Carbide-Tipped Z2
Traditional Raised Panel Router Bit
Amana Tool 54117 is an industrial-grade traditional raised-panel router bit featuring a 15-degree profile angle, 1-7/16-inch cut depth, 3-3/8-inch cutting diameter, 1/2-inch cutting height, 1/2-inch shank, and a bottom-mount ball bearing guide for precise cabinet door manufacturing.
Engineering & Performance
Professional Cabinetry Joinery & Profile Accuracy
Amana Tool 54117 is engineered for professional woodworkers and cabinetmakers seeking flawless, rattle-free panel profiles. The tool geometry cleanly shapes the raised field, establishes the architectural reveal, and forms the exact integral tongue required to fit frame-and-panel groove members securely.
Manufactured from European sub-micrograin and micrograin carbide, the cutting edges deliver superior wear resistance and extended service life. The single-clamping body manufacturing process ensures optimal balance, reduced vibration, and high concentricity during heavy stock removal.
Official Specifications
Technical Data
- Tool No. / SKU54117
- ManufacturerAmana Tool
- Product TypeTraditional Raised Panel Router Bit
- Cut Depth (A)1-7/16 in
- Angle (a°)15°
- Diameter (D)3-3/8 in
- Cutting Height (B)1/2 in
- B15/16 in
- Shank (d)1/2 in
- Overall Length (L)2-51/64 in
- Flutes2 (Z2)
- Cutting MaterialCarbide Tipped
- Replacement Bearing47706
- Replacement Screw67096
- Dust Shield67098
- Flat Washer67202
- Max RPM14,000 RPM
Target Workpieces & Industries
Best Fit Applications
Design Advantages
Product Highlights
European Carbide Integration
Produced using premium sub-micrograin and micrograin carbide with thick tips designed to withstand multiple resharpenings.
Balanced Body Construction
Machined from solid bar stock steel in a single clamping setup to guarantee exceptional symmetry, balance, and operational centricity.
Integrated Guide Bearing
Equipped with a bottom-mount ball bearing pilot (Bearing #47706) for smooth, template-referenced profile tracking along curved and straight edges.
Compatibility & Setup Requirements
Must be used exclusively in a table-mounted router equipped with a 3+ horsepower motor. Due to the large cutting diameter (3-3/8 in), run the tool at reduced speed (maximum 14,000 RPM). Always make multiple shallow passes to ensure operator safety, minimize stock burn, and achieve an exceptional surface finish.
