Precision 3/8-Inch Radius
Engineered for exact roundover profiles with a 7/8-inch cutting diameter and 3/8-inch cutting height.
Amana Tool Tru Point Insert Roundover CNC System Knife 3/8 R x 7/8 D x 3/8 CH
CA$999.99
Out of stock
SKU
RCK-475
Product Type
Solid Carbide Insert Roundover Knife
Family / Category
Tru Point Insert CNC System Router Bits
Radius
3/8 inch
Cutting Diameter
7/8 inch
Cutting Height
3/8 inch
D1 Dimension
13/16 inch
Cutting Material
Solid Carbide
Applications
Lettering,engraving,signmaking,fluting,and trimming
Solid Carbide Insert
3/8-Inch Radius Roundover Knife
Insert Knife
Amana Tool RCK-475 is the exact solid carbide insert replacement knife designed for the Tru Point Roundover Insert CNC System. Featuring a 3/8-inch radius, 7/8-inch diameter, 3/8-inch cutting height, and 13/16-inch D1 dimension for precise lettering, engraving, signmaking, fluting, and decorative trimming applications.
3/8 inRadius (R)
7/8 inDiameter (D)
3/8 inCutting Height (B)
13/16 inD1 Dimension
Insert Knife
A solid carbide replacement knife engineered for the Tru Point Roundover Insert CNC System. The exact official SKU is RCK-475, matching tool body RC-1063.
Amana ToolSolid CarbideTru Point SystemSKU RCK-475
Compatible with Amana Tool Tru Point Roundover insert tool bodies such as RC-1063. Ensure proper seating and torque specifications during knife replacement for optimal CNC performance.
Main Product Description
Amana Tool RCK-475 is the exact solid carbide insert replacement knife engineered for the Tru Point Roundover Insert CNC System. The official specification block confirms a 3/8-inch radius, 7/8-inch diameter, 3/8-inch cutting height, and 13/16-inch D1 dimension.
Designed for professional CNC routing, this replacement knife delivers exceptional edge retention and clean profile cuts in hardwood, softwood, MDF, plywood, and plastics. It is ideal for lettering, engraving, signmaking, fluting, and decorative trimming applications.
Note: Due to the very fine plunge point characteristic of this profile, the knife requires careful handling and is not guaranteed against breakage. Ensure secure installation in compatible tool bodies such as the RC-1063.
Technical Specifications
Tru Point Roundover Insert Knife · SKU RCK-475
- Amana Tool
- Solid Carbide Insert Roundover Knife
- RCK-475
- Tru Point Roundover Insert CNC System
- Tru Point Insert CNC System Router Bits
- 3/8 inch
- 7/8 inch
- 3/8 inch
- 13/16 inch
- RC-1063 (1/2-Inch Shank)
- Solid Carbide
- Lettering, Signmaking, Fluting & Trim
- CNC Signmaking & Lettering · Decorative Fluting · Edge Roundover Trim
- Compatible with Amana Tool Tru Point Roundover insert tool bodies such as RC-1063. Ensure proper seating and torque specifications during knife replacement for optimal CNC performance.
Best Fit Applications
CNC Signmaking & Lettering
Decorative Fluting
Edge Roundover Trim
Engraving Work
Complex Panel Detailing
Product Highlights
Industrial Solid Carbide
Manufactured from premium industrial-grade solid carbide for superior wear resistance and extended tool life in demanding production environments.
Tru Point System Integration
Designed for seamless interchangeability within the Amana Tool Tru Point Roundover insert body ecosystem.
Compatibility & Installation Notes
Verify secure knife seating and correct screw torque prior to operation. Due to the very fine plunge point on this profile, the knife requires careful handling and is not guaranteed against breakage. Ensure compatibility with tool body RC-1063 and follow all CNC machine safety guidelines.
Engineered For Precision CNC Signmaking
Amana Tool RCK-475 provides professional CNC operators with reliable replacement tooling for intricate signmaking, fluting, and decorative edge profiling. Built to exacting industrial standards for consistent repeatability.
Amana Tool RCK-475 is the exact solid carbide insert replacement knife engineered for the Tru Point Roundover Insert CNC System. The official specification block confirms a 3/8-inch radius, 7/8-inch diameter, 3/8-inch cutting height, and 13/16-inch D1 dimension.
