpg
- For compatible routers accepting a 1/4-inch shank. Confirm collet condition, bearing 791.002.00 rotation, shield 990.422.00 seating, cutter projection, template support, guarding, and correct feed direction before use.
Best Fit Applications
Laminate Flush Trimming
Template-Guided Routing
Edge Duplication
Through-Mortise Finishing
Natural Wood
Product Highlights
Verified HW Z2 Geometry
Two HW carbide cutting edges and right-hand rotation provide the exact cutting configuration published for Item Code 806.095.11.
Published Service Components
CMT identifies shield 990.422.00 and bearing 791.002.00 for this exact flush-trim bit.
Compatibility & Installation Notes
Use CMT 806.095.11 only in a compatible router with a clean, undamaged 1/4-inch collet. Inspect bearing 791.002.00 for free rotation, play, contamination, and damage, and confirm shield 990.422.00 is correctly seated. The bearing must contact the intended template or finished reference surface without forcing the cutter sideways. Secure the workpiece and template, verify cutter and bearing clearance, feed against cutter rotation, and use controlled passes appropriate to the material and cut depth. Follow the router and tool manufacturers' speed, projection, guarding, and workholding limits.
3/8-Inch Bearing-Guided Flush Trimming with HW Carbide
CMT 806.095.11 combines a 3/8-inch cutting diameter, 1-inch cutting length, 1/4-inch shank, Z2 HW carbide geometry, and right-hand rotation.
The verified 791.002.00 bearing, 990.422.00 shield, and Series 7/8/906 application range complete the setup for laminate, template, and flush-trim work.
