Down-Shear Cutting Geometry
The shear angle supports efficient chip removal and is designed for a faster, cleaner cut than straight-angle geometry.
Amana Tool Carbide Tipped Down Shear Face Plunge Template 3/4 D x 2 Inch CH
CA$999.99
Out of stock
SKU
45364
Product Type
Carbide-Tipped Down-Shear Face Plunge Template Router Bit
Family / Category
Down-Shear Flush Trim Plunge Template Router Bits
Cutting Diameter
3/4 inch
Cutting Height
2 inches
Shank / Overall
1/2-inch shank · 4-inch overall length
Geometry / Flutes
Down-shear geometry · 2 flutes
Cutting Material
Carbide tipped
Pilot / Service Parts
Upper ball bearing · Replacement bearing 47721 · Collar 47739
Router Compatibility
Handheld and table-mounted routers
Carbide-Tipped Z2
Down-Shear Face Plunge Template Router Bit
Down-Shear Template Bit
Amana Tool 45364 is the exact carbide-tipped down-shear face plunge template router bit with a 3/4-inch diameter, 2-inch cutting height, 1/2-inch shank, 4-inch overall length, two flutes, and a shank-mounted upper ball-bearing pilot for template and pattern routing.
3/4 inDiameter (D)
2 inCutting Height (B)
1/2 inShank (d)
4 inOverall Length (L)
Down-Shear Template Bit
A two-flute, carbide-tipped plunge-cutting template router bit with a shank-mounted upper ball-bearing pilot. Its dedicated official page identifies the exact Tool No. as 45364.
Amana ToolCarbide TippedUpper BearingSKU 45364
Amana Tool identifies this bit for handheld and table-mounted routers. Use a compatible 1/2-inch collet; the pattern is positioned above the work for handheld routing and beneath the work for table-mounted routing.
Main Product Description
Amana Tool 45364 is the exact Tool No. shown on its dedicated official product page. The labelled specification block confirms a 3/4-inch diameter, 2-inch cutting height, 1/2-inch shank, 4-inch overall length, and two flutes.
This carbide-tipped bit combines plunge-cutting straight-bit geometry with a shank-mounted upper ball-bearing pilot. During template or pattern routing, the bearing follows the template edge while the cutting edges reproduce the template shape in the workpiece.
The down-shear geometry is designed to improve chip removal and deliver a faster, cleaner cut than a straight-angle configuration. The official service record lists replacement bearing 47721 and replacement collar 47739; both are replacement references rather than additional products included with this SKU.
Technical Specifications
Down-Shear Flush Trim Plunge Template Router Bits · SKU 45364
- Amana Tool
- Carbide-Tipped Down-Shear Face Plunge Template Router Bit
- 45364
- Down-Shear Flush Trim Plunge Template Router Bits
- Down-Shear Flush Trim Plunge Template Router Bits
- 3/4 inch
- 2 inches
- 1/2 inch
- 4 inches
- 47739
- 47721
- 2
- Active Cutting Material: Carbide Tipped · Shear Geometry: Down Shear · Pilot Configuration: Shank-Mounted Upper Ball Bearing · Router Compatibility: Handheld and Table-Mounted Routers
- Amana Tool identifies this bit for handheld and table-mounted routers. Use a compatible 1/2-inch collet; the pattern is positioned above the work for handheld routing and beneath the work for table-mounted routing.
Best Fit Applications
Template Routing of Parts
Pattern Routing
Joint Routing
Internal Cuts
Handheld or Router-Table Work
Product Highlights
Upper-Bearing Template Control
The shank-mounted ball-bearing pilot follows a template edge so the two cutting edges reproduce the pattern in the workpiece.
Verified 2-Inch Cutting Height
Exact Tool No. 45364 combines a 3/4-inch diameter, 2-inch cutting height, 1/2-inch shank, and 4-inch overall length.
Compatibility & Installation Notes
Confirm exact Tool No. 45364, a compatible 1/2-inch collet, adequate cutter clearance, secure workholding, and appropriate guarding. For handheld routing, the pattern is above the work; for table-mounted routing, the pattern is beneath the work. Replacement bearing 47721 and collar 47739 are service references, not additional tools included with this SKU. Follow Amana Tool and machine-manufacturer safety documentation.
Down-Shear Template Routing with Upper-Bearing Control
Amana Tool 45364 combines carbide-tipped two-flute geometry with a 3/4-inch diameter, 2-inch cutting height, 1/2-inch shank, and 4-inch overall length.
Its shank-mounted upper bearing supports template and pattern routing of parts, joints, and internal cuts in handheld or table-mounted routers.
