Carbide tips form the working edges, supported by the tool body.
Saw BladeSKU 11-012 002 100
Match the 1 in bore and all locating features to the machine mounting.
Main Product Description
This Walter ATB cut-off saw blade is designed to make straight saw cuts. It is suitable for solid wood and wood-based boards.
The tooth pattern and cutting width determine how the blade engages the workpiece. Match the diameter and bore to the saw before fitting the blade. Carbide tips form the working edges, supported by the tool body.
The blade diameter is 12 in, with 100 teeth. The 1 in bore must match the arbor and the complete mounting arrangement. Its nominal kerf is .126 in.
Technical Specifications
11-012 002 100 · ATB Cut-Off Saw Blade
BrandWalter
SKU11-012 002 100
Product ClassSaw Blade
Product TypeATB Cut-Off Saw Blade
Family / SeriesType 11
Manufacturer Part Number11-012 002 100
Cutting Diameter (D)12 in
Kerf (B).126 in
Plate Thickness (b).087 in
Bore Diameter (d)1 in
Cutting MaterialCarbide Tipped
Number of Teeth100
Tooth GeometryATB
Hook Angle (degrees)5
Workpiece Materialssolid wood, wood-based boards
Configuration Details
Tool Configuration
cutting along and across the grain
Performance Details
Product Highlights
01
Working geometry
The tooth pattern and cutting width determine how the blade engages the workpiece.
02
Cutting material
Carbide tips form the working edges, supported by the tool body.
03
This version
The blade diameter is 12 in, with 100 teeth. The 1 in bore must match the arbor and the complete mounting arrangement. Its nominal kerf is .126 in.
Before Machining
Compatibility & Installation Notes
Match the part number, mounting dimensions and machine configuration before use. Follow the tool and machine manufacturer’s operating instructions.
Production Outcome
ATB Cut-Off Saw Blade
Walter 11-012 002 100 is designed to make straight saw cuts. It is suitable for solid wood and wood-based boards.
The tooth pattern and cutting width determine how the blade engages the workpiece. Match the diameter and bore to the saw before fitting the blade. Carbide tips form the working edges, supported by the tool body.
The blade diameter is 12 in, with 100 teeth. The 1 in bore must match the arbor and the complete mounting arrangement. Its nominal kerf is .126 in. Match the 1 in bore and all locating features to the machine mounting.
For help selecting this version, share your machine model, workpiece material and intended operation with Titan.
