Quick-Change Indexing
Engineered to swap inserts directly inside the CNC machine, eliminating downtime and preserving registration.
Amana Tool Solid Carbide Insert 30 Deg x 0.020 Inch V-Tip Engraving Knife
CA$999.99
Out of stock
SKU
RCK-362
Product Type
Solid Carbide Insert Engraving Knife
Family / Category
In-Groove™ Insert Engraving System
Angle / Tip Width
30° · 0.020 inch tip width
Cutting Height
16mm (5/8 inch)
Plunge Feed Rate
80 Inch/Min
Cutting Material
Solid Carbide
Applications
Signmaking,lettering,plastics,wood,and non-ferrous metals
Solid Carbide 30° V-Tip
Engraving Insert Knife
Insert Engraving Knife
Amana Tool RCK-362 is a precision industrial solid carbide insert engraving knife engineered for the In-Groove™ system. Featuring a 30-degree profile angle, 0.020-inch V-tip width, and a 16mm (5/8-inch) cutting height, this replacement knife delivers exceptional clean cuts and high-accuracy etching across a wide range of woods, plastics, composites, and non-ferrous metals.
30°V-Tip Angle (a°)
0.020 inTip Width (t)
5/8 inCutting Height (B)
80 In/MinPlunge Feed Rate
Insert Engraving Knife
An industrial solid carbide replacement insert designed to fit In-Groove™ tool bodies while remaining mounted in CNC routers, minimizing downtime and maximizing runout accuracy.
Amana ToolSolid CarbideIn-Groove™ SystemSKU RCK-362
Designed exclusively for use with Amana Tool In-Groove™ insert engraving tool bodies (such as RC-1075, RC-1076, RC-1077, and RC-1078). Ensure the insert seat is completely free of debris and chips before securing the locking screw to maintain accurate runout and prevent edge chipping. *V-Tip inserts are suitable for engraving aluminum, brass, and copper when paired with appropriate feed and speed rates.
Main Product Description
The Amana Tool RCK-362 is part of the versatile In-Groove™ engraving system, built to deliver ultra-clean details for professional signmaking, fine lettering, and intricate etching. Industrial-grade solid carbide construction offers superior edge retention, lasting at least twice as long as comparable solid carbide monolithic bits.
Designed for maximum shop efficiency, the insert can be rapidly exchanged while the tool body stays locked in the CNC collet, eliminating recalibration overhead. This knife handles challenging substrates with absolute precision, from high-density plastics and solid surfaces to hardwoods and non-ferrous metals.
Amana Tool RCK-362 combines high-performance solid carbide metallurgy with quick-change modular convenience, giving CNC operators an elite solution for detailed engraving, fine etching, and professional sign routing.
Technical Specifications
Technical Specifications
- Amana Tool
- Insert Engraving Knife
- RCK-362
- In-Groove™ Insert Engraving System
- In-Groove™ System
- Solid Carbide
- 0.020 in
- 16mm (5/8 in)
- 80 Inch/Min
- RC-1075, RC-1076, RC-1077, RC-1078
- 30°
- 0.020 in
- Signmaking & Lettering · Hard & Soft Woods · Plastics & Plexiglass
- Designed exclusively for use with Amana Tool In-Groove™ insert engraving tool bodies (such as RC-1075, RC-1076, RC-1077, and RC-1078). Ensure the insert seat is completely free of debris and chips before securing the locking screw to maintain accurate runout and prevent edge chipping. *V-Tip inserts are suitable for engraving aluminum, brass, and copper when paired with appropriate feed and speed rates.
Best Fit Applications
Signmaking & Lettering
Hard & Soft Woods
Plastics & Plexiglass
Aluminum, Brass & Copper*
MDF & Laminated Panels
Product Highlights
Extended Tool Life
Industrial solid carbide formulation delivers cleaner details and lasts at least twice as long as standard solid bits.
Versatile Metal & Wood Cutting
Optimized 30-degree V-tip geometry excels in wood, plastics, composite panels, and non-ferrous metals.
Compatibility & Installation Notes
Designed exclusively for use with Amana Tool In-Groove™ insert engraving tool bodies (such as RC-1075, RC-1076, RC-1077, and RC-1078). Ensure the insert seat is completely free of debris and chips before securing the locking screw to maintain accurate runout and prevent edge chipping. *V-Tip inserts are suitable for engraving aluminum, brass, and copper when paired with appropriate feed and speed rates.
Built for High-Precision CNC Production
Amana Tool RCK-362 combines high-performance solid carbide metallurgy with quick-change modular convenience, giving CNC operators an elite solution for detailed engraving, fine etching, and professional sign routing.
Rely on genuine Amana Tool engineering to maintain absolute cut consistency across demanding production schedules.
