Three Roundover Profiles
One set provides 1/8-inch, 3/16-inch and 1/4-inch radii for varied lettering, fluting and decorative trimming profiles.
Amana Tool 4-Piece Tru Point Roundover Insert CNC System Router Bit Set, 1/2-Inch Shank
CA$999.99
Out of stock
SKU
AMS-216
Product Type
4-Piece Tru Point Roundover Insert CNC Router Bit Set
Family / Category
Tru Point Insert CNC System Router Bits
Set Contents
One tool body plus three solid-carbide roundover inserts
Radius Profiles
1/8 inch · 3/16 inch · 1/4 inch
Shank / Overall
1/2-inch shank · 2-3/4-inch tool-body length
Cutting Diameter
7/8 inch with each included radius profile
Insert References
RCK-471 · RCK-472 · RCK-473
Operating Reference
18,000 RPM
Applications
CNC lettering,engraving,signmaking,fluting and decorative trimming
4-Piece Tru Point
Roundover Insert CNC Set
Tru Point Roundover System
Amana Tool AMS-216 combines one 1/2-inch-shank Tru Point CNC tool body with three industrial-quality solid-carbide roundover inserts in 1/8-inch, 3/16-inch and 1/4-inch radii. The system is designed for lettering, engraving, signmaking, fluting and decorative trimming in hardwood, softwood, MDF, plastic and plywood.
4 PiecesBody Plus Three Inserts
1/8 · 3/16 · 1/4Roundover Radii
1/2 inTool Body Shank
18,000Operating RPM Reference
Tru Point Roundover System
A serviceable CNC profiling system with one reusable tool body and three interchangeable solid-carbide roundover inserts for fine point-cutting geometry.
Amana ToolInsert Carbide1/2-Inch ShankSKU AMS-216
Intended for CNC lettering, engraving, signmaking, fluting and decorative trimming. Match the 1/2-inch shank to a compatible CNC collet and use the setup data for the installed radius profile.
Main Product Description
Amana Tool AMS-216 is the exact four-piece Tru Point Roundover Insert CNC System set shown on its dedicated official product page. The specification block confirms a 1/2-inch shank, 2-3/4-inch tool-body overall length and the description “Tru Point Roundover Insert CNC System 4-Piece Set.”
The official set description states that AMS-216 contains one tool body and three industrial-quality solid-carbide inserts with 1/8-inch, 3/16-inch and 1/4-inch radii. The matching profiles produce a 7/8-inch cutting diameter, with cutting heights of 1/4 inch, 3/8 inch and 1/2 inch respectively.
The system is intended for lettering, engraving, signmaking, fluting and decorative trimming. Amana Tool lists hardwood, softwood, MDF, plastic and plywood as supported materials. The linked Tru Point speed-and-feed chart publishes an 18,000 RPM operating reference for this insert roundover CNC system.
Technical Specifications
Tru Point Insert CNC System Router Bits · SKU AMS-216
- Amana Tool
- 4-Piece Tru Point Roundover Insert CNC Router Bit Set
- AMS-216
- Tru Point Insert CNC System Router Bits
- Tru Point Insert CNC System Router Bits
- One tool body plus three roundover inserts
- 1/2 inch
- 2-3/4 inches
- Replaceable solid-carbide inserts
- 1/8 inch · 3/16 inch · 1/4 inch
- 7/8 inch with each listed radius profile
- RCK-471 matching insert · D1 5/16 inch · Cutting height 1/4 inch
- 3/16-Inch Profile: RCK-472 matching insert · D1 7/16 inch · Cutting height 3/8 inch · 1/4-Inch Profile: RCK-473 matching insert · D1 9/16 inch · Cutting height 1/2 inch · Operating RPM: 18,000 RPM official system reference · Torx Screw: 67110 · Torx Key: 5005 · Primary Applications: Lettering · Engraving · Signmaking · Fluting · Decorative trimming · Supported Materials: Hardwood · Softwood · MDF · Plastic · Plywood
- Intended for CNC lettering, engraving, signmaking, fluting and decorative trimming. Match the 1/2-inch shank to a compatible CNC collet and use the setup data for the installed radius profile.
Best Fit Applications
CNC Lettering
Engraving and Signmaking
Decorative Fluting
Point-Cutting Roundovers
Wood, MDF and Plastic
Product Highlights
Reusable Insert System
The 1/2-inch-shank tool body accepts replaceable solid-carbide profile inserts instead of requiring a separate complete tool for each included radius.
Fine Tru Point Geometry
The point-cutting roundover design is intended for detailed CNC lettering, engraving, signmaking, fluting and decorative trimming.
Compatibility & Installation Notes
Confirm exact set SKU AMS-216, a compatible 1/2-inch CNC collet, the installed radius profile, adequate clearance and guarding, secure workholding, a clean insert seat and correctly secured Torx hardware. Use the official 18,000 RPM operating reference and the Amana Tool data associated with the installed insert. The fine plunge point requires careful handling and is not guaranteed against breakage. Follow Amana Tool and CNC machine-manufacturer safety documentation.
Three Solid-Carbide Roundover Profiles on One CNC Tool Body
Amana Tool AMS-216 combines one 1/2-inch-shank, 2-3/4-inch-long Tru Point tool body with 1/8-inch, 3/16-inch and 1/4-inch solid-carbide roundover insert profiles.
Its serviceable four-piece configuration supports detailed lettering, engraving, signmaking, fluting and decorative trimming in hardwood, softwood, MDF, plastic and plywood.
