Verified 45-Degree Variant
Exact Item Code 836.280.11 combines a 45-degree angle, 3/8-inch cutting length, and 1-1/4-inch diameter in the current official variation table.
CMT Orange Tools 45° Chamfer Router Bit, 1-1/4" D x 3/8" Cut, 1/4" Shank
CA$999.99
In stock
SKU
836.280.11
Product Type
Carbide-Tipped Chamfer Router Bit with Bearing
Family / Series
CMT 7/8/936
Chamfer Angle
45 degrees
Cutting Diameter
1-1/4 inches
Cutting Length
3/8 inch
Shank / Overall
1/4-inch shank · 2-3/32-inch overall length
Cutting Material
Carbide-Tipped
Bearing System
Bearing-Guided · Guide Bearing 791.003.00
Applications
Chamfers,bevel profiles,decorative edges,boxes,beams,and columns
45-Degree
Chamfer Router Bit
Bearing-Guided Chamfer Bit
CMT 836.280.11 is the exact 45-degree variant in the 7/8/936 chamfer-router-bit family. The current official row combines a 3/8-inch cutting length, 1-1/4-inch cutting diameter, 2-3/32-inch overall length, 1/4-inch shank, carbide-tipped cutting edges, and a serviceable guide-bearing system for clean bevels, chamfers, decorative edgework, boxes, beams, and columns.
45°Chamfer Angle (A)
3/8 inCutting Length (I)
1-1/4 inCutting Diameter (D)
1/4 inShank Diameter (S)
Bearing-Guided Chamfer Bit
A bearing-guided carbide-tipped chamfer router bit for clean, accurate bevels and decorative edge profiles. The exact Item Code is 836.280.11; the family/series reference is 7/8/936. This variant carries the verified 45-degree geometry.
CMT Orange ToolsCarbide-Tipped1/4-Inch ShankSKU 836.280.11
For compatible routing equipment accepting a 1/4-inch shank and providing suitable guarding, workholding, bearing clearance, and cutter clearance for the 1-1/4-inch diameter. Confirm collet condition and all machine and tool operating limits.
Main Product Description
CMT 836.280.11 is one exact Item Code within the official 7/8/936 chamfer-router-bit family. The current verified row specifies a 45-degree chamfer angle, 3/8-inch cutting length, 1-1/4-inch cutting diameter, 2-3/32-inch overall length, and 1/4-inch shank.
CMT positions this chamfer-bit family for clean bevels and chamfers, edge work, accurately aligned multi-sided containers, boxes, and decorative projects. The published family guidance also covers larger-scale work such as beams and columns.
The official row identifies bearing 791.003.00, bearing shield 990.423.00, screw 990.058.00, and hex key 991.057.00 as the matching service components. Correct Item Code selection, collet fit, bearing condition, cutter clearance, guarding, workholding, and equipment limits remain essential for compatible equipment.
Technical Specifications
Series 7/8/936 · SKU 836.280.11
- CMT Orange Tools
- Carbide-Tipped Chamfer Router Bit with Bearing
- 836.280.11
- 7/8/936 — Chamfer Router Bits
- 45 degrees
- 3/8 inch
- 1-1/4 inches
- 2-3/32 inches
- 1/4 inch
- Carbide-Tipped
- Bearing-Guided
- 791.003.00 · 1/2-Inch Diameter
- Bearing Shield: 990.423.00 · Service Screw: 990.058.00 · Hex Key: 991.057.00
- For compatible routing equipment accepting a 1/4-inch shank and providing suitable guarding, workholding, bearing clearance, and cutter clearance for the 1-1/4-inch diameter. Confirm collet condition and all machine and tool operating limits.
Best Fit Applications
Edge Chamfering
Clean Bevel Profiles
Multi-Sided Boxes
Decorative Edgework
Beams and Columns
Product Highlights
Carbide Chamfer Geometry
Carbide-tipped cutting edges and bearing guidance support the clean bevel and chamfer profiles specified for this family.
Serviceable Bearing System
CMT publishes exact matching codes for the guide bearing, shield, screw, and hex key used with this variant.
Compatibility & Installation Notes
Confirm exact Item Code 836.280.11 and a clean compatible 1/4-inch collet; do not select by the 7/8/936 family heading alone. Verify correct bearing assembly, adequate clearance for the 1-1/4-inch cutting diameter, suitable guarding and workholding, and all applicable router and tool operating limits before use.
Clean Chamfer and Bevel Profiling in a Verified 45-Degree Format
CMT 836.280.11 combines a 45-degree chamfer angle, 3/8-inch cutting length, 1-1/4-inch diameter, 2-3/32-inch overall length, 1/4-inch shank, carbide-tipped cutting edges, and bearing-guided chamfer geometry.
Accurate Item Code selection, collet fit, bearing condition, cutter clearance, guarding, workholding, and equipment limits are essential to consistent edge profiling.
