Verified 60-Degree Profile
Exact Tool No. RC-1108 combines a 60-degree V angle, 30-degree a1 angle, 1-1/16-inch diameter, and 29/32-inch cutting height.
Amana Tool Insert Carbide 60° V-Groove CNC Router Bit, 1-1/16" Diameter x 29/32" Cutting Height x 1/2" Shank
CA$999.99
Out of stock
SKU
RC-1108
Product Type
Insert Carbide 60° V-Groove CNC Router Bit
Family / Category
Insert Carbide V-Groove,Miter Fold &Signmaking CNC Router Bits
Angle / Profile
60° V-groove angle · 30° a1 angle
Diameter / Cut
1-1/16-inch diameter · 29/32-inch cutting height
Shank / Overall
1/2-inch shank · 2-15/32-inch overall length
Geometry
1 cutting edge · 1 flute · 1 replaceable insert
Insert System
Solid carbide · RCK-56 included · RCK-350 MDF insert optional
Speed
18,000 RPM published speed chart · 24,000 RPM maximum
Applications
Miter folds,signmaking,lettering,wood panels,plastics,composites and engraving
Insert Carbide 60°
V-Groove CNC Router Bit
60° V-Groove Bit
Amana Tool RC-1108 is the exact 60-degree insert-carbide V-groove CNC router bit with a 1-1/16-inch diameter, 29/32-inch cutting height, 1/2-inch shank, 2-15/32-inch overall length, one flute, one replaceable solid-carbide insert, and a manufacturer-published maximum speed of 24,000 RPM.
60°V-Groove Angle (a°)
1-1/16 inDiameter (D)
29/32 inCutting Height (B)
24,000Maximum RPM
60° V-Groove Bit
A professional single-flute CNC insert-carbide router bit for miter folds, signmaking, lettering, and compatible engraving work. The exact official Tool No. is RC-1108.
Amana ToolInsert Carbide1/2-Inch ShankSKU RC-1108
Intended for compatible CNC routing equipment with a 1/2-inch collet, secure workholding, and operation within the published 24,000 RPM maximum. The current Amana Tool V-groove speed chart lists 18,000 RPM for RC-1108.
Main Product Description
Amana Tool RC-1108 is the exact Tool No. shown on its dedicated official product page. The labelled specification block confirms a 60-degree V-groove angle, 30-degree a1 angle, 1-1/16-inch diameter, 29/32-inch cutting height, 1-1/16-inch B1 dimension, 1/2-inch shank, 2-15/32-inch overall length, and 1-3/8-inch L1 dimension.
The single-flute insert-carbide design is built for CNC miter-fold work, signmaking, and lettering. Amana Tool also lists acrylic and plastic, composites, composite decking, epoxy, foam, HDPE, laminate, melamine, MDF/HDF, PVC, sign board, solid surface, veneered plywood, wood, Xanita® Board, and high-density urethane among the compatible materials.
The current official records identify included general-purpose insert RCK-56, optional MDF insert RCK-350, Torx retaining screw 67117, and T-15 Torx key 5005. The product page publishes a maximum speed of 24,000 RPM, while the current V-groove speed chart lists 18,000 RPM.
Technical Specifications
Insert Carbide V-Groove, Miter Fold & Signmaking CNC Router Bits · SKU RC-1108
- Amana Tool
- Insert Carbide 60° V-Groove CNC Router Bit
- RC-1108
- CNC V-Groove & Signmaking Tooling
- Insert Carbide V-Groove, Miter Fold & Signmaking CNC Router Bits
- 60°
- 30°
- 1-1/16 inches
- 29/32 inch
- 1-1/16 inches
- 1
- 1/2 inch
- Overall Length (L): 2-15/32 inches · L1: 1-3/8 inches · Maximum RPM: 24,000 · Published Speed Chart RPM: 18,000 · Flutes: 1 · Number of Inserts: 1 · Active Cutting Material: Solid Carbide Insert · Included General-Purpose Insert: RCK-56 · 27 × 9 × 1.5mm · Optional MDF Insert: RCK-350 · 27 × 9 × 1.5mm · Torx Retaining Screw: 67117 · 3.5 × 0.6 × 5mm · Torx Key: 5005 · T-15
- Intended for compatible CNC routing equipment with a 1/2-inch collet, secure workholding, and operation within the published 24,000 RPM maximum. The current Amana Tool V-groove speed chart lists 18,000 RPM for RC-1108.
Best Fit Applications
Miter-Fold Joinery
Signmaking & Lettering
MDF/HDF & Veneered Plywood
Plastics, Composites & Solid Surface
Non-Ferrous Metal Engraving
Product Highlights
Current Insert System
Official records identify included RCK-56 general-purpose carbide, optional RCK-350 MDF carbide, screw 67117, and T-15 key 5005.
Broad CNC Material Coverage
Verified applications include miter folds, signmaking, lettering, wood-based panels, plastics, composites, solid surface, and engraving work.
Compatibility & Installation Notes
Confirm exact Tool No. RC-1108, a compatible 1/2-inch CNC collet, adequate cutter clearance, secure workholding, and operation within the manufacturer’s published limits. The product page lists a 24,000 RPM maximum, and the current speed chart lists 18,000 RPM for RC-1108. Amana Tool limits the listed aluminum, brass, bronze, copper, gold, silver, and carbon-fiber applications to engraving. For Xanita LightBoard panels, the manufacturer recommends the optional MDF insert. Follow all Amana Tool and CNC machine safety documentation.
Replaceable-Carbide Accuracy for 60-Degree CNC V-Grooving
Amana Tool RC-1108 combines a 60-degree V angle, 1-1/16-inch diameter, 29/32-inch cutting height, 1/2-inch shank, 2-15/32-inch overall length, one flute, and one replaceable solid-carbide insert.
The exact official page supports miter folds, signmaking, lettering, and a broad range of wood, panel, plastic, composite, foam, and solid-surface materials, with non-ferrous metals and carbon fiber limited to engraving work.
