Clean Compression Finish
The compression spiral geometry is designed to control both panel faces for clean top and bottom edges in double-sided melamine, laminates, plywood, and veneered materials.
Amana Tool Spektra™ Solid Carbide 3-Flute Compression Spiral CNC Router Bit, 3/8" Diameter x 1-1/8" Cutting Height x 3/8" Shank
CA$999.99
Out of stock
SKU
46010-K
Product Type
Solid-Carbide 3-Flute Compression Spiral CNC Router Bit
Family / Category
Spektra™ Extreme Tool Life Coated Compression Spiral CNC Router Bits
Diameter / Cut
3/8-inch diameter · 1-1/8-inch cutting height
B1 / Overall
9 mm B1 · 3-inch overall length
Shank / Flutes
3/8-inch shank · 3 flutes
Geometry
Compression spiral for clean top and bottom panel edges
Cutting Material
Solid carbide
Coating / Speed
Spektra™ nACo® ceramic coating · 18,000 RPM CNC chart
Applications
Melamine,laminate,MDF,particleboard,plywood,wood,OSB,cork and CFRP
3-Flute Compression
3/8-Inch Diameter
Compression Spiral
Amana Tool 46010-K is a three-flute solid-carbide compression spiral CNC router bit with a 3/8-inch diameter, 1-1/8-inch cutting height, and 3/8-inch shank. Its compression geometry is designed for high-feed CNC applications requiring clean top and bottom surfaces in double-sided melamine, laminated panels, plywood, MDF, wood, and other abrasive materials.
3/8 inCutting Diameter
1-1/8 inCutting Height
9 mmB1 Compression Length
3Flutes
Compression Spiral
A solid-carbide, three-flute CNC compression spiral with Spektra™ Extreme Tool Life nACo® ceramic coating. The exact official Tool No. is 46010-K.
Amana ToolSolid Carbide3 FlutesSKU 46010-K
Intended for industrial CNC routing equipment using a secure 3/8-inch collet. Amana Tool's linked compression-spiral chart publishes an 18,000 RPM CNC operating spindle-speed reference and material-specific feed recommendations for the 3/8-inch, three-flute configuration.
Main Product Description
Amana Tool 46010-K is the exact three-flute solid-carbide compression spiral CNC router bit shown on its dedicated official product page. It combines a 3/8-inch cutting diameter, 1-1/8-inch cutting height, 9 mm B1 dimension, 3/8-inch shank, and 3-inch overall length.
The compression geometry is designed to produce clean top and bottom edges in double-sided melamine, laminated sheet goods, veneered plywood, MDF, particleboard, and solid wood. Amana Tool specifically positions this tool for CNC applications requiring high feed rates, clean finishes, and reliable performance in abrasive materials.
The solid-carbide body carries Amana Tool's Spektra™ Extreme Tool Life nACo® nanocomposite ceramic coating. The coating is engineered to help preserve cutting-edge sharpness and lubricity while resisting heat and oxidation. The linked official chart identifies 46010-K as a three-flute 3/8-inch tool and publishes an 18,000 RPM CNC operating spindle-speed reference.
Technical Specifications
3-Flute Compression Spiral · SKU 46010-K
- Amana Tool
- Solid-Carbide 3-Flute Compression Spiral CNC Router Bit
- 46010-K
- Spektra™ Solid-Carbide Compression Spiral
- Solid Carbide Spektra™ Extreme Tool Life Coated Compression Spiral CNC Router Bits
- 3/8 inch
- 1-1/8 inches
- 9 mm
- 3/8 inch
- 3 inches
- 3
- Solid Carbide
- Type / Coating: nACo Ceramic Coating · Spektra™ Extreme Tool Life · Published Operating RPM: 18,000 RPM · Official Compression-Spiral Chart · Official Materials: CFRP · Cork · Double-Sided Melamine · Laminate · Laminated Plywood · Melamine Particleboard · MDF · OSB · Particleboard · Softwood/Hardwood · Veneered Plywood
- Intended for industrial CNC routing equipment using a secure 3/8-inch collet. Amana Tool's linked compression-spiral chart publishes an 18,000 RPM CNC operating spindle-speed reference and material-specific feed recommendations for the 3/8-inch, three-flute configuration.
Best Fit Applications
Double-Sided Melamine & Laminate
MDF & Particleboard
Laminated & Veneered Plywood
Softwood & Hardwood
CFRP, Cork & OSB
Product Highlights
Three-Flute CNC Geometry
The verified three-flute configuration supports high-feed CNC applications while maintaining a clean finish across abrasive panel products and solid wood.
Spektra™ nACo® Coating
The micro-thin nanocomposite ceramic coating helps retain cutting-edge sharpness and lubricity while resisting heat and oxidation during production routing.
Compatibility & Installation Notes
Confirm exact SKU 46010-K, a compatible 3/8-inch CNC collet, secure workholding, and sufficient clearance for the 1-1/8-inch cutting height. The official 18,000 RPM speed-and-feed chart is a recommendation and must be matched to the material, machine, tooling condition, and production setup. Follow all Amana Tool and machine-manufacturer safety documentation.
Clean Panel Edges with Three-Flute Spektra™ Performance
Amana Tool 46010-K combines solid-carbide construction, three-flute compression geometry, and Spektra™ nACo® coating for demanding CNC panel-processing applications.
Its verified 3/8-inch diameter, 1-1/8-inch cutting height, 9 mm B1 dimension, and 3/8-inch shank make it a focused production tool for double-sided melamine, laminate, plywood, MDF, particleboard, solid wood, cork, OSB, and CFRP.
