Ultra-Fine 0.005-Inch Tip
The verified 15° profile and 0.005-inch tip width support precise carving, lettering, and intricate signmaking details.
Amana Tool Spektra™ Solid Carbide 15° Engraving Router Bit, 0.005" Tip x 1/4" Shank
CA$999.99
Out of stock
SKU
4561-K
Product Type
Spektra™ Solid-Carbide Engraving Router Bit
Engraving Angle
15°
Tip Width
0.005 in
Shank
1/4 in
Cutting Material
Solid Carbide
Coating
Spektra™
15° Engraving
0.005-Inch Tip
Spektra™ Engraving
Amana Tool 45611-K is a single-flute solid-carbide engraving router bit with a precise 15° profile, an ultra-fine 0.005-inch tip width, and Spektra™ Extreme Tool Life coating. It is designed for extra-fine carving, lettering, and signmaking details in wood, plastics, cork, solid surface, veneered plywood, MDF/HDF, and laminate.
15°Engraving Angle
0.005 inTip Width
0.93 inCutting Height
1/4 inShank Diameter
Spektra™ Engraving
A solid-carbide, single-flute signmaking and engraving router bit with a 15° profile, 0.005-inch tip, and nACo® nanocomposite Spektra™ coating. The exact official Tool No. is 45611-K.
Amana ToolSolid CarbideSingle FluteSKU 45611-K
Intended for compatible CNC routing and engraving equipment using a secure 1/4-inch collet. Amana Tool publishes an 18,000 RPM operating chart for this engraving family, while the exact product page lists a 28,000 RPM maximum.
Main Product Description
Amana Tool 45611-K is the exact solid-carbide 15° engraving router bit shown on its dedicated official product page. Its 0.005-inch tip width is intended for extra-fine carving and lettering details, with a 0.93-inch cutting height, 1/4-inch shank, and 2-1/4-inch overall length.
The single-flute geometry is paired with Amana Tool's Spektra™ Extreme Tool Life nACo® nanocomposite coating. The coating is engineered to help the cutting edge retain sharpness and lubricity while resisting heat and oxidation during demanding engraving work.
Official application data supports wood, plastic, cork, and solid-surface materials. Amana Tool's matching CNC set literature additionally identifies wood, veneered plywood, MDF/HDF, and laminate for this exact 45611-K profile. Compatible Vectric and Fusion 360 tool files are available from Amana Tool.
Technical Specifications
15° Spektra™ Engraving · SKU 45611-K
- Amana Tool
- Solid-Carbide Single-Flute Engraving Router Bit
- 4561-K
- Spektra™ Solid-Carbide Engraving
- 45611-K
- Solid Carbide Spektra™ Extreme Tool Life Coated Engraving Router Bits for Signmaking
- 15°
- 0.005 inch
- 0.93 inch
- 1/4 inch
- 2-1/4 inches
- 1 Flute
- Active Cutting Material: Solid Carbide · Coating: Spektra™ Extreme Tool Life · nACo® Nanocomposite Coating · Published Operating RPM: 18,000 RPM · Official Engraving Speed Chart · Maximum RPM: 28,000 RPM · Exact Product Page · Digital Tool Support: Vectric and Fusion 360 Compatible Tool Files Available
- Intended for compatible CNC routing and engraving equipment using a secure 1/4-inch collet. Amana Tool publishes an 18,000 RPM operating chart for this engraving family, while the exact product page lists a 28,000 RPM maximum.
Best Fit Applications
Extra-Fine CNC Engraving
Detailed Lettering & Signmaking
Wood & Veneered Plywood
MDF, HDF & Laminate
Plastic, Cork & Solid Surface
Product Highlights
Spektra™ nACo® Coating
The micro-thin nanocomposite coating helps retain cutting-edge sharpness and lubricity while resisting heat and oxidation.
Verified Digital Tool Support
Amana Tool provides compatible Vectric and Fusion 360 tool files for the exact 45611-K profile to support accurate CNC tool-library setup.
Compatibility & Installation Notes
Confirm exact SKU 45611-K, a compatible 1/4-inch CNC collet, secure workholding, and adequate clearance for the 15° engraving profile. Keep the official 18,000 RPM engraving chart separate from the product-page maximum of 28,000 RPM. Use only the Amana Tool digital tool record assigned to this exact item number and follow all Amana Tool and CNC machine safety documentation.
Fine 15° Detail with Solid-Carbide Spektra™ Performance
Amana Tool 45611-K combines a 0.005-inch tip, 15° single-flute engraving geometry, solid-carbide construction, and Spektra™ nACo® coating for precise detail work.
Its verified dimensions, broad signmaking material range, and official digital-tool support make it a focused CNC engraving option for fine lettering, carving, and detailed decorative work.
