Verified 150-Degree Profile
Exact Tool No. RC-1106 combines a 150-degree V angle, 75-degree a1 angle, 2-1/4-inch diameter, and 19/64-inch cutting height.
Amana Tool Insert Carbide 150° V-Groove CNC Router Bit, 2-1/4" Diameter x 19/64" Cutting Height x 1/2" Shank
CA$999.99
Out of stock
SKU
RC-1106
Product Type
Insert Carbide 150° V-Groove CNC Router Bit
Family / Category
Insert Carbide V-Groove,Miter Fold &Signmaking CNC Router Bits
Angle / Profile
150° V-groove angle · 75° a1 angle
Diameter / Cut
2-1/4-inch diameter · 19/64-inch cutting height
Shank / Overall
1/2-inch shank · 2-15/16-inch overall length
Geometry
1 cutting edge · 2 flutes · 2 replaceable inserts
Cutting Material
Solid carbide inserts · RCK-137 included · RCK-354 MDF inserts optional
Maximum Speed
22,000 RPM
Applications
Miter folds,signmaking,lettering,wood-based panels,plastics,composites and engraving
Insert Carbide 150°
V-Groove CNC Router Bit
150° V-Groove Bit
Amana Tool RC-1106 is the exact 150-degree insert-carbide V-groove CNC router bit with a 2-1/4-inch diameter, 19/64-inch cutting height, 1/2-inch shank, 2-15/16-inch overall length, two flutes, two replaceable carbide inserts, and a manufacturer-published maximum speed of 22,000 RPM.
150°V-Groove Angle (a°)
2-1/4 inDiameter (D)
19/64 inCutting Height (B)
22,000Maximum RPM
150° V-Groove Bit
A professional CNC insert-carbide router bit for miter folds, signmaking, lettering, and compatible engraving work. The exact official Tool No. is RC-1106.
Amana ToolInsert Carbide1/2-Inch ShankSKU RC-1106
Intended for compatible CNC routing equipment with a 1/2-inch collet, secure workholding, and operation within the published 22,000 RPM limit. Listed metals and carbon fiber are approved for engraving only.
Main Product Description
Amana Tool RC-1106 is the exact Tool No. shown on its dedicated official product page. The labelled specification block confirms a 150-degree V-groove angle, 75-degree a1 angle, 2-1/4-inch diameter, 19/64-inch cutting height, 1-3/16-inch B1 dimension, 1/2-inch shank, 2-15/16-inch overall length, and 2-inch L1 dimension.
The insert-carbide design is built for CNC miter-fold work, signmaking, and lettering. Amana Tool also lists acrylic and plastic, composites, composite decking, epoxy, foam, HDPE, laminate, melamine, MDF/HDF, PVC, sign board, solid surface, veneered plywood, wood, Xanita® Board, and high-density urethane among the compatible materials.
The official replacement-parts record identifies included general-purpose carbide inserts RCK-137, optional MDF inserts RCK-354, Torx screw 67115, and Torx key 5005. The page publishes a maximum speed of 22,000 RPM and limits the listed non-ferrous metals and carbon fiber to engraving applications.
Technical Specifications
Insert Carbide V-Groove, Miter Fold & Signmaking CNC Router Bits · SKU RC-1106
- Amana Tool
- Insert Carbide 150° V-Groove CNC Router Bit
- RC-1106
- CNC V-Groove & Signmaking Tooling
- Insert Carbide V-Groove, Miter Fold & Signmaking CNC Router Bits
- 150°
- 75°
- 2-1/4 inches
- 19/64 inch
- 1-3/16 inches
- 1
- 1/2 inch
- Overall Length (L): 2-15/16 inches · L1: 2 inches · Maximum RPM: 22,000 · Flutes: 2 · Number of Inserts: 2 · Active Cutting Material: Solid Carbide Inserts · Included Inserts: RCK-137 General Purpose · 2 Required · Optional MDF Inserts: RCK-354 · 2 Required · Torx Screw: 67115 · 4 Required · Torx Key: 5005
- Intended for compatible CNC routing equipment with a 1/2-inch collet, secure workholding, and operation within the published 22,000 RPM limit. Listed metals and carbon fiber are approved for engraving only.
Best Fit Applications
Miter-Fold Joinery
Signmaking & Lettering
MDF/HDF & Veneered Plywood
Plastics, Composites & Solid Surface
Non-Ferrous Metal Engraving
Product Highlights
Replaceable Carbide Insert System
The official parts table identifies two included RCK-137 general-purpose inserts and optional RCK-354 MDF inserts for this exact tool.
Broad CNC Material Coverage
Verified applications include miter folds, signmaking, lettering, wood-based panels, plastics, composites, solid surface, and engraving work.
Compatibility & Installation Notes
Confirm exact Tool No. RC-1106, a compatible 1/2-inch CNC collet, adequate cutter clearance, secure workholding, and operation at or below the published 22,000 RPM maximum. Amana Tool limits the listed aluminum, brass, bronze, copper, gold, silver, and carbon-fiber applications to engraving. For Xanita LightBoard panels, the manufacturer recommends the optional MDF inserts. Follow all Amana Tool and CNC machine safety documentation.
Replaceable-Carbide Accuracy for 150-Degree CNC V-Grooving
Amana Tool RC-1106 combines a 150-degree V angle, 2-1/4-inch diameter, 19/64-inch cutting height, 1/2-inch shank, 2-15/16-inch overall length, two flutes, and two replaceable solid-carbide inserts.
The exact official page supports miter folds, signmaking, lettering, and a broad range of wood, panel, plastic, composite, foam, and solid-surface materials, with non-ferrous metals and carbon fiber limited to engraving work.
