Wide Adjustable Angle Range
RC-2370 adjusts from -45° through +90° for chamfer cuts across a broad range of panel and profile work.
Amana Tool Insert Adjustable Chamfer CNC Router Bit, 3-1/8-Inch Diameter x 40mm Cutting Height x 3/4-Inch Shank
CA$999.99
Out of stock
SKU
RC-2370
Product Type
Insert Adjustable Chamfer CNC Router Bit
Family / Category
Adjustable Chamfer Insert CNC Router Bits
Angle Range
-45° to +90° · 7.5° indexed adjustment
Cutting Diameter
3-1/8 inches
Cutting Height
40 mm
Shank / Overall
3/4-inch shank · 3-11/16-inch overall length
Geometry / Speed
2 flutes · Maximum 12,000 RPM
Insert System
RCK-40 pair · 40 × 12 × 1.5 mm solid carbide inserts
Applications
Adjustable chamfering in wood,man-made boards,laminate,melamine,plywood,plastic,acrylic,and UHMWPE
Insert Adjustable
Chamfer CNC Router Bit
Adjustable Chamfer Insert Bit
Amana Tool RC-2370 is an adjustable chamfer insert CNC router bit with a 3-1/8-inch diameter, 40 mm cutting height, 3/4-inch shank, 3-11/16-inch overall length, two cutting flutes, indexed 7.5-degree angle adjustment from -45° through +90°, and a published maximum speed of 12,000 RPM.
-45° to +90°Adjustable Angle Range
3-1/8 inDiameter (D)
40 mmCutting Height (B)
12,000Maximum RPM
Adjustable Chamfer Insert Bit
A two-flute insert router bit for producing chamfer cuts at varied angles. Its notched scale indexes the cutting angle in 7.5° steps across the published -45° to +90° range.
Amana ToolSolid Carbide Inserts3/4-Inch ShankSKU RC-2370
Amana Tool specifies RC-2370 for routers and machining centers with CNC control. Match the 3/4-inch shank to a compatible holder or collet and observe the official 12,000 RPM maximum.
Main Product Description
Amana Tool RC-2370 is the exact Tool No. shown on its dedicated official product page in the Adjustable Chamfer Insert CNC Router Bits family. The labelled specification block confirms a 3-1/8-inch diameter, 40 mm cutting height, 3/4-inch shank, 3-11/16-inch overall length, and a maximum speed of 12,000 RPM.
The insert router bit is complete with two cutting flutes and is intended for producing chamfer cuts at varied angles. A notched scale indexes the cutting angle in 7.5° steps from -45° through +90°, while the published bit tolerance is ±0.5°. Amana Tool identifies use on routers and machining centers with CNC control.
The official material list includes hardwood, softwood, man-made boards, plastic and acrylic, UHMWPE, laminate, MDF/HDF, melamine, and plywood. The active cutting components are replaceable solid carbide inserts. The official replacement insert is RCK-40, supplied as a pair of 40 x 12 x 1.5 mm solid carbide inserts for Tool No. RC-2370.
Technical Specifications
Adjustable Chamfer Insert CNC Router Bits · SKU RC-2370
- Amana Tool
- Insert Adjustable Chamfer CNC Router Bit
- RC-2370
- Adjustable Chamfer Insert CNC Router Bits
- Adjustable Chamfer Insert CNC Router Bits
- -45° to +90°
- 7.5° notched-scale steps
- ±0.5°
- 3-1/8 inches
- 40 mm
- 3/4 inch
- 3-11/16 inches
- Flutes: 2 · Active Cutting Material: Replaceable solid carbide inserts · Maximum RPM: 12,000 · Replacement Inserts: RCK-40 · Pair · 40 x 12 x 1.5 mm · Replacement Hardware: WB-50 · 67189 · 67183 · 5020 · 5024 · Machine Compatibility: Routers and machining centers with CNC control · Workpiece Materials: Hardwood, softwood, man-made boards, plastic/acrylic, UHMWPE, laminate, MDF/HDF, melamine, plywood
- Amana Tool specifies RC-2370 for routers and machining centers with CNC control. Match the 3/4-inch shank to a compatible holder or collet and observe the official 12,000 RPM maximum.
Best Fit Applications
Variable-Angle Chamfering
Hardwood and Softwood
MDF, HDF and Plywood
Laminate and Melamine
Plastic, Acrylic and UHMWPE
Product Highlights
Indexed 7.5-Degree Adjustment
The notched scale provides published 7.5° angle steps, with a manufacturer-stated bit tolerance of ±0.5°.
Replaceable Carbide Insert System
Two cutting flutes use replaceable solid carbide inserts, with RCK-40 specified as the exact replacement pair.
Compatibility & Installation Notes
Confirm exact Tool No. RC-2370, a compatible 3/4-inch holder or collet, adequate cutter clearance and guarding, the selected angle setting, secure insert and hardware seating, and the official maximum speed of 12,000 RPM. RCK-40 is the exact replacement insert pair; WB-50, 67189, 67183, 5020, and 5024 are official replacement-hardware references. Follow Amana Tool and machine-manufacturer safety documentation for router or CNC machining-center use.
Indexed Chamfer Geometry From -45° Through +90°
Amana Tool RC-2370 combines a 3-1/8-inch diameter, 40 mm cutting height, 3/4-inch shank, 3-11/16-inch overall length, two cutting flutes, indexed 7.5-degree adjustment, and a published maximum speed of 12,000 RPM.
Its replaceable solid carbide insert system and broad official material list support adjustable chamfer work on routers and machining centers with CNC control.
