160-Degree V-Groove Geometry
The exact 160° included angle and 80° half-angle support broad, shallow V-groove profiles for miter-fold, signmaking, and lettering work.
Amana Tool Insert Carbide V-Groove CNC Router Bit, 160° x 2-5/16-Inch Diameter x 13/64-Inch Cutting Height x 1/2-Inch Shank
CA$999.99
Out of stock
SKU
RC-1109
Product Type
Insert Carbide V-Groove CNC Router Bit
Family / Category
V-Groove,Miter Fold,Signmaking &Lettering Insert CNC Bits
V-Groove Angle
160° included angle · 80° half-angle
Cutting Diameter
2-5/16 inches
Cutting Height
13/64 inch
Shank / Overall
1/2-inch shank · 2-25/32-inch overall length
Geometry / Speed
2 flutes · 2 carbide inserts · Maximum 22,000 RPM
Insert System
Included RCK-137 general-purpose inserts · Optional RCK-354 MDF inserts
Applications
160° V-grooving,miter folds,signmaking,and lettering on CNC routers
Insert V-Groove
160° CNC Router Bit
160° Insert V-Groove Bit
Amana Tool RC-1109 is a 160° insert carbide V-groove CNC router bit with a 2-5/16-inch diameter, 13/64-inch cutting height, 1/2-inch shank, 2-25/32-inch overall length, two flutes, two replaceable inserts, and a manufacturer-published maximum speed of 22,000 RPM.
160°V-Groove Angle
2-5/16 inDiameter (D)
13/64 inCutting Height (B)
22,000Maximum RPM
160° Insert V-Groove Bit
An industrial insert carbide CNC router bit designed for V-grooving, miter-fold work, signmaking, and lettering across wood, panel products, plastics, composites, and selected non-ferrous materials for engraving applications.
Amana ToolInsert Carbide1/2-Inch ShankSKU RC-1109
Built for CNC routing applications. Match the 1/2-inch shank to a compatible CNC collet, use secure workholding, confirm insert and Torx-screw seating, and observe the official 22,000 RPM maximum.
Main Product Description
Amana Tool RC-1109 is the exact Tool No. shown on its dedicated official product page in the CNC V-Groove, Miter Fold, Signmaking & Lettering Insert Carbide Router Bits family. The official specification block confirms a 160° included angle, 80° half-angle, 2-5/16-inch diameter, 13/64-inch cutting height, 1-5/32-inch B1 dimension, 1/2-inch shank, 2-25/32-inch overall length, 2-inch L1 dimension, two flutes, and two inserts.
This industrial insert tool is designed for miter-fold, signmaking, and lettering applications. Amana Tool lists wood, veneered plywood, MDF/HDF, laminate, melamine, plastics and acrylic, PVC, HDPE, composites, composite decking, epoxy resins, foam, solid surface, sign board, Xanita® board, and high-density urethane among its supported workpiece groups.
The active cutting system uses replaceable carbide inserts. RC-1109 is supplied with two RCK-137 general-purpose inserts. RCK-354 is the optional MDF insert reference, while Torx screw 67115 and Torx key 5005 are the official service hardware. The secure locking-screw system supports precise insert replacement and repeatable cutting geometry.
Technical Specifications
Insert Carbide V-Groove CNC Router Bits · SKU RC-1109
- Amana Tool
- Insert Carbide V-Groove CNC Router Bit
- RC-1109
- Insert Carbide V-Groove CNC Router Bits
- CNC V-Groove, Miter Fold, Signmaking & Lettering Insert Carbide Router Bits
- 160°
- 80°
- 2-5/16 inches
- 13/64 inch
- 1-5/32 inches
- 1 per insert
- 1/2 inch
- Overall Length (L): 2-25/32 inches · L1: 2 inches · Maximum RPM: 22,000 · Flutes: 2 · Number of Inserts: 2 · Active Cutting Material: Replaceable carbide inserts · Included Inserts: RCK-137 general-purpose inserts · 2 required · Optional MDF Inserts: RCK-354 · 2 required · 29.8 x 12 x 1.5 mm · Torx Screw: 67115 · 4 required · Torx Key: 5005 · Primary Applications: Miter folds · Signmaking · Lettering · Machine Compatibility: CNC routers with secure workholding
- Built for CNC routing applications. Match the 1/2-inch shank to a compatible CNC collet, use secure workholding, confirm insert and Torx-screw seating, and observe the official 22,000 RPM maximum.
Best Fit Applications
160° V-Grooving
Miter-Fold Machining
Signmaking and Lettering
Wood and Panel Products
Plastics and Composites
Product Highlights
Two-Flute Insert Construction
The cutter uses two replaceable carbide inserts across two flutes, combining serviceable cutting components with repeatable CNC geometry.
General-Purpose and MDF Options
Two RCK-137 general-purpose inserts are supplied, while RCK-354 provides the official optional MDF insert configuration for the same tool body.
Compatibility & Installation Notes
Confirm exact Tool No. RC-1109, a compatible 1/2-inch CNC collet, adequate cutter clearance and guarding, secure workholding, clean insert pockets, firmly seated inserts, and correctly tightened Torx hardware before operation. Observe the official 22,000 RPM maximum. RCK-137 is the included general-purpose insert reference; RCK-354 is the optional MDF insert reference; 67115 and 5005 are service hardware. Follow Amana Tool and CNC machine-manufacturer safety documentation.
160° Insert V-Groove Geometry for CNC Signmaking and Folding
Amana Tool RC-1109 combines a 160° included angle, 2-5/16-inch diameter, 13/64-inch cutting height, 1/2-inch shank, 2-25/32-inch overall length, two flutes, two carbide inserts, and a published maximum speed of 22,000 RPM.
Its replaceable insert system, included RCK-137 general-purpose inserts, optional RCK-354 MDF inserts, and broad official material list make it a serviceable CNC solution for V-grooving, miter folds, signmaking, and lettering.
