90° Two-Flute Geometry
The verified 90° profile and two-flute solid-carbide construction are designed for decorative V-grooves, lettering, chamfers, and beveled edges.
Amana Tool Spektra™ Solid Carbide 2-Flute 90° V-Groove Router Bit, 1/4" Diameter x 1/8" Cutting Height x 1/4" Shank
CA$999.99
Out of stock
SKU
45625-K
Product Type
Spektra™ Solid-Carbide 2-Flute V-Groove Router Bit
Family / Category
Spektra™ V-Groove Signmaking &Lettering Router Bits
Angle / Profile
90° V-groove profile
Diameter / Cut
1/4-inch diameter · 1/8-inch cutting height
B1 / Overall
9/16-inch B1 · 1-1/2-inch overall length
Shank / Flutes
1/4-inch shank · 2 flutes
Cutting Material
Solid carbide
Coating / Speed
Spektra™ nACo® coating · 18,000 RPM CNC operating chart
Applications
Decorative V-grooves,lettering,chamfering,beveling and signmaking
90° V-Groove
2-Flute Precision
Spektra™ V-Groove
Amana Tool 45625-K is a two-flute solid-carbide V-groove router bit with a 90° profile, 1/4-inch diameter, 1/8-inch cutting height, and Spektra™ Extreme Tool Life coating. It is designed for decorative V-grooves, sign lettering, chamfering, and beveling with handheld, table-mounted, and CNC routers.
90°V-Groove Angle
1/4 inCutting Diameter
1/8 inCutting Height
2Flutes
Spektra™ V-Groove
A solid-carbide, two-flute signmaking and lettering router bit with a 90° V-groove profile and nACo® nanocomposite Spektra™ coating. The exact official Tool No. is 45625-K.
Amana ToolSolid Carbide2 FlutesSKU 45625-K
Compatible with routing equipment using a secure 1/4-inch collet. Amana Tool lists handheld, table-mounted, and CNC router use and publishes an 18,000 RPM CNC operating spindle-speed chart for this Spektra™ V-groove family.
Main Product Description
Amana Tool 45625-K is the exact two-flute solid-carbide 90° V-groove router bit shown on its dedicated official product page. It combines a 1/4-inch diameter, 1/8-inch cutting height, 9/16-inch B1 dimension, 1/4-inch shank, and 1-1/2-inch overall length in a compact signmaking profile.
The tool is intended for decorative V-grooves and lettering on signs and can also be used for guided chamfering and beveling. Amana Tool identifies this exact family for handheld, table-mounted, and CNC routers, providing flexibility across shop and production routing setups.
Spektra™ Extreme Tool Life treatment uses Amana Tool's nACo® nanocomposite coating to help preserve cutting-edge sharpness and lubricity while resisting heat and oxidation. The official material list includes high-density urethane, acrylic, composites, composite decking, cork, foam, laminate, MDF/HDF, melamine, plywood, PVC plastic, sign board, solid surface, veneered plywood, wood, and Xanita® Board.
Technical Specifications
90° Spektra™ V-Groove · SKU 45625-K
- Amana Tool
- Solid-Carbide 2-Flute V-Groove Router Bit
- 45625-K
- Spektra™ Solid-Carbide V-Groove
- Solid Carbide Spektra™ Extreme Tool Life Coated V-Groove Signmaking & Lettering Router Bits
- 90°
- 1/4 inch
- 1/8 inch
- 9/16 inch
- 1/4 inch
- 1-1/2 inches
- 2 Flutes
- Active Cutting Material: Solid Carbide · Coating: Spektra™ Extreme Tool Life · nACo® Nanocomposite Coating · Router Compatibility: Handheld, Table-Mounted and CNC Routers · CNC Operating Spindle Speed: 18,000 RPM · Official Spektra™ V-Groove Chart
- Compatible with routing equipment using a secure 1/4-inch collet. Amana Tool lists handheld, table-mounted, and CNC router use and publishes an 18,000 RPM CNC operating spindle-speed chart for this Spektra™ V-groove family.
Best Fit Applications
Decorative 90° V-Grooves
Sign Lettering & Detail
Guided Chamfering & Beveling
Wood, Plywood & MDF/HDF
Plastics, Foam & Composites
Product Highlights
Spektra™ nACo® Coating
The micro-thin nanocomposite coating helps retain cutting-edge sharpness and lubricity while resisting heat and oxidation.
Broad Router Compatibility
Amana Tool lists handheld, table-mounted, and CNC router use for decorative V-grooves, lettering, chamfering, and beveling applications.
Compatibility & Installation Notes
Confirm exact SKU 45625-K and use a compatible, secure 1/4-inch collet with adequate clearance for the 90° profile. Amana Tool permits handheld, table-mounted, and CNC router use; guided edge chamfering and beveling require an appropriate edge guide. For CNC records, keep the official 18,000 RPM operating spindle-speed chart assigned to this Spektra™ V-groove family and follow all router, machine, guarding, and workholding documentation.
90° V-Groove Detail with Two-Flute Spektra™ Performance
Amana Tool 45625-K combines a 90° V-groove profile, two-flute solid-carbide geometry, 1/4-inch diameter, and Spektra™ nACo® coating for signmaking and decorative routing.
Its verified dimensions, broad router compatibility, and official material range make it a versatile choice for lettering, V-grooves, chamfers, and beveled edges.
