Four Verified Profiles
The collection combines exact tool numbers RC-1045, RC-1108, RC-1102, and RC-1104 to cover 45°, 60°, 90°, and 120° V-groove profiles.
Amana Tool 4-Piece 3D CNC Signmaking, Lettering & Engraving Insert-Carbide 45°, 60°, 90° & 120° V-Groove Router Bit Collection
CA$999.99
Out of stock
SKU
AMS-150
Product Type
4-Piece 3D CNC Insert-Carbide V-Groove Router Bit Collection
Family / Category
CNC Signmaking,Lettering &Engraving Router Bit Sets
Included Profiles
45° · 60° · 90° · 120° V-groove profiles
Included Tools
RC-1045 · RC-1108 · RC-1102 · RC-1104
Shank Diameter
1/2 inch on all four tools
Cutting Material
Replaceable solid-carbide cutting inserts
Storage / Literature
Fitted wood showcase box · Full-colour booklet included
Published Speed
18,000 RPM chart listing for all four included tools
Applications
Signmaking,lettering,engraving,miter folds,wood panels,foam,plastics and composites
4-Piece 3D CNC
V-Groove Router Bit Collection
3D Signmaking Set
Amana Tool AMS-150 is the exact four-piece insert-carbide CNC collection for signmaking, lettering, engraving, and miter-fold work. The set combines 45°, 60°, 90°, and 120° V-groove profiles, each with a 1/2-inch shank, replaceable solid-carbide cutting inserts, a fitted wood storage box, and an included full-colour booklet.
4 PiecesComplete CNC Collection
45°–120°Four V-Groove Angles
1/2 inShank Diameter
18,000Published Chart RPM
3D Signmaking Set
Four industrial CNC V-groove router bits covering 45°, 60°, 90°, and 120° profiles for signmaking, lettering, engraving, and miter-fold applications. The exact official Tool No. is AMS-150.
Amana Tool4-Piece SetInsert CarbideSKU AMS-150
Intended for compatible CNC routing equipment with a 1/2-inch collet, sufficient cutter clearance, and secure workholding. The current official insert V-groove chart lists 18,000 RPM for all four included tool numbers.
Main Product Description
Amana Tool AMS-150 is the exact SKU shown on its dedicated official product page. The collection contains RC-1045 at 45°, RC-1108 at 60°, RC-1102 at 90°, and RC-1104 at 120°. All four tools use 1/2-inch shanks and replaceable solid-carbide cutting inserts for repeatable CNC V-grooving and profile work.
The set is designed for miter folds, signmaking, and lettering. Amana Tool also lists foam, laminate, melamine, MDF/HDF, sign board, solid surface, veneered plywood, wood, Xanita® Board, 20-pound high-density urethane, and engraving work in aluminum, bronze, copper, and carbon fiber among the supported applications.
The collection is supplied in a fitted wood storage box measuring 8 inches long by 6-1/4 inches wide by 3-1/4 inches high and includes a full-colour booklet. Each insert provides two usable cutting edges by rotating the insert when one edge becomes worn, while the secure locking system maintains insert location and accuracy.
Technical Specifications
CNC Router Bit Sets · SKU AMS-150
- Amana Tool
- 4-Piece 3D CNC Signmaking, Lettering & Engraving Insert-Carbide V-Groove Router Bit Collection
- AMS-150
- CNC Signmaking & Engraving Collection
- CNC Router Bit Sets
- 4
- RC-1045 · 45° V-Groove
- RC-1108 · 60° V-Groove
- RC-1102 · 90° V-Groove
- RC-1104 · 120° V-Groove
- 1/2 inch on all four tools
- Replaceable Solid-Carbide Inserts
- Published Speed Chart: 18,000 RPM for RC-1045, RC-1108, RC-1102 & RC-1104 · Storage Box: Fitted wood showcase box · Box Dimensions: 8 in L × 6-1/4 in W × 3-1/4 in H · Included Literature: Full-colour booklet
- Intended for compatible CNC routing equipment with a 1/2-inch collet, sufficient cutter clearance, and secure workholding. The current official insert V-groove chart lists 18,000 RPM for all four included tool numbers.
Best Fit Applications
3D CNC Signmaking
Lettering & Engraving
Miter-Fold Joinery
Wood Panels & Solid Surface
Foam, Plastics & Composites
Product Highlights
Replaceable Carbide System
High-grade solid-carbide inserts provide two usable cutting edges and allow worn edges to be renewed by rotating the insert in its tool body.
Complete Stored Collection
All four 1/2-inch-shank tools are organized in a fitted wood showcase storage box and supplied with a full-colour booklet.
Compatibility & Installation Notes
Confirm exact collection SKU AMS-150, a compatible 1/2-inch CNC collet, adequate clearance for the selected included tool, secure workholding, and operation within the published limits for that exact tool number. The current official chart lists 18,000 RPM for RC-1045, RC-1108, RC-1102, and RC-1104. Amana Tool limits the listed aluminum, bronze, copper, and carbon-fiber applications to engraving. For Xanita LightBoard panels, the manufacturer recommends compatible MDF inserts. Follow all Amana Tool and CNC machine safety documentation.
Four Insert-Carbide Profiles for CNC Signmaking and V-Grooving
Amana Tool AMS-150 brings together 45°, 60°, 90°, and 120° V-groove profiles in one four-piece 1/2-inch-shank CNC collection with replaceable solid-carbide inserts.
The fitted storage box, included booklet, broad material coverage, and four verified tool numbers make the set a compact solution for signmaking, lettering, engraving, miter folds, and related CNC profile work.
