CMT 90° V-Grooving Router Bit 1/2-Inch Diameter x 1/2-Inch Cutting Length x 1/4-Inch Shank, 2 Cutting Edges
HW Z2 90°
V-Grooving Router Bit
CMT 815.127.11 is the exact 1/2-inch cutting-diameter variant in the 7/8/915 family of 90° V-grooving router bits. It combines a 1/2-inch cutting length, 1/4-inch tip depth, 1-3/4-inch overall length, 1/4-inch shank, two HW carbide cutting edges, and right-hand rotation for clean V-grooves, 45° chamfers, and lettering in compatible panels and drawer-front work.
Main Product Description
CMT 815.127.11 is one exact Item Code within the official 7/8/915 family of 90° V-grooving router bits. The verified row specifies a 1/2-inch cutting diameter, 1/2-inch cutting length, 1/4-inch tip depth, 1-3/4-inch overall length, 1/4-inch shank, two cutting edges, HW active cutting material, and right-hand rotation.
CMT describes the family as double-cutting-edge tooling for clean cuts in panels and drawer fronts, as well as chamfering and lettering. The 90° included angle creates a V groove and also allows the same profile to produce a 45° edge chamfer.
The 2026 CMT router-bit catalog corroborates the exact variant at 12.7 mm cutting diameter, 12.7 mm cutting length, 6.35 mm tip depth, 44.5 mm overall length, and 6.35 mm shank. Correct machine compatibility, collet fit, guarding, workholding, and cutter clearance remain essential.
Best Fit Applications
Product Highlights
Verified 1/2-Inch Variant
Exact Item Code 815.127.11 combines a 1/2-inch diameter, 1/2-inch cutting length, and 1/4-inch shank.
90° HW Z2 Geometry
Two HW carbide cutting edges form the verified 90° V profile with right-hand rotation.
Two Operations in One Profile
The 90° V geometry supports both V-grooving and accurate 45° edge chamfering with the same cutter profile.
Compatibility & Installation Notes
Confirm exact Item Code 815.127.11 and routing equipment with a compatible 1/4-inch collet. Verify machine compatibility, cutter clearance, shank engagement, guarding, workholding, and the applicable machine and tool limits before operation. Do not select by the 7/8/915 family heading alone; confirm the exact 1/2-inch cutting-diameter row and all associated dimensions.
Clean 90° V-Grooving in a Verified 1/2-Inch Format
CMT 815.127.11 combines a 1/2-inch diameter, 1/2-inch cutting length, 1/4-inch tip depth, 1-3/4-inch overall length, 1/4-inch shank, Z2 HW carbide geometry, and right-hand rotation.
Its 90° profile supports clean V-grooves, lettering, and 45° chamfers in compatible panel and drawer-front routing work.
