4-Edge Indexable Design
Precision-ground solid carbide knife featuring four usable cutting edges for extended tooling life and reduced downtime.
Amana Tool Solid Carbide Insert Replacement Knife for MDF / Fiberboard 12 x 12 x 1.5mm x 45°
CA$999.99
Out of stock
SKU
RCK-459
Product Type
Carbide-Tipped Raised Panel Router Bit
Family / Category
Traditional Raised Panel Router Bits
Cut Depth / Angle
1-7/16 inch · 15°
Cutting Diameter
3-3/8 inches
Cutting Height
1/2 inch
Shank / Overall
1/2-inch shank · 2-51/64-inch overall length
Geometry / Speed
2 flutes · Maximum 14,000 RPM
Cutting Material
Carbide tipped
Applications
Raised panels,cabinet doors,furniture,and architectural panels
Solid Carbide 4-Edge
Insert Replacement Knife for MDF
Insert Knife
Amana Tool RCK-459 is the exact 12 x 12 x 1.5mm solid carbide replacement knife featuring 4 cutting edges, a 45-degree angle, and a 35-degree bevel, specifically engineered for high-precision routing and grooving in MDF, fiberboard, and chipboard.
12 mmCut Depth (A)
1.5 mmThickness (C)
45°Angle
4 EdgesCutting Capacity
Insert Knife
A precision-ground solid carbide replacement knife with four indexable cutting edges. The exact official Tool No. is RCK-459; its dedicated amanatool.com page places it in Solid Carbide Insert Knives.
Amana ToolSolid CarbideMDF & FiberboardSKU RCK-459
Engineered for compatible Amana Tool CNC router bodies including RC-2255, RC-2255-M, RC-2255-TG, RC-2259, RC-2259-TG, RC-2261, and RC-2263. Ensure proper seating and torque specs during installation.
Main Product Description
Amana Tool RCK-459 is the exact Tool No. shown on its dedicated official product page. The labelled specification block confirms a 12mm cut depth (A), 1.5mm thickness (C), 45-degree angle, and four indexable cutting edges designed specifically for MDF and fiberboard.
Manufactured from industrial-grade solid carbide, this replacement knife features a 35-degree bevel and delivers exceptional wear resistance and clean edge quality when machining abrasive composite panels, particle board, and high-density fiberboard. Each knife offers four usable cutting edges for maximum operational efficiency.
This knife is fully compatible with Amana Tool body series RC-2255, RC-2255-M, RC-2255-TG, RC-2259, RC-2259-TG, RC-2261, and RC-2263. Knives are sold individually; verify the required quantity for your specific cutterhead assembly.
Technical Specifications
12mm Insert Knives · SKU RCK-459
- Amana Tool
- Solid Carbide Insert Replacement Knife
- RCK-459
- Solid Carbide Insert Knives
- Solid Carbide Insert Knives
- 12 mm
- 1.5 mm
- 45°
- 35°
- 4 Edges
- Solid Carbide
- MDF, Fiberboard, Chipboard
- Package Configuration: Sold Individually
- Engineered for compatible Amana Tool CNC router bodies including RC-2255, RC-2255-M, RC-2255-TG, RC-2259, RC-2259-TG, RC-2261, and RC-2263. Ensure proper seating and torque specs during installation.
Best Fit Applications
Medium Density Fiberboard (MDF)
High-Density Fiberboard (HDF)
Particle Board & Chipboard
Composite Panel Processing
Cabinetry & Millwork Production
Product Highlights
Engineered for MDF & Fiberboard
Optimized 35-degree bevel geometry and solid carbide grade built to resist abrasive wear in composite materials.
Broad Body Compatibility
Directly compatible with Amana Tool router bodies including RC-2255, RC-2259, RC-2261, and RC-2263 series.
Compatibility & Installation Notes
Verify exact Tool No. RCK-459 and ensure compatibility with your specific Amana Tool body (such as RC-2255 or RC-2259). Clean knife seats thoroughly of any resin or debris before installing new inserts. Torque pocket screws to manufacturer specifications using a proper torque driver. Knives are sold individually; confirm the required quantity per tool body prior to setup.
Precision Solid Carbide Cutting Performance for MDF and Fiberboard
Amana Tool RCK-459 provides industrial-grade reliability with its 12 x 12 x 1.5mm dimensions, four indexable cutting edges, and 35-degree bevel geometry.
Designed specifically for high-speed routing in MDF, fiberboard, and chipboard, this replacement knife ensures clean edge finishes and consistent productivity across demanding production environments.
