Two Coordinated Radii
The assembly combines a verified 1/8-inch outer radius with a 5/64-inch inner radius for a double roundover panel profile.
CMT Orange Tools Adjustable Double Roundover Router Bit, 1-11/32" Diameter, R1/8" & R5/64", 1/2" Shank
CA$999.99
In stock
SKU
800.622.11
Product Type
HW adjustable double roundover router bit
Family / Series
CMT 8/900.622
Tool Diameter
1-11/32 inches · approximately 34 mm
Stock Range
7/16–1-1/4 inches · 11.1–31.8 mm
Roundover Radii
1/8 inch outer · 5/64 inch inner
Overall / Shank
3-15/16-inch overall · 1/2-inch shank
Geometry
HW Z2 · right-hand rotation · bearing guided
Adjustment
Interchangeable precision shims included
Machine Use
Table-mounted routers only · not for hand-held use
HW Z2
Adjustable Double Roundover Bit
Double Roundover
CMT 800.622.11 is the exact 1-11/32-inch diameter variant in the 8/900.622 adjustable double roundover family. It combines a 7/16- to 1-1/4-inch adjustable stock-thickness range, 1/8-inch outer radius, 5/64-inch inner radius, 3-15/16-inch overall length, 1/2-inch shank, two HW carbide cutting edges, and right-hand rotation. Interchangeable shims support multiple board thicknesses on table-mounted routers.
1-11/32 inTool Diameter (D)
7/16–1-1/4 inStock Range (T)
R1/8 · R5/64Double Roundover Profile
1/2 in · Z2 RHShank & Geometry
Double Roundover
An adjustable, bearing-guided HW carbide router-bit assembly that produces two coordinated roundover profiles on opposite panel edges. The exact Item Code is 800.622.11; the family reference is 8/900.622.
CMT Orange ToolsHW Carbide1/2-Inch ShankSKU 800.622.11
For table-mounted routers accepting a 1/2-inch shank. CMT expressly advises against use in hand-held routers. Assemble the cutters, bearing, spacers, shields, arbor, and M8 nut only in the sequences shown in the official instructions.
Main Product Description
CMT 800.622.11 is the exact imperial variant in the official 8/900.622 Adjustable Double Roundover Router Bits family. The verified row specifies D = 1-11/32 inches, T = 7/16 to 1-1/4 inches, R = 1/8 inch, L = 3-15/16 inches, S = 1/2 inch, and R1 = 5/64 inch.
The paired cutter assembly creates a double roundover treatment on wood panels. CMT identifies the profiles as 3 mm (1/8 inch) and 2 mm (5/64 inch), while interchangeable shims allow the assembly spacing to be adjusted for different board thicknesses. The official instructions cover examples from 11.1 mm (7/16 inch) through 31.75 mm (1-1/4 inches).
The 2026 CMT router-bit catalog identifies the family as HW Z2 RH. The official assembly drawing lists profile cutters 822.031.11 and 822.032.11, 1/2-inch arbor 824.137.00, bearing 791.037.00, M8 nut 990.020.00, assembly shields, and multiple precision spacers. The tool is intended for table-mounted routers and must not be used in hand-held power tools.
Technical Specifications
Series 8/900.622 · SKU 800.622.11
- CMT Orange Tools
- Adjustable double roundover router bit
- 800.622.11
- 8/900.622 — Adjustable double roundover router bits
- 1-11/32 in · approximately 34 mm
- 7/16–1-1/4 in · 11.1–31.8 mm
- 1/8 in · 3 mm
- 5/64 in · 2 mm
- 3-15/16 in · approximately 100 mm
- 1/2 in · 12.7 mm
- HW Z2 · right-hand rotation
- HW carbide
- Guiding System: Ball-bearing guided assembly · Machine Type: Table-mounted router · Hand-Held Router Use: Not permitted by CMT · Adjustment Method: Interchangeable precision shims · Profile Cutter: 822.031.11 · Profile Cutter: 822.032.11 · Arbor: 824.137.00 · 1/2-inch shank · Bearing: 791.037.00 · Ø8–28 mm · H9 mm per assembly drawing · Retaining Nut: 990.020.00 · M8 · Assembly Shield: 541.500.00 · Assembly Shield: 541.501.00 · Spacer: 541.515.00 · 0.1 mm · Spacer: 541.516.00 · 0.3 mm · Spacer: 541.517.00 · 0.5 mm · Spacer: 541.518.00 · 1.0 mm · Spacer: 541.519.00 · 5.8 mm · Included Adjustment Feature: Interchangeable shims · Material Image Route: /media/wysiwyg/titan/Titan-SolidCarbide.jpg
- For table-mounted routers accepting a 1/2-inch shank. CMT expressly advises against use in hand-held routers. Assemble the cutters, bearing, spacers, shields, arbor, and M8 nut only in the sequences shown in the official instructions.
Best Fit Applications
Double-Edge Panel Rounding
Furniture Components
Decorative Wood Panels
7/16–1-1/4-Inch Stock
Table-Mounted Routers
Product Highlights
Adjustable Stock Capacity
Interchangeable shims configure the cutter spacing for material from 7/16 inch through 1-1/4 inches thick.
Complete Service Architecture
CMT publishes the exact cutters, arbor, bearing, shields, spacers, and M8 retaining nut used in the official assembly sequence.
Compatibility & Installation Notes
Use CMT 800.622.11 only in a table-mounted router with a sound 1/2-inch collet; CMT specifically advises against hand-held router use. Select the official assembly sequence for the required 2 mm or 3 mm profile and board thickness. Keep cutters, spacers, bearing, shields, arbor shoulder, and M8 nut clean and seated flat. Confirm that the bearing turns freely, the workpiece is fully supported, the fence and guards are correctly positioned, and the cutter clears the table and surrounding hardware. Follow the router and tool manufacturers' speed, feed, and projection limits.
Adjustable Double Roundover Production in One Guided Assembly
CMT 800.622.11 combines two HW carbide profile cutters, bearing guidance, a 1/2-inch shank, and shim-based adjustment for 7/16- to 1-1/4-inch panels.
The verified 1/8-inch and 5/64-inch radii, published service components, and table-router-only requirement define the complete operating envelope.
