Compact 1/4-Inch Cutting Diameter
The 1/4-inch diameter and 1-inch cutting length support detailed flush trimming, template work, and narrow-profile routing.
CMT Orange Tools Bearing-Guided Flush Trim Router Bit 1/4" Diameter x 1" Cut, 1/4" Shank
CA$999.99
In stock
SKU
806.064.11
Product Type
HWM bearing-guided flush trim router bit
Family / Series
CMT 7/8/906 Flush Trim Bits
Cutting Diameter
1/4 inch · 6.35 mm
Cutting Length
1 inch · 25.4 mm
Overall / Shank
2-1/2-inch overall · 1/4-inch shank
Geometry
Z2 HWM carbide · right-hand rotation
Guide Bearing
CMT 791.035.00 · 1/4-inch outside diameter
Applications
Laminate trimming,template routing,and edge duplication
Additional Use
Completing through mortises from the opposite face
HWM Z2
Flush Trim Router Bit
Flush Trim Bit
CMT 806.064.11 is the exact 1/4-inch cutting-diameter variant in the Series 7/8/906 flush-trim family. It combines a 1-inch cutting length, 2-1/2-inch overall length, 1/4-inch shank, two HWM carbide cutting edges, right-hand rotation, and a published 791.035.00 bearing guide for precision laminate trimming, template work, edge duplication, and through-mortise finishing.
1/4 inCutting Diameter (D)
1 inCutting Length (I)
1/4 inShank Diameter (S)
Z2 · HWM · RHCutting Geometry
Flush Trim Bit
A compact bearing-guided flush-trim router bit with HWM carbide cutting edges. The exact Item Code is 806.064.11; the family reference is 7/8/906.
CMT Orange ToolsHWM CarbideBearing GuidedSKU 806.064.11
For compatible routers accepting a 1/4-inch shank. Confirm collet condition, bearing 791.035.00 rotation, cutter projection, template or workpiece support, clearance, guarding, and correct feed direction before use.
Main Product Description
CMT 806.064.11 is the exact imperial variant in the official 7/8/906 Flush Trim Router Bits family. The North American row specifies I = 1 inch, D = 1/4 inch, L = 2-1/2 inches, S = 1/4 inch, Z = 2, MAT = HWM, and RH rotation.
The worldwide metric table confirms the same configuration as a 25.4 mm cutting length, 6.35 mm cutting diameter, 63.5 mm overall length, and 6.35 mm shank. CMT positions the family for precision laminate work and fast template-guided routing with a clean finished edge.
The exact variation row identifies bearing 791.035.00 as the guide component. CMT also recommends this flush-trim family for completing through mortises by following a previously established groove from the opposite side of the workpiece. The bearing, cutter, collet, template, and workpiece must remain correctly aligned throughout the operation.
Technical Specifications
Series 7/8/906 · SKU 806.064.11
- CMT Orange Tools
- Bearing-guided flush trim router bit
- 806.064.11
- 7/8/906 — Flush trim router bits
- 1/4 in · 6.35 mm
- 1 in · 25.4 mm
- 2-1/2 in · 63.5 mm
- 1/4 in · 6.35 mm
- 2
- HWM carbide
- Right hand
- Ball-bearing guided
- Published Bearing: 791.035.00 · Bearing Outside Diameter: 1/4 in · 6.35 mm · Bearing Bore: 1/8 in · 3.17 mm · Bearing Width: 2.8 mm · Primary Applications: Flush trimming · laminate finishing · template routing · Additional Verified Use: Completing through mortises from the opposite face · Workpiece Materials: Laminates · natural wood · Machine Fit: Compatible routers accepting a 1/4-inch shank · Material Image Route: /media/wysiwyg/titan/Titan-SolidCarbide.jpg
- For compatible routers accepting a 1/4-inch shank. Confirm collet condition, bearing 791.035.00 rotation, cutter projection, template or workpiece support, clearance, guarding, and correct feed direction before use.
Best Fit Applications
Laminate Flush Trimming
Template-Guided Routing
Edge Duplication
Through-Mortise Finishing
Natural Wood
Product Highlights
Verified HWM Z2 Geometry
Two HWM carbide cutting edges and right-hand rotation provide the exact cutting configuration published for Item Code 806.064.11.
Matched Bearing Guide
CMT identifies bearing 791.035.00 for this exact item, maintaining the published 1/4-inch guide diameter for flush-trim control.
Compatibility & Installation Notes
Use CMT 806.064.11 only in a compatible router with a clean, undamaged 1/4-inch collet. Inspect bearing 791.035.00 for free rotation, play, contamination, and damage before each use. Confirm the bearing contacts the intended template or finished reference surface without forcing the cutter sideways. Secure the workpiece and template, verify cutter and bearing clearance, feed against cutter rotation, and use multiple controlled passes when the material or cut depth requires it. Follow the router and tool manufacturers' speed, projection, guarding, and workholding limits.
Compact Bearing-Guided Flush Trimming with HWM Carbide
CMT 806.064.11 combines a 1/4-inch cutting diameter, 1-inch cutting length, 1/4-inch shank, Z2 HWM carbide geometry, and right-hand rotation.
The verified 791.035.00 guide bearing and Series 7/8/906 application range complete the setup for laminate finishing, template routing, and flush-trim work.
