Fine 1/16-Inch O-Flute
The compact single-flute geometry provides a 1/16-inch cutting diameter and 1/4-inch cutting height with a precise 1/8-inch shank.
Amana Tool Spektra™ Extreme Tool Life Coated Solid Carbide Single O-Flute Plastic Cutting Up-Cut CNC Router Bit, 1/16-Inch Diameter x 1/4-Inch Cutting Height x 1/8-Inch Shank
CA$999.99
Out of stock
SKU
51415-K
Product Type
Solid-Carbide Single O-Flute Plastic Cutting CNC Router Bit
Family / Category
Spektra™ Coated Spiral O-Flute Plastic Cutting CNC Router Bits
Direction
Up-cut · Right-hand helix · Right-hand cut
Diameter / Cut
1/16-inch diameter · 1/4-inch cutting height
Shank / Overall
1/8-inch shank · 2-inch overall length
Geometry / Speed
Single flute · Maximum 35,000 RPM
Material / Coating
Solid carbide · Spektra™ nACo® ceramic coating
Optional Accessory
RB-102 reducer for 1/4-inch collet to 1/8-inch shank · Sold separately
Applications
Fine acrylic,plastics,solid surface,sign materials,ACM and wood
Spektra™ Spiral O-Flute
Plastic Cutting CNC Bit
Single O-Flute Up-Cut Bit
Amana Tool 51415-K is a solid-carbide, single-flute, up-cut spiral O-flute CNC router bit with a 1/16-inch diameter, 1/4-inch cutting height, 1/8-inch shank, 2-inch overall length and Spektra™ nACo® ceramic coating for clean routing in plastics, acrylics, solid-surface materials and wood.
1/16 inCutting Diameter
1/4 inCutting Height
1/8 inShank Diameter
35,000Maximum RPM
Single O-Flute Up-Cut Bit
A mirror-finished solid-carbide CNC tool designed to direct chips upward while producing clean, smooth cuts in acrylic, plastics, solid-surface materials and wood.
Amana ToolSolid CarbideSpektra™ nACo®SKU 51415-K
Amana Tool specifies this bit only for CNC machines and routers with automatic feeding. It requires a compatible 1/8-inch collet; the RB-102 reducer is listed as an available optional accessory for adapting a 1/4-inch collet to a 1/8-inch shank.
Main Product Description
Amana Tool 51415-K is the exact Tool No. shown on its dedicated official product page in the Solid Carbide Spektra™ Extreme Tool Life Coated Spiral O-Flute Plastic Cutting CNC Router Bits family. The official specification block confirms up-cut direction, 1/16-inch diameter, 1/4-inch cutting height, 1/8-inch shank, 2-inch overall length, one flute and nACo® ceramic coating.
The single O-flute geometry is manufactured from an exclusive solid-carbide grade, polished to a mirror finish and designed to eject chips upward. Amana Tool identifies super-clean, smooth cutting in acrylic materials, other plastics and wood, with right-hand helix and right-hand cut geometry.
The mirror-finished cutting edge is intended to promote chip evacuation, reduce chip re-welding, dissipate heat and help prevent melting. The Spektra™ nACo® nanocomposite coating is a micro-thin ceramic treatment designed to retain cutting-edge sharpness and lubricity while resisting heat and oxidation.
Technical Specifications
Spektra™ Spiral O-Flute Plastic Cutting CNC Bits · SKU 51415-K
- Amana Tool
- Solid-Carbide Single-Flute Spiral O-Flute Plastic Cutting CNC Router Bit
- 51415-K
- Spektra™ Plastic Cutting Spiral O-Flute CNC Router Bits
- Solid Carbide Spektra™ Extreme Tool Life Coated Spiral O-Flute Plastic Cutting CNC Router Bits
- Up-cut
- Right-hand helix · Right-hand cut
- 1/16 inch
- 1/4 inch
- 1/8 inch
- 2 inches
- 1
- Active Cutting Material: Solid carbide · Coating Type: Spektra™ Extreme Tool Life · nACo® nanocomposite ceramic coating · Surface Finish: Mirror-finished cutting edge · Maximum RPM: 35,000 · Family Operating RPM: 18,000 RPM official chart reference · Machine Compatibility: CNC machines and routers with automatic feeding only · Optional Accessory: RB-102 router collet reducer · 1/4 inch to 1/8 inch · Available separately · Primary Applications: Plastic, acrylic, solid surface, sign materials and wood · Selected Materials: Acrylic, ABS, acetal, nylon, PVC, HDPE, UHMWPE, polycarbonate, PETG, ACM, laminate, cork and engineered plastics
- Amana Tool specifies this bit only for CNC machines and routers with automatic feeding. It requires a compatible 1/8-inch collet; the RB-102 reducer is listed as an available optional accessory for adapting a 1/4-inch collet to a 1/8-inch shank.
Best Fit Applications
Fine Acrylic Routing
PVC and Engineered Plastics
Solid-Surface Materials
ACM and Sign Panels
Wood and Plastic Detail Cuts
Product Highlights
Spektra™ nACo® Coating
The micro-thin nanocomposite ceramic coating is engineered to retain edge sharpness and lubricity while resisting heat and oxidation.
Mirror-Finished Up-Cut Edge
The polished right-hand up-cut geometry supports clean cutting, chip evacuation and reduced chip re-welding in industrial CNC applications.
Compatibility & Installation Notes
Confirm exact Tool No. 51415-K, a compatible 1/8-inch CNC collet, adequate cutter clearance and guarding, secure workholding and automatic machine feeding. The optional RB-102 reducer is available separately for adapting a 1/4-inch collet to the 1/8-inch shank. Observe the exact-page 35,000 RPM maximum, use the official chart only as an operating reference, and account for up-cut chip direction. Follow Amana Tool and CNC machine-manufacturer safety documentation.
Fine-Diameter O-Flute Geometry with a 1/8-Inch Shank
Amana Tool 51415-K combines a 1/16-inch solid-carbide cutting diameter, 1/4-inch cutting height, 1/8-inch shank, 2-inch overall length, single up-cut O-flute and 35,000 RPM maximum.
Its polished cutting edge and Spektra™ nACo® coating support clean CNC routing, chip evacuation, heat control and reduced chip re-welding across acrylic, plastics, sign materials, solid surface and wood.
