Hybrid Edge Construction
Combines one high-durability polycrystalline diamond (PCD) cutting edge with three solid carbide cutting edges for optimized wear resistance.
Amana Tool Polycrystalline Diamond Tipped & Solid Carbide Insert Knife 12 x 12 x 1.5mm x 45°
CA$999.99
Out of stock
SKU
RCK-459-PCD
Product Type
Polycrystalline Diamond &Carbide Insert Knife
Family / Category
Solid Carbide Insert Knives
Dimensions / Angle
12 x 12 x 1.5mm · 45° Angle · 35° Bevel
Cut Depth / Thickness
12mm Cut Depth · 1.5mm Thickness
Cutting Edges
1 PCD Cutting Edge &3 Solid Carbide Cutting Edges
Compatible Tool Nos.
RC-2255,RC-2259,RC-2261,RC-2263
Cutting Material
Polycrystalline Diamond (PCD) &Solid Carbide
Applications
MDF,chipboard,engineered wood composites,and high-wear CNC routing
PCD Tipped 1-Edge
Solid Carbide 3-Edge Insert Knife
Insert Knife
Amana Tool RCK-459-PCD is the exact 12 x 12 x 1.5mm polycrystalline diamond (PCD) tipped and solid carbide insert knife featuring one PCD cutting edge, three solid carbide cutting edges, a 45-degree angle, a 35-degree bevel, and engineered specifically for CNC routing and machining of MDF and chipboard.
45°Angle
12 mmCut Depth (A)
1.5 mmThickness (C)
1 PCD / 3 SCCutting Edges
Insert Knife
A precision replacement insert knife with one polycrystalline diamond cutting edge and three solid carbide cutting edges. The exact official Tool No. is RCK-459-PCD; verified for compatibility with CNC tool bodies RC-2255, RC-2259, RC-2261, and RC-2263.
Amana ToolPCD / Carbide Tipped12mm InsertSKU RCK-459-PCD
Designed for high-wear CNC routing applications in MDF, chipboard, and composite panels using compatible Amana Tool insert cutterheads. Ensure correct seating, torque specifications, and secure clamping prior to machine operation.
Main Product Description
Amana Tool RCK-459-PCD is the exact polycrystalline diamond and solid carbide insert knife identified on its dedicated official product page. Engineered with one PCD tipped cutting edge and three solid carbide cutting edges, this 12 x 12 x 1.5mm knife delivers exceptional wear resistance and superior edge retention when cutting abrasive panel materials.
Featuring a 45-degree angle and a 35-degree bevel, the knife is specifically optimized for CNC tooling systems including tool numbers RC-2255, RC-2259, RC-2261, and RC-2263. The combination of diamond technology and solid carbide provides extended tool life, allowing operators to cut thousands of feet more between changes compared to standard carbide tooling.
Sold individually, these replacement insert knives are tailored for demanding production environments processing MDF, chipboard, and engineered wood composites. Ensure proper pocket cleanliness and recommended screw torque during installation.
Technical Specifications
12mm Insert Knives · SKU RCK-459-PCD
- Amana Tool
- Polycrystalline Diamond & Carbide Insert Knife
- RCK-459-PCD
- Solid Carbide Insert Knives
- Solid Carbide Insert Knives
- 12 x 12 x 1.5 mm
- 45°
- 35°
- 12 mm
- 1.5 mm
- 1 PCD Edge / 3 Solid Carbide Edges
- Polycrystalline Diamond (PCD) & Solid Carbide
- Workpiece Material: MDF, Chipboard, Engineered Wood · Package Configuration: Sold Individually
- Designed for high-wear CNC routing applications in MDF, chipboard, and composite panels using compatible Amana Tool insert cutterheads. Ensure correct seating, torque specifications, and secure clamping prior to machine operation.
Best Fit Applications
MDF Routing & Profiling
Chipboard Panel Processing
High-Wear CNC Operations
Engineered Wood Composites
High-Volume Production Runs
Product Highlights
Extended Tool Life
Diamond technology cuts thousands of feet more than standard carbide without changing tooling, minimizing machine downtime.
Precision CNC Fitment
Designed specifically for Amana Tool insert cutterheads including RC-2255, RC-2259, RC-2261, and RC-2263.
Compatibility & Installation Notes
Ensure tool holders and cutterhead pockets are thoroughly cleaned of debris and resin build-up prior to installing replacement insert knives. Verify proper seating against locating pins and torque all clamping screws to manufacturer specifications before operating CNC equipment.
Engineered for Maximum Production Efficiency
Amana Tool RCK-459-PCD delivers exceptional cutting performance and wear resistance for professional woodworking and industrial CNC fabrication. By uniting PCD technology with solid carbide backup edges, this insert knife maximizes throughput and surface finish quality across demanding MDF and chipboard applications.
Amana Tool RCK-459-PCD is the exact polycrystalline diamond and solid carbide insert knife identified on its dedicated official product page. Engineered with one PCD tipped cutting edge and three solid carbide cutting edges, this 12 x 12 x 1.5mm knife delivers exceptional wear resistance and superior edge retention when cutting abrasive panel materials.
