Quick Insert Interchange
The In-Groove™ system is engineered so compatible inserts can be changed while the RC-1075 body remains mounted in the CNC machine.
Amana Tool In-Groove™ CNC Insert Engraving Tool Body, 1/4-Inch Shank
CA$999.99
Out of stock
SKU
RC-1075
Product Type
CNC Insert Engraving Tool Body
Family / Category
In-Groove™ CNC Insert Engraving System
Configuration
Tool body only · Cutting inserts sold separately
Shank
1/4 inch
Overall Length
2-1/2 inches
Maximum Speed
24,000 RPM
Cutting Inserts
Compatible In-Groove™ solid-carbide inserts
Service Parts
Hex screw 67127 · Hex key 5004
Applications
CNC engraving,etching,cutting,and profile-specific work
CNC In-Groove™
Insert Engraving Tool Body
Engraving Tool Body
Amana Tool RC-1075 is the exact 1/4-inch-shank CNC In-Groove™ insert engraving tool body with a 2-1/2-inch overall length. The body accepts separately sold solid-carbide inserts and is manufacturer-rated to a maximum of 24,000 RPM.
1/4 inShank (d)
2-1/2 inOverall Length (L)
24,000Maximum RPM
Body OnlyInserts Sold Separately
Engraving Tool Body
A balanced CNC tool body engineered for quick interchange of compatible In-Groove™ solid-carbide inserts while the body remains mounted in the CNC machine. The exact official Tool No. is RC-1075.
Amana ToolIn-Groove™1/4-Inch ShankSKU RC-1075
For compatible CNC routing equipment with a 1/4-inch collet and the correct separately sold In-Groove™ insert. Select the official speed and feed chart that matches the installed insert profile.
Main Product Description
Amana Tool RC-1075 is the exact Tool No. shown on its dedicated official product page. The labelled specification block confirms a 1/4-inch shank, 2-1/2-inch overall length, and tool-body-only configuration. Solid-carbide cutting inserts are sold separately.
Amana Tool engineered the In-Groove™ body so compatible inserts can be interchanged while the tool body remains mounted in the CNC machine. The published design intent is to reduce downtime, maintain consistent cutting accuracy, and provide balanced operation with virtually no vibration.
The system is presented as an engraving and etching solution for laminated materials, veneers, MDF, plastics, softwood, hardwood, phenolic, solid surface, carbon fiber, PCB board, HDPE, PMMA, Corian, Acrylic Stone, and other officially listed materials. The service-parts table identifies hex screw 67127 and hex key 5004.
Technical Specifications
In-Groove™ CNC Insert Engraving System · SKU RC-1075
- Amana Tool
- CNC Insert Engraving Tool Body
- RC-1075
- In-Groove™ CNC Insert Engraving System
- In-Groove™ CNC Insert Engraving System
- 1/4 inch
- 2-1/2 inches
- Tool Body · Select Compatible Inserts Separately
- Tool Body Only
- Solid Carbide · Sold Separately
- CNC Router
- 24,000
- Replacement Hex Screw: 67127 · Hex Key: 5004 · Primary Application: Cutting, Engraving, and Etching · Published Feed Resources: V-Tip · Profile · Straight/Core Box · In-Plastic Chamfering Charts · Material Groups: Laminates · Veneers · MDF · Plastics · Wood · Phenolic · Solid Surface · Carbon Fiber · Additional Materials: PCB Board · HDPE · PMMA · Corian · Acrylic Stone · Coroplast® · Conditional Metal Use: Aluminum, Brass, and Copper with Compatible V-Tip Inserts
- For compatible CNC routing equipment with a 1/4-inch collet and the correct separately sold In-Groove™ insert. Select the official speed and feed chart that matches the installed insert profile.
Best Fit Applications
CNC Engraving & Etching
Laminates & Veneers
Plastics, PMMA & HDPE
Hardwood, Softwood & MDF
Phenolic, Solid Surface & Carbon Fiber
Product Highlights
Solid-Carbide Insert Platform
Separately sold solid-carbide inserts provide the active cutting profiles while one verified 1/4-inch-shank body supports the system.
Balanced CNC Tool Body
Amana Tool identifies the body as expertly balanced for virtually no vibration and publishes a maximum speed of 24,000 RPM.
Compatibility & Installation Notes
RC-1075 is the 1/4-inch-shank tool body only; cutting inserts are sold separately. Confirm the exact compatible In-Groove™ insert, a matching 1/4-inch CNC collet, cutter clearance, workholding, and guarding. Use the official speed and feed chart for the installed profile and do not exceed 24,000 RPM. Aluminum, brass, and copper engraving is limited to compatible V-Tip inserts. Match service parts 67127 and 5004 by exact code and follow all Amana Tool and machine-manufacturer safety documentation.
One Balanced CNC Body for the In-Groove™ Solid-Carbide Insert System
Amana Tool RC-1075 combines a 1/4-inch shank, 2-1/2-inch overall length, quick insert interchange, balanced CNC construction, and a manufacturer-published maximum speed of 24,000 RPM.
The body supports separately sold In-Groove™ solid-carbide inserts for engraving, etching, and profile-specific work across the exact material groups published for the system.
