Extended Tooling Life
Industrial sub-micron solid carbide formulation yields flawless surface cutting and delivers a service span at least double that of non-insert detailing bits.
Amana Tool In-Groove Solid Carbide Corner Round 3/32 Inch Radius Insert Engraving Knife
CA$999.99
Out of stock
SKU
RCK-412
Product Type
Corner Round Engraving Insert Knife
Family / Category
In-Groove CNC Insert Engraving System
Radius (R)
3/32 inch
Cutting Height (B)
8mm (5/16 inch)
Plunge Feed Rate
80 Inch/Min
Cutting Material
Solid Carbide
Compatibility
Fits In-Groove Tool Bodies RC-1075,RC-1076,RC-1077,RC-1078
Applications
Precision engraving,edge detailing,and signmaking in MDF,laminates,acrylics,and woods
Solid Carbide
Corner Round Insert Engraving Knife
Insert Knife
Amana Tool RCK-412 is the exact solid carbide corner round engraving insert knife engineered for the industrial In-Groove™ engraving system, featuring a 3/32-inch radius, 8mm (5/16-inch) cutting height, and a factory-calibrated 80 inch/min plunge feed rate.
3/32 inRadius (R)
8mmCutting Height (B)
80 IPMPlunge Feed
In-GrooveSystem Fit
Insert Knife
An industrial-grade replaceable solid carbide knife for detail etching and corner rounding. The exact official SKU is RCK-412, nested in the In-Groove CNC Insert Engraving Tool Body system.
Amana ToolSolid CarbideInsert ComponentSKU RCK-412
Designed exclusively for Amana Tool CNC In-Groove tool bodies including RC-1075 (1/4" shank), RC-1076 (1/2" shank), RC-1077 (6mm shank), and RC-1078 (12mm shank). Interchanges quickly while mounted in the CNC machine to eliminate downtime.
Main Product Description
Amana Tool RCK-412 is the exact replacement profile insert knife detailed on its dedicated official product page. Engineered as part of the innovative In-Groove™ Insert Engraving System, this single tool component provides a precision 3/32-inch radius corner round configuration combined with an 8mm (5/16-inch) cutting height.
Constructed entirely from premium industrial solid carbide, these specialized insert knives are designed to produce exceptionally crisp, clean cuts. Testing confirms they last at least twice as long as traditional standard solid carbide engraving bits, making them a highly cost-effective choice for modern high-production panel processing and manufacturing workflows.
The unique configuration allows you to instantly interchange inserts while the master tool body remains securely clamped inside the CNC spindle. This design maintains exact centerline tracking, eliminates the need for repeated tool length re-zeroing, and entirely mitigates operational machine downtime.
Technical Specifications
In-Groove System · SKU RCK-412
- Amana Tool
- Corner Round Engraving Insert Knife
- RCK-412
- In-Groove Insert Engraving System
- In-Groove CNC Insert Engraving Tool Body & Replacement Knives
- 3/32 inch
- 8mm (5/16 inch)
- 80 Inch/Min
- Solid Carbide
- RC-1075, RC-1076, RC-1077, RC-1078
- Precision Etching & Detailing
- 3/32 in
- Laminates & Veneers · MDF & Solid Surface · Plastics & Acrylics
- Designed exclusively for Amana Tool CNC In-Groove tool bodies including RC-1075 (1/4" shank), RC-1076 (1/2" shank), RC-1077 (6mm shank), and RC-1078 (12mm shank). Interchanges quickly while mounted in the CNC machine to eliminate downtime.
Best Fit Applications
Laminates & Veneers
MDF & Solid Surface
Plastics & Acrylics
Hardwoods & Softwoods
Phenolic & Carbon Fiber
Product Highlights
Zero Spindle Downtime
Engineered to slide precisely into position and lock rigidly while the toolholder body remains inside the machine spindle, protecting registration accuracy.
Crisp Fine-Line Etching
Expertly optimized geometric relief tracking enables micro-grooving and fine profiling completely free of vibration artifacts or edge fraying.
Compatibility & Installation Notes
This deliverable comprises the single replacement insert knife only; master In-Groove CNC tool bodies are sold separately. Verify that the tool nesting pocket is completely clear of micro-debris and resin buildup before torqueing the retention mechanism. Always ensure your spindle parameters match the official Amana Tool feed tables for point-roundover and corner-round components.
Precision Engineered
Amana Tool RCK-412 stands as an authentic industrial component of the flexible In-Groove system. By deploying solid carbide engineering to eliminate component replacement waste and machine tuning overhead, it serves as an indispensable solution for modern CNC routing operations demanding accurate fine-line profiling across diverse engineered substrates.
Amana Tool RCK-412 is the exact replacement profile insert knife detailed on its dedicated official product page. Engineered as part of the innovative In-Groove™ Insert Engraving System, this single tool component provides a precision 3/32-inch radius corner round configuration combined with an 8mm (5/16-inch) cutting height.
