Exact 1-1/4-Inch Bore Variant
Item Code 694.002.31 combines a 5-29/32-inch diameter, 1-1/4-inch bore, Z2 geometry, and a verified 5,100–8,800 RPM operating range.
CMT Orange Tools 45° Chamfer Insert Cutter Head 5-29/32" Diameter x 1-1/4" Bore, 2-Tooth
CA$999.99
In stock
SKU
694.002.31
Product Type
45° chamfer insert cutter head
Family / Series
CMT 694.002 Chamfer Cutter Heads
Diameter
5-29/32 inches · 150 mm
Bore
1-1/4 inches · 31.75 mm
Geometry
45° profile · Z2 reversible HWM carbide inserts
Insert Size
50 × 12 × 1.5 mm
Operating Speed
5,100–8,800 RPM · manual feed
Applications
Bevels,chamfers,joints,solid wood,veneer,plywood,and laminates
Machine Fit
Compatible spindle moulders,double-end tenoners,and shapers
45° Chamfer
Insert Cutter Head
45° Cutter Head
CMT 694.002.31 is the exact 1-1/4-inch-bore variant in the Series 694.002 45° chamfer cutter-head family. It combines a 5-29/32-inch cutting diameter, 1-1/4-inch bore, two HWM carbide cutting inserts, a 5,100–8,800 RPM operating range, manual-feed classification, and automatic insert-positioning pins for clean bevels, chamfers, joints, and edge work on compatible industrial machines.
5-29/32 inCutting Diameter (D)
1-1/4 inBore Diameter (B)
Z2 · 45°Insert Geometry
5100–8800Operating RPM
45° Cutter Head
A manual-feed industrial chamfer cutter head with a hard aluminium-alloy body, two reversible HWM carbide cutting inserts measuring 50 × 12 × 1.5 mm, automatic positioning pins, and verified Z2 geometry.
CMT Orange ToolsHWM Carbide Inserts1-1/4-Inch BoreSKU 694.002.31
For compatible spindle moulders, double-end tenoners, and shaper machines accepting a 1-1/4-inch bore and the verified cutter diameter. Confirm spindle fit, rotation, guarding, workholding, feed direction, cutter clearance, and the 5,100–8,800 RPM range.
Main Product Description
CMT 694.002.31 is the exact North American 1-1/4-inch-bore item in the official Series 694.002 45° chamfer cutter-head family. The verified row specifies a 5-29/32-inch diameter, 1-1/4-inch bore, two cutting edges, a 5,100–8,800 RPM range, and HW active cutting material. The corresponding metric row lists 150 mm diameter and 31.75 mm bore.
The cutter head uses a hard aluminium-alloy body with high resistance to tensile and yield stress. Two reversible HWM carbide cutting inserts measuring 50 × 12 × 1.5 mm form the active cutting system, while positioning pins support repeatable insert seating. The tool is classified for manual feed and the catalog identifies right-hand rotation.
CMT specifies the family for accurate bevels, chamfers, joints, and edge work on spindle moulders, double-end tenoners, and shaper machines. It is suitable across a broad material range and is especially suited to solid wood, veneer, plywood, and laminated materials. The cutter head is supplied in a solid plastic storage box.
Technical Specifications
Series 694.002 · SKU 694.002.31
- CMT Orange Tools
- 45° chamfer insert cutter head
- 694.002.31
- 694.002 — 45° Chamfer Cutter Heads
- 5-29/32 in · 150 mm
- 1-1/4 in · 31.75 mm
- 2
- 45°
- 5,100–8,800 RPM
- MAN — manual feed
- RH — right hand
- HWM carbide
- Included Cutting Inserts: 2 reversible inserts · 50 × 12 × 1.5 mm · Insert Edge Geometry: 2 cutting edges · 35° · Body Construction: Hard aluminium alloy · Insert Positioning: Automatic positioning pins · Storage: Supplied in a solid plastic box · Replacement Insert: 790.500.00 · minimum 10-piece pack or multiple · Listed Service Wedge: 695.999.42 · Clamping Screw: 990.064.00 · M8 × 16 · Hex Key: 991.064.00 · 4 mm · Recommended Service Tool: TW-006 torque screwdriver
- For compatible spindle moulders, double-end tenoners, and shaper machines accepting a 1-1/4-inch bore and the verified cutter diameter. Confirm spindle fit, rotation, guarding, workholding, feed direction, cutter clearance, and the 5,100–8,800 RPM range.
Best Fit Applications
45° Bevels & Chamfers
Edge Joints
Solid Wood
Veneer, Plywood & Laminates
Spindle Moulders, Tenoners & Shapers
Product Highlights
Reversible HWM Insert System
Two 50 × 12 × 1.5 mm HWM carbide inserts provide the active cutting edges, with automatic positioning pins supporting repeatable insert placement.
Industrial Manual-Feed Body
The hard aluminium-alloy body is classified for manual feed and is intended for compatible spindle moulders, double-end tenoners, and shaper machines.
Compatibility & Installation Notes
Confirm exact Item Code 694.002.31, a compatible 1-1/4-inch spindle or arbor, right-hand rotation, and machine guarding suitable for a 5-29/32-inch cutter head. Operate only within the verified 5,100–8,800 RPM range and follow the machine’s lower applicable limit. Inspect the aluminium body, positioning pins, inserts, wedge, and screws before use; seat both inserts correctly and maintain balanced Z2 installation. Use the recommended TW-006 torque screwdriver for fastening service screws. Replacement insert 790.500.00 is listed in minimum packs of 10 or multiples.
Verified 45° Chamfering in a 1-1/4-Inch Bore Format
CMT 694.002.31 combines a 5-29/32-inch diameter, 1-1/4-inch bore, Z2 HWM carbide insert system, 45° profile, and a 5,100–8,800 RPM operating range.
A hard aluminium-alloy body, automatic insert-positioning pins, manual-feed classification, and verified spare-part references complete the Series 694.002 industrial cutter-head configuration.
