Seven Verified Profiles
The set combines three 30° V-tips, one 60° V-tip, a straight insert, a corner-round insert, and a core-box insert in one compact system.
Amana Tool In-Groove™ 8-Piece CNC Insert Engraving Router Bit Set, 1/4" Shank
CA$999.99
Out of stock
SKU
AMS-210
Product Type
8-Piece In-Groove™ CNC Insert Engraving Set
Family / Category
In-Groove™ CNC Insert Engraving System
Set Contents
1 engraving tool body · 7 interchangeable inserts
Included Inserts
RCK-360 · RCK-361 · RCK-362 · RCK-380 · RCK-400 · RCK-412 · RCK-420
Profile Range
30° and 60° V-tips · Straight · Corner round · Core box
Shank / Overall
1/4-inch shank · 2-1/2-inch overall length
Cutting Material
Industrial solid-carbide inserts
System Feature
Profiles interchange while the CNC tool body remains mounted
Applications
Engraving,etching,lettering,laminates,MDF,wood,plastics,solid surface and composites
8-Piece In-Groove™
Insert Engraving Set
In-Groove™ Engraving
Amana Tool AMS-210 combines one 1/4-inch-shank In-Groove™ CNC engraving tool body with seven interchangeable solid-carbide cutting inserts. The set covers straight, corner-round, core-box, 30° V-tip, and 60° V-tip profiles for detailed engraving, etching, lettering, and precision profile work across wood, laminates, plastics, composites, and selected non-ferrous materials.
8 PiecesBody Plus 7 Inserts
7 ProfilesInterchangeable Carbide
1/4 inShank Diameter
2-1/2 inOverall Length
In-Groove™ Engraving
An industrial CNC insert system that allows the supplied solid-carbide profiles to be exchanged while the tool body remains mounted, helping reduce downtime and maintain consistent cutting position. The exact official Tool No. is AMS-210.
Amana Tool8-Piece SetInsert CarbideSKU AMS-210
Intended for compatible CNC routing equipment with a 1/4-inch collet and secure workholding. Use the official In-Groove™ speed-and-feed chart that corresponds to the installed V-tip, corner-round, straight, or core-box insert profile.
Main Product Description
Amana Tool AMS-210 is the exact eight-piece In-Groove™ set shown on its dedicated official product page. The package contains one 1/4-inch-shank engraving tool body and seven industrial solid-carbide inserts: RCK-360, RCK-361, RCK-362, RCK-380, RCK-400, RCK-412, and RCK-420.
The included profile range consists of three 30° V-tip inserts with 0.005-, 0.010-, and 0.020-inch tip widths; one 60° V-tip insert with a 0.005-inch tip width; one 1/8-inch straight profile; one 3/32-inch-radius corner-round profile; and one 1/16-inch-radius core-box profile.
Amana Tool designed the In-Groove™ system so inserts can be exchanged while the tool body remains mounted in the CNC machine. The balanced body supports low-vibration cutting, while the solid-carbide inserts produce crisp engraving and are specified for laminated materials, veneers, MDF, plastics, softwood, hardwood, phenolic, solid surface, carbon fiber, PCB board, HDPE, and marine building material. V-tip profiles may also engrave aluminum, brass, and copper.
Technical Specifications
In-Groove™ CNC Engraving · SKU AMS-210
- Amana Tool
- 8-Piece In-Groove™ Insert Engraving Tool Body & Solid-Carbide Insert Set
- AMS-210
- In-Groove™ CNC Engraving System
- In-Groove™ CNC Insert Engraving Tool Body & Replacement Inserts
- 8 · One Tool Body + Seven Inserts
- 1/4 inch
- 2-1/2 inches
- RCK-360 · 30° V-Tip · 0.005 in Tip Width
- RCK-361 · 30° V-Tip · 0.010 in Tip Width
- RCK-362 · 30° V-Tip · 0.020 in Tip Width
- RCK-380 · 60° V-Tip · 0.005 in Tip Width
- Included Insert 5: RCK-400 · 1/8 in Straight · 5mm (3/16 in) Cutting Height · Included Insert 6: RCK-412 · 3/32 in Corner Round · 8mm (5/16 in) Cutting Height · Included Insert 7: RCK-420 · 1/16 in Core Box · 5mm (3/16 in) Cutting Height · Active Cutting Material: Industrial Solid-Carbide Inserts · Digital Tool Support: Vectric-Compatible Tool File and Official DXF/PDF Profiles Available
- Intended for compatible CNC routing equipment with a 1/4-inch collet and secure workholding. Use the official In-Groove™ speed-and-feed chart that corresponds to the installed V-tip, corner-round, straight, or core-box insert profile.
Best Fit Applications
CNC Engraving & Etching
Lettering & Detailed Sign Work
Laminates, Veneers & MDF
Plastics, Solid Surface & HDPE
Wood, Phenolic & Composites
Product Highlights
Fast Insert Changes
Interchangeable profiles can be changed while the tool body remains mounted, reducing setup interruption and helping preserve consistent cutting position.
Broad Material Coverage
The official application range spans wood products, laminates, plastics, phenolic, solid surface, carbon fiber, PCB board, HDPE, and marine panels.
Compatibility & Installation Notes
Confirm exact set SKU AMS-210, a compatible 1/4-inch CNC collet, proper insert seating, secure workholding, and adequate clearance for the installed profile. Match operating parameters to the official In-Groove™ chart for the selected V-tip, corner-round, straight, or core-box insert. Amana Tool limits aluminum, brass, and copper use to compatible V-tip engraving profiles. Follow all Amana Tool and CNC machine safety documentation.
One CNC Body, Seven Solid-Carbide Engraving Profiles
Amana Tool AMS-210 packages the 1/4-inch-shank In-Groove™ system with seven verified solid-carbide inserts for fine engraving, lettering, etching, and profile work.
Its interchangeable insert architecture, balanced CNC body, broad workpiece coverage, and official digital profile support make the set a versatile engraving platform for production and custom CNC applications.
