In-Groove™ Quick-Change
Engineered for rapid insert indexing and replacement while the tool body remains secured in the CNC machine spindle.
Amana Tool Solid Carbide Insert 30° x 0.030" V-Tip Engraving Knife
CA$999.99
Out of stock
SKU
RCK-363
Product Type
Solid Carbide V-Tip Engraving Insert Knife
Family / Category
In-Groove CNC Insert Engraving Tool Body &Replacement Knives
Angle / Tip Width
30° · 0.030-inch Tip Width
Cutting Height
16mm (5/8 inch)
System Series
In-Groove™ Insert Engraving System
Plunge Feed
80 Inches/Min
Cutting Material
Solid Carbide
Applications
CNC Signmaking,lettering,etching,and detailed grooving
Solid Carbide Insert
30° x 0.030" V-Tip Engraving Knife
Engraving Insert Knife
Amana Tool RCK-363 is the exact 30-degree solid carbide insert engraving knife featuring a 0.030-inch V-tip width and a 16mm (5/8-inch) cutting height, engineered for precision CNC signmaking, lettering, etching, and detailed multi-material grooving.
30°Angle (a°)
0.030"Tip Width (t)
5/8"Cutting Height (B)
80 IPMPlunge Feed
Engraving Insert Knife
A replaceable solid carbide insert knife designed for the Amana Tool In-Groove™ engraving system. The exact official Tool No. is RCK-363; its dedicated amanatool.com page places it within In-Groove CNC Insert Engraving Tool Bodies.
Amana ToolSolid CarbideIn-Groove™ SystemSKU RCK-363
Designed for use with In-Groove tool bodies including RC-1075 (1/4" shank), RC-1076 (1/2" shank), RC-1077 (6mm shank), and RC-1078 (12mm shank). Allows rapid insert exchanges while the body remains mounted in the CNC machine.
Main Product Description
Amana Tool RCK-363 is the exact Tool No. shown on its dedicated official product page. The labelled specification block confirms a 30-degree angle, 0.030-inch tip width, and 16mm (5/8-inch) cutting height, crafted from industrial-quality micrograin solid carbide.
Engineered as part of the versatile In-Groove™ CNC insert engraving system, this knife delivers clean, sharp cuts for lettering, fine etching, and detailed signmaking. The industrial insert design allows quick, accurate replacement directly in the machine collet to eliminate downtime.
Optimized for a recommended plunge feed rate of 80 inches per minute, the insert provides exceptional longevity across wood, plastics, composites, and non-ferrous metals. Note that this listing is for the replacement insert knife only; In-Groove tool bodies are sold separately.
Technical Specifications
In-Groove™ Engraving Knife · SKU RCK-363
- Amana Tool
- Solid Carbide V-Tip Engraving Insert Knife
- RCK-363
- In-Groove™ Engraving System
- In-Groove CNC Insert Engraving Tool Body & Replacement Knives
- 30°
- 0.030 inches
- 16mm (5/8 inches)
- Solid Carbide
- 80 Inch/Min
- RC-1075, RC-1076, RC-1077, RC-1078
- In-Groove™ Insert Engraving System
- Package Configuration: Sold individually (1 per pack)
- Designed for use with In-Groove tool bodies including RC-1075 (1/4" shank), RC-1076 (1/2" shank), RC-1077 (6mm shank), and RC-1078 (12mm shank). Allows rapid insert exchanges while the body remains mounted in the CNC machine.
Best Fit Applications
CNC Signmaking & Lettering
Fine Detailing & Etching
Plastics & Acrylic Engraving
Non-Ferrous Metal Etching
Cabinetry & Wood Profiling
Product Highlights
Precision 30° Geometry
Features a 30-degree angle with a 0.030-inch V-tip width to deliver ultra-crisp lines for intricate lettering and etching.
Industrial Solid Carbide
Manufactured from premium carbide to last at least twice as long as comparable solid carbide bits.
Compatibility & Installation Notes
RCK-363 is a replacement insert knife designed exclusively for use with Amana Tool In-Groove™ insert engraving tool bodies. Ensure the insert seat is thoroughly clean and free of debris before tightening retaining screws to maintain precise concentricity and balanced high-speed CNC operation.
Precision Engraving Excellence
Amana Tool RCK-363 brings industrial-grade reliability and repeatable accuracy to CNC signmaking and engraving workflows. By combining quick-change convenience with premium solid carbide durability, this insert knife minimizes downtime and maximizes cut quality across demanding production environments.
Amana Tool RCK-363 is the exact Tool No. shown on its dedicated official product page. The labelled specification block confirms a 30-degree angle, 0.030-inch tip width, and 16mm (5/8-inch) cutting height, crafted from industrial-quality micrograin solid carbide.
