Extended Tool Life
Industrial sub-micrograin solid carbide provides extreme resistance to abrasive materials, outlasting traditional engraving cutters two-to-one.
Amana Tool In-Groove Solid Carbide 90 Deg x 0.020 Inch V-Tip Width Engraving Insert Knife
CA$999.99
Out of stock
SKU
RCK-392
Product Type
Solid Carbide Insert V-Tip Engraving Knife
Family / Category
In-Groove™ CNC Insert Engraving Tool System
V-Angle
90°
Tip Width
0.020 inch (0.5mm)
Cutting Height
4mm (5/32")
Plunge Feed
80 Inch/Min
Cutting Material
Solid Carbide
System Compatibility
Fits tool bodies RC-1075,RC-1076,RC-1077,RC-1078
Applications
Precision detail engraving,signmaking,and etching on plastics,woods,acrylics,and non-ferrous metals
Solid Carbide 90° V-Tip
RCK-392
Amana Tool
Industrial-grade V-tip insert engraving knife engineered for crisp, clean precision etching across diverse materials. Part of the innovative multi-functional In-Groove™ system designed to eliminate production downtime.
90°V-Angle
0.020"Tip Width
5/32"Cut Height
80 IPMPlunge Feed
RCK-392
Solid Carbide Insert 90 Deg x 0.020 Inch V-Tip Width Engraving Knife
Solid CarbideCNC RatedAmana ToolRCK-392
The RCK-392 replacement insert knife must be used exclusively with official Amana Tool CNC In-Groove™ Insert Engraving Tool Bodies. Compatible bodies include RC-1075 (1/4" Shank), RC-1076 (1/2" Shank), RC-1077 (6mm Shank), and RC-1078 (12mm Shank). Ensure the insert pocket is completely cleared of fine chips and debris before tightening the locking mechanism to avoid deflection or insert breakage.
Main Product Description
The Amana Tool RCK-392 is a premium solid carbide insert knife engineered for the industrial In-Groove™ Insert Engraving System. This tool configuration features an industrial quality insert knife that produces exceptionally crisp, clean cuts and lasts at least twice as long as standard solid carbide bits.
Engineered specifically for CNC machinery, the In-Groove™ architecture permits operators to quickly interchange inserts while the tool body remains securely clamped in the router collet. This eliminates nested repositioning steps, reduces machining downtime, and safeguards absolute cutting reference accuracy across long production cycles.
Optimize your signmaking, nesting, and detail-etching manufacturing workflows with the Amana Tool In-Groove™ system. By delivering clean edges on composite panels, hardwood laminates, and non-ferrous metals alongside a smart indexing insert assembly, the RCK-392 gives industrial production environments the ultimate competitive edge.
Technical Specifications
Technical Specs
- Amana Tool
- RCK-392
- RCK-392
- In-Groove™ Engraving System
- Amana Tool
- In-Groove™
- Solid Carbide
- 90°
- 0.020" (0.5mm)
- 4mm (5/32")
- 80 Inch/Min
- 90°
- Plastics & Acrylic · MDF & Laminated Panels · Hard & Soft Woods
- The RCK-392 replacement insert knife must be used exclusively with official Amana Tool CNC In-Groove™ Insert Engraving Tool Bodies. Compatible bodies include RC-1075 (1/4" Shank), RC-1076 (1/2" Shank), RC-1077 (6mm Shank), and RC-1078 (12mm Shank). Ensure the insert pocket is completely cleared of fine chips and debris before tightening the locking mechanism to avoid deflection or insert breakage.
Best Fit Applications
Plastics & Acrylic
MDF & Laminated Panels
Hard & Soft Woods
Aluminum, Brass & Copper
PCB Boards & Solid Surface
Product Highlights
Zero-Downtime Swaps
Interchange your insert profiles immediately on-machine without removing the tool body, preserving zero-point registration precisely.
Ultra-Crisp Etching
The specialized 90° geometry paired with a refined 0.020" V-tip width guarantees high-definition detail rendering on metals and polymers.
Compatibility & System Installation Notes
The RCK-392 replacement insert knife must be used exclusively with official Amana Tool CNC In-Groove™ Insert Engraving Tool Bodies. Compatible bodies include RC-1075 (1/4" Shank), RC-1076 (1/2" Shank), RC-1077 (6mm Shank), and RC-1078 (12mm Shank). Ensure the insert pocket is completely cleared of fine chips and debris before tightening the locking mechanism to avoid deflection or insert breakage.
Uncompromised CNC Precision
Optimize your signmaking, nesting, and detail-etching manufacturing workflows with the Amana Tool In-Groove™ system. By delivering clean edges on composite panels, hardwood laminates, and non-ferrous metals alongside a smart indexing insert assembly, the RCK-392 gives industrial production environments the ultimate competitive edge.
The Amana Tool RCK-392 is a premium solid carbide insert knife engineered for the industrial In-Groove™ Insert Engraving System. This tool configuration features an industrial quality insert knife that produces exceptionally crisp, clean cuts and lasts at least twice as long as standard solid carbide bits.
