Verified Two-in-One Profile
RC-49496 combines a 1/8-inch corner-round radius with a verified 45-degree bevel profile in one In-Tech™ tool.
Amana Tool In-Tech™ Insert-Carbide Corner Round / Bevel Router Bit, 1/8-Inch Radius x 1-Inch Diameter x 3/8-Inch Cutting Height x 1/4-Inch Shank
CA$999.99
Out of stock
SKU
RC-49496
Product Type
Insert-Carbide Corner Round / Bevel Router Bit
Family / Category
In-Tech™ Corner Rounding Insert Router Bits
Profile
2-in-1 corner round or 45° bevel · 1/8-inch radius
Diameter / D1
1-inch diameter · 1/2-inch D1
Cutting Height
3/8 inch
Shank / Overall
1/4-inch shank · 2-3/16-inch overall length
Cutting System
2 flutes · Replaceable solid-carbide inserts
Replacement Inserts
RCK-268 · Pair of two profile inserts
Applications
Wood,MDF/HDF,chipboard,acrylic,laminate,melamine,and plywood
In-Tech™ Insert Carbide
1/8-Inch Corner Round / Bevel
2-in-1 Profile Bit
Amana Tool RC-49496 is the exact two-in-one In-Tech™ corner-round or bevel router bit with a 45-degree angle, 1/8-inch radius, 1-inch diameter, 3/8-inch cutting height, 1/4-inch shank, 2-3/16-inch overall length, and two solid-carbide insert flutes.
1/8 inRadius (R)
1 inDiameter (D)
3/8 inCutting Height (B)
1/4 inShank (d)
2-in-1 Profile Bit
An In-Tech™ insert-carbide router bit that produces either a 1/8-inch corner round or a 45-degree bevel. The exact official Tool No. is RC-49496.
Amana ToolIn-Tech™Solid-Carbide InsertsSKU RC-49496
For compatible routing equipment with a 1/4-inch collet. Replacement profile insert pair RCK-268 and guide bearing 47706 must be matched by exact code.
Main Product Description
Amana Tool RC-49496 is the exact Tool No. shown on its dedicated official product page. The labelled specification block confirms a 45-degree angle, 1-inch diameter, 1/2-inch D1 dimension, 1/8-inch radius, 3/8-inch cutting height, 1/4-inch shank, 2-3/16-inch overall length, and two flutes.
The published type is a two-in-one corner-round or bevel profile. Amana Tool's In-Tech™ system uses replaceable solid-carbide inserts so the tool dimensions, cutting quality, and accuracy remain consistent without resharpening the original profile.
The exact page lists MDF, chipboard, softwood, hardwood, acrylic, laminate, MDF/HDF, melamine, and plywood as suitable materials. Its service references are solid-carbide replacement insert pair RCK-268, bearing 47706, insert screws 67013, top screw 67099, and washer 67098.
Technical Specifications
In-Tech™ Corner Rounding Insert Router Bits · SKU RC-49496
- Amana Tool
- Insert-Carbide Corner Round / Bevel Router Bit
- RC-49496
- In-Tech™ Corner Rounding Insert Router Bits
- In-Tech™ Corner Rounding Insert Router Bits
- 45°
- 1 inch
- 1/2 inch
- 1/8 inch
- 3/8 inch
- 1/4 inch
- 2-3/16 inches
- Type: 2-in-1 Corner Round or Bevel · Flutes: 2 · Active Cutting Material: Solid-Carbide Inserts · Replacement Insert Pair: RCK-268 · 2 Inserts · Replacement Bearing: 47706 · Replacement Insert Screws: 67013 · 2 Required · Replacement Top Screw: 67099 · Replacement Washer: 67098 · Workpiece Materials: MDF · Chipboard · Softwood · Hardwood · Acrylic · Laminate · MDF/HDF · Melamine · Plywood
- For compatible routing equipment with a 1/4-inch collet. Replacement profile insert pair RCK-268 and guide bearing 47706 must be matched by exact code.
Best Fit Applications
1/8-Inch Corner Rounding
45-Degree Edge Beveling
MDF/HDF & Chipboard
Hardwood & Softwood
Acrylic, Laminate, Melamine & Plywood
Product Highlights
Replaceable Solid-Carbide Inserts
The two-flute system uses solid-carbide profile inserts, with exact replacement pair RCK-268 specified for RC-49496.
Consistent Profile Accuracy
Replacing worn inserts preserves the published tool dimensions, cutting quality, and profile accuracy without resharpening.
Compatibility & Installation Notes
Confirm exact Tool No. RC-49496, a compatible 1/4-inch collet, cutter clearance, workholding, guarding, and the required corner-round or bevel setup. Match solid-carbide replacement insert pair RCK-268, bearing 47706, insert screws 67013, top screw 67099, and washer 67098 by exact code. Replacement inserts are supplied as a pair. Follow all Amana Tool and machine-manufacturer safety documentation.
Two Verified Edge Profiles with Replaceable Solid-Carbide Inserts
Amana Tool RC-49496 combines a 45-degree angle, 1-inch diameter, 1/8-inch radius, 3/8-inch cutting height, 1/4-inch shank, 2-3/16-inch overall length, and two flutes.
Its In-Tech™ insert system supports consistent corner-round or bevel profiles across the exact wood, panel-product, laminate, melamine, acrylic, and plywood materials published for this SKU.
