Wide Adjustable Angle Range
Exact Tool No. RC-2375 adjusts from -45° through +90° for chamfer, rabbet, bevel, and spoilboard profiles.
Amana Tool In-Bevel™ Insert Adjustable Chamfer Router Bit, 2-Inch Diameter x 31/32-Inch Cutting Height x 1/2-Inch Shank
CA$999.99
Out of stock
SKU
RC-2375
Product Type
In-Bevel™ Insert Adjustable Chamfer Router Bit
Family / Category
Adjustable Chamfer Insert Router Bits
Angle Range
-45° to +90° · 15° click-stop increments
Cutting Diameter
2 inches
Cutting Height
31/32 inch
Shank / Overall
1/2-inch shank · 2-13/16-inch overall length
Geometry / Speed
2 flutes · Maximum 16,000 RPM
Insert System
RCK-460 general-purpose inserts · Optional RCK-462 MDF-grade inserts
Applications
Chamfer,rabbet,bevel,and spoilboard cuts on CNC machines,handheld routers,and router tables
In-Bevel™ Insert
Adjustable Chamfer Router Bit
Adjustable Chamfer Bit
Amana Tool RC-2375 is the exact In-Bevel™ adjustable chamfer insert router bit with a -45° to +90° angle range, 2-inch diameter, 31/32-inch cutting height, 1/2-inch shank, 2-13/16-inch overall length, two cutting flutes, and a manufacturer-published maximum speed of 16,000 RPM.
-45° to +90°Adjustable Angle Range
2 inDiameter (D)
31/32 inCutting Height (B)
16,000Maximum RPM
Adjustable Chamfer Bit
A two-flute insert router bit for producing adjustable chamfer, rabbet, bevel, and spoilboard cuts. Its notched angle scale provides click-stops at 15-degree intervals.
Amana ToolInsert Carbide1/2-Inch ShankSKU RC-2375
Amana Tool identifies RC-2375 for CNC machines, handheld routers, and router tables. Match the 1/2-inch shank to a compatible collet and observe the official 16,000 RPM maximum.
Main Product Description
Amana Tool RC-2375 is the exact Tool No. shown on its dedicated official product page. The labelled specification block confirms a -45° to +90° adjustable angle range, 2-inch diameter, 25 mm (63/64-inch) D1 dimension, 31/32-inch cutting height, 1/2-inch shank, 2-13/16-inch overall length, 11.5 mm (29/64-inch) D2 dimension, and a maximum speed of 16,000 RPM.
The In-Bevel™ system is suitable for chamfer, rabbet, bevel, and spoilboard cuts at varied angles. Amana Tool identifies use in softwood, hardwood, man-made boards, plastic and acrylic, UHMWPE, laminate, MDF/HDF, melamine, and plywood, with compatibility for CNC machines, handheld routers, and router tables.
The two-flute body uses coated, double-edge replaceable inserts that can be rotated to present a fresh cutting edge. The exact specification identifies two RCK-460 general-purpose inserts, optional RCK-462 MDF-grade inserts, screw 67133, insert screw key 5001, and adjustment screw key 5003. The angle dial indexes every 15° and the published bit tolerance is ±0.5°.
Technical Specifications
Adjustable Chamfer Insert Router Bits · SKU RC-2375
- Amana Tool
- In-Bevel™ Insert Adjustable Chamfer Router Bit
- RC-2375
- Adjustable Chamfer Insert Router Bits
- Adjustable Chamfer Insert Router Bits
- -45° to +90°
- 2 inches
- 25 mm (63/64 inch)
- 31/32 inch
- 1/2 inch
- 2-13/16 inches
- 2
- D2: 11.5 mm (29/64 inch) · Active Cutting Material: Replaceable coated carbide inserts · Maximum RPM: 16,000 · General-Purpose Inserts: RCK-460 (2) · Optional MDF-Grade Inserts: RCK-462 (2) · Insert Screw: 67133 · Insert Screw Key: 5001 · Adjustment Screw Key: 5003 · Angle Index: 15° click-stop increments · Angle Tolerance: ±0.5° · Machine Compatibility: CNC machine · Handheld router · Router table
- Amana Tool identifies RC-2375 for CNC machines, handheld routers, and router tables. Match the 1/2-inch shank to a compatible collet and observe the official 16,000 RPM maximum.
Best Fit Applications
Variable-Angle Chamfers
Rabbets and Bevels
Spoilboard Cuts
Hardwood and Softwood
MDF, Plywood and Plastics
Product Highlights
Indexed 15-Degree Adjustment
The notched dial clicks and stops every 15°, with a manufacturer-published bit tolerance of ±0.5°.
Double-Edge Insert System
Two coated replaceable inserts provide two cutting edges, with RCK-460 general-purpose and optional RCK-462 MDF-grade options.
Compatibility & Installation Notes
Confirm exact Tool No. RC-2375, a compatible 1/2-inch collet, adequate cutter clearance and guarding, the selected angle setting, secure insert and screw seating, and the official maximum speed of 16,000 RPM. RCK-462 is an optional MDF-grade insert reference; 67133, 5001, and 5003 are service-part references rather than additional cutting tools. Follow Amana Tool and machine-manufacturer safety documentation for CNC, handheld-router, or router-table use.
Adjustable In-Bevel™ Geometry Across a -45° to +90° Range
Amana Tool RC-2375 combines a 2-inch diameter, 31/32-inch cutting height, 1/2-inch shank, 2-13/16-inch overall length, two insert cutting flutes, indexed 15-degree adjustment, and a published maximum speed of 16,000 RPM.
Its coated double-edge insert system and broad material list support variable-angle chamfer, rabbet, bevel, and spoilboard work on CNC machines, handheld routers, and router tables.
