Verified 120-Degree Geometry
Exact Tool No. RC-1104 combines a 120-degree profile with a 2-1/32-inch diameter and 9/16-inch cutting height.
Amana Tool Insert Carbide CNC V-Groove Router Bit, 120°, 2-1/32-Inch Diameter, 9/16-Inch Cutting Height, 1/2-Inch Shank
CA$999.99
Out of stock
SKU
RC-1104
Product Type
Insert Carbide CNC V-Groove Router Bit
Profile Angle
120° · 60° a1 geometry
Cutting Diameter
2-1/32 inches
Cutting Height
9/16 inch
Shank / Overall
1/2-inch shank · 3-1/16-inch overall length
Flutes / Inserts
2 flutes · 2 solid-carbide inserts
Included Inserts
RCK-136 general-purpose inserts · Quantity 2
Optional Inserts
RCK-353 MDF inserts · Quantity 2 required
Maximum Speed
18,000 RPM manufacturer maximum
Insert Carbide CNC V-Groove
120-Degree · 2-1/32-Inch Diameter
120° Insert V-Groove
Amana Tool RC-1104 is the exact 120-degree CNC insert V-groove router bit with a 2-1/32-inch diameter, 9/16-inch cutting height, 1/2-inch shank, 3-1/16-inch overall length, two flutes, and two included solid-carbide general-purpose inserts.
120°Profile Angle (a°)
2-1/32 inDiameter (D)
9/16 inCutting Height (B)
1/2 inShank (d)
120° Insert V-Groove
A two-flute CNC V-groove, miter-fold, signmaking, and lettering tool using replaceable solid-carbide inserts. The exact official Tool No. is RC-1104.
Amana ToolInsert Carbide2 Included InsertsSKU RC-1104
Designed for professional CNC equipment accepting a 1/2-inch shank. Amana Tool publishes 18,000 RPM as the maximum speed ceiling; this is a safety limit, not setup guidance. Operation and insert service are for qualified adults following all manufacturer documentation.
Main Product Description
Amana Tool RC-1104 is the exact Tool No. shown on its dedicated official product page. The labelled specification block confirms a 120-degree angle, 60-degree a1 geometry, 2-1/32-inch diameter, 9/16-inch cutting height, 1-5/32-inch B1, 1/2-inch shank, 3-1/16-inch overall length, and 2-inch L1.
The insert-carbide CNC design is identified for V-grooving, miter folds, signmaking, and lettering. Amana Tool lists compatibility with acrylic and plastic, composites, composite decking, epoxy, foam, HDPE, laminate, melamine, MDF/HDF, PVC, sign board, solid surface, veneered plywood, wood, Xanita® board, and high-density urethane.
Two RCK-136 solid-carbide general-purpose inserts are included and required for the standard configuration. RCK-353 is the separately available optional MDF insert reference, also requiring two inserts. The official service-part record separately identifies four Torx screws under 67139 and Torx key 5005.
Technical Specifications
120° Insert Carbide CNC V-Groove Router Bit · SKU RC-1104
- Amana Tool
- Insert Carbide CNC V-Groove Router Bit
- RC-1104
- CNC Signmaking & V-Groove Tooling
- Insert Carbide V-Groove, Miter Fold & Signmaking CNC Router Bits
- 120°
- 60°
- 2-1/32 inches
- 9/16 inch
- 1-5/32 inches
- 1
- 1/2 inch
- Overall Length (L): 3-1/16 inches · L1: 2 inches · Maximum RPM: 18,000 · Flutes: 2 · Number of Inserts: 2 · Active Cutting Material: Solid-Carbide Inserts · Included General-Purpose Inserts: RCK-136 · 2 Required · Optional MDF Inserts: RCK-353 · 2 Required · Replacement Torx Screws: 67139 · Quantity 4 · Torx Key: 5005 · Compatible Tool Files: Vectric & Fusion 360
- Designed for professional CNC equipment accepting a 1/2-inch shank. Amana Tool publishes 18,000 RPM as the maximum speed ceiling; this is a safety limit, not setup guidance. Operation and insert service are for qualified adults following all manufacturer documentation.
Best Fit Applications
120-Degree CNC V-Grooving
Miter-Fold Profiles
Signmaking & Lettering
Wood, MDF & Veneered Plywood
Plastics, Composites & Solid Surface
Product Highlights
Included Carbide Insert Pair
The standard configuration includes the two RCK-136 solid-carbide general-purpose inserts required by the tool body.
Optional MDF Insert Support
Amana Tool identifies RCK-353 as the separately available MDF insert option, preserving the exact two-insert system format.
Compatibility & Safety Notes
Confirm exact Tool No. RC-1104, a compatible 1/2-inch interface, correct insert specification, secure workholding, and the official 18,000-RPM maximum ceiling. RCK-136 inserts are included; RCK-353 MDF inserts, Torx screws 67139, and Torx key 5005 are separate unless explicitly stated by the seller. CNC use and insert service require a qualified adult following all manufacturer guidance.
Verified 120-Degree CNC Geometry with Replaceable Carbide Inserts
Amana Tool RC-1104 combines a 120-degree profile, 2-1/32-inch diameter, 9/16-inch cutting height, 1/2-inch shank, 3-1/16-inch overall length, two flutes, and two included solid-carbide inserts.
Its verified application record covers V-grooving, miter folds, signmaking, lettering, wood products, plastics, composites, and solid-surface materials within the manufacturer’s published compatibility and safety limits.
